Summary of Contents for T-Eye ADR-3000
-
Page 2: Main Features
“Player.exe” line starts the playback software. Data analysis The recorded data can be easily analyzed for speed, vehicle location and direction of travel including impact by using the T-eye Player that is found on conveniently on the supplied SD card. -
Page 3: Table Of Contents
Continous recording while driving ................. 12 SD Card related information .................. 13 Functions of each part ................... 14 Using T-eye Player: Playback, SD Card and Initial System Set-Up 15 PC Minimum Systems Requirements ..............15 To Review Video ....................15 Playback Interface Controls ................... -
Page 4: Safety Instructions
Safety Instructions To ensure proper operation please read the manual before installation and use. Failure to follow this safety notice may cause a malfunction and may void the warranty. Do not apply excessive shock or Do not clean the product with never insert foreign materials into water or volatile solvents. -
Page 5: Components
Components Body External Alarm Button Mirror Mount IR Light Module Fixed-type Holder IR light Holder SD Card Users Guide CD Cigarette Lighter Plug for Power Supply... -
Page 6: Part Numbers
Part Numbers Front face of Body Name Description Power Connection Port Used to connect the power cord with the unit. Front Mounting connection Used to mate with the selected mount. Forward Facing Camera Used to record scenes through the windshield. SD Card Slot Used to insert the SD Card into unit. -
Page 7: Rear Panel Of Recorder
Rear panel of Recorder Name Description Status Display Used to display the status of T-eye or traffic information by using English text or symbols. Rear Mount Connection Used to mate with the selected mount. Built-in Speaker Provides audio output for chime and any information. -
Page 8: Technical Specifications
Built-in GPS module Automatic Event Sensor, Alarm input G-sensor (3-axis), Manual external alarm trigger Memory SD Card (512M to 8GB) * T-eye Body DC 5V to recording unit Power Input Cigarette Lighter Plug DC 12V to 24V input * Depending on the model ordered, typically a 2GB SD Card is provided with the unit. -
Page 9: Installation
Installation: Be sure to stop the engine before installing the product. Remove all power to any areas where wires will be connected. Install the product in a location where the satellite signals are received. Caution Before permanently mounting the unit, ensure that the camera views meet your requirements. -
Page 10: Installing The Ir Light Module
2. Installing the IR light Module You may install the product using any of the following 2 mounting methods: Method1. Installation with the mirror mount Connect the “Y” power Insert the IR light module cable adapter to both the IR after aligning it with the top light module and the of the mirror holder... -
Page 11: Installing The Remote Manual Alarm Event Button
3. Installing the Remote Manual Alarm Event Button Insert the Jack of the manual Locate the best position for alarm input cable into the the remote alarm button. connection port on the Secure the button by upper part of the Cigarette removing the adhesive film Lighter Plug. -
Page 12: Tips Before Using The Product
Continous recording while driving T-eye informs you of your vehicle’s speed, when stopped, the unit it displays the time. When the capacity of the SD Card has been reached, the oldest files are overwritten for continuous recording. The data recorded by either the unit’s internal G-Sensor or external manual record button are not overwritten. -
Page 13: Sd Card Related Information
To playback video, use the T-eye exclusive viewer that is located on the SD card. With the SD card inserted in your computer, explore the SD card, locate the “player .exe” file which is located on the SD card. -
Page 14: Functions Of Each Part
Functions of each part Forward facing and rear facing/interior view camera The camera must be horizontal and vertical. When the lens of the camera is obstructed or is dirty, clear images may not be captured. Periodic cleaning is required. To clean the lens, use a soft camera lens cloth to prevent damage. -
Page 15: Using T-Eye Player: Playback, Sd Card And Initial System Set-Up
Graphics Hard disk drive space 200 MB or higher *Note: When using MS Windows Vista and T-eye Player software for the first time, you may have to run the Player in Administrator Mode. To Review Video: Remove Power from the unit. Remove the SD card from the unit and Insert the SD card into a PC or SD card reader and connect it to a computer. -
Page 16: Playback Interface Controls
Playback Interface Controls Button Function Button Function Move to the previous frame Open a file Reverse Playback Convert the file into an AVI format Pause the Playback Link the recorded data with map Stop Playback Access System Set Up Menu Playback Exit, close the program Move to the next frame... -
Page 17: System Configuration
Enables or Disables the audio record function. Sets the time to record the previous scenes before the event. Pre-Event Recording (Ex. in case of 3 minutes, T-eye records scenes for previous 3 minutes Time and next 1 minute for a manual record event.) Sets any Password to be used to access the recorded data. -
Page 18: Playback
Playback With the Playback interface Open: After clicking the folder icon on the lower right corner of the viewer, click Change Directory to select the location for the recorded data. Typically the first time you do this all the files are located on the SD card. If saved elsewhere, use this utility to explore your computer to locate the file for playback. -
Page 19: Converting The Authenticated Files Into Avi File Format
Converting the Authenticated files into AVI file format One may convert a portion of the recorded data into an AVI file format when one wants to share the recorded data with someone else or email a file. Click the AVI conversion button ( ) at the start of video clip position where you want to convert the images into the AVI file format. -
Page 20: Interfacing With A Gis/City Map
Interfacing with a GIS/City map T-eye simultaneously records the GPS data while driving so you can check the driver’s route on the map. Click the GIS/MAP icon ( ) on the lower right corner. The map window appears for the user to see the vehicle location and travel onto a city map. -
Page 21: Additional Functions Of Player: Pop-Up Display Window
Additional Functions of Player: Pop-up Display window When you double-click the display window, the recorded images are played back at the original size. Double clicking the screen returns the view to normal, original size. You may use your PC's mouse to move the screens and adjust them within your desktop window. -
Page 22: Analyzing G-Sensor Data
Analyzing G-SENSOR data The G-sensor (Gravity Sensor) furnishes data for X, Y and Z axis and stores it along with the other recorded data on the SD card. When using the playback software, this information is represented in a graphic format. The resulting graph may be used to analysis the driving condition and driver’s habits. -
Page 23: System Diagnostics Via The T-Eye Led Display
System Diagnostics via the T-eye LED Display T-eye status Display Status Event Sound or Status Display Initialization after power applied No sound. [ dr ][Init] Chime is heard (“Ding dong”) from the speaker. System When SD Card is not inserted... -
Page 24: Firmware And Playback Sw Update
Firmware and Playback SW Update Firmware Update With the Unit unpowered (blank unlit multi segment LED display), remove the SD Card from the unit; Insert the card into either the SD card slot on the computer. If your computer doesn’t have SD card slot, connect the memory reader to the USB port on your computer. -
Page 25: Trouble Shooting
Trouble shooting When you start the playback software, if you have ‘skin control error’ please follow below; For XP OS User, Needed log on with administrator right when you start PC. If user log on without administrator right, the player will not run. Skin error message will display For Vista OS user Firstly log on with administrator right when you start PC.
