Model:
For your convenience, we recommend to attach the serial number label HERE.
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE.
Installation
and Operating
Instructions
FS54R
FS54CER
727626122014
Advertisement
Table of Contents
Related Manuals for Parmco FS54R
Summary of Contents for Parmco FS54R
- Page 1 FS54CER For your convenience, we recommend to attach the serial number label HERE. As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE.
- Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to nd out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...
-
Page 3: Table Of Contents
INDEX E ............................2 S ............................2 N ......................... 2 P .................. 3 S ................4 N ............................4 E ........................6 N ..............................7 L ............................... 11 P ............................. 12 N .......................... 13 E ..............................14 G ............................17 S .................. -
Page 4: C O N D I T I O N S O F U S E
All electric appliances should only be installed by authorized personnel. If the supply cord is damaged, it must be replaced by the Parmco or an authorised service agent. Do not spray aerosols in the vicinity of this appliance while it is in operation. -
Page 5: W A R N I N G S F O R U S E O F G R I L L , O V E N A N D C O O K T O P
Do not cook on the ceramic cooktop without liquid or food inside pots as this may affect the hob’s performance. If the surface of the ceramic cooktop is damaged, do not use the cooktop and contact Parmco Appliances. ... -
Page 6: I N S T A L L A T I O N , C L E A N I N G A N D S E R V I C I N G W A R N I N G S
Only an authorised person must install this appliance. Before first time use, ensure that all packing materials are removed from the appliance. In order to avoid any potential hazards, the Installation Instructions must be strictly adhered to. ... - Page 7 1. Hob – ceramic hotplates 2. Heat shield 3. Telescopic runner 4. Grill Drawer 5. Oven Shelf 6. Baking tray 7. Oven Inner Glass Door 8. Oven Door 9. Control Panel 10. Socket-outlet 11. Fuse holder 12. Grill Element (inside compartment) 13.
-
Page 8: F I R S T T I M E U S E O F T H E A P P L I A N C E
7. Function switch Control Knob • Sets Oven Function/Mode. 8. 120 Minute Ringer Timer (where fitted) • Sets count-down time and if oven is being used, turns OFF the oven after the cooking time set has ended. Please wipe out the oven’s inside cavity prior to first time operation with warm soapy water and polish dry with a soft clean cloth. -
Page 9: U S I N G T H E O V E N
Always follow the instructions for placing the shelves and side racks into the oven, to avoid accidents. Do not line the oven with foil, it will damage the enamel coating and will not be covered by warranty. Do not place cookwares or anything else on the bottom of oven as trapped heat will damage the oven enamel coating and could damage the concealed element. - Page 10 Selection of cooking temperature is carried out by turning the knob clockwise to the temperature required, ranging between 60°C to MAX . The “oven indicator lamp” will come on when the oven is heating up. When it goes out it indicates that the set temperature has been reached.
- Page 11 The following cooking guide is intended as a guide only. You may be required to set oven 10-20 degrees above or below this guide to get the wanted results. Adjustments may be needed to the cooking time to suit personal expectations. If you are new user of an fan forced oven, we recommend making these adjustments until you get to know the way your oven performs.
- Page 12 Problem Causes What to do Incorrect shelf position Select shelf that puts food in centre of oven Oven tray too large Remove oven tray. Use smaller trays or dishes Uneven cooking Trays not in centre Put trays in centre Oven fan causing uneven browning or small Rotate food during cooking, or use Conventional cakes to lean over Mode (i.e.
- Page 13 Also spacing and size of food on trays and the number of baking dishes in the oven can affect air circulation. Steam and Condensation Often owners of new ovens will see a higher level of steam and condensation than they are used to in their previous appliance.
-
Page 14: U U S S I I N N G G T T H H E E C C O O O O K K T T O O P
Ensure that the enameled grill tray is positioned correctly on the pins located on the telescopic side runners. Insert the grill rack insert, choosing height level required for food being grilled, into the enameled grill tray and close the grill drawer fully. - Page 15 Check the radiant coil elements position on your stove before using it for the first time, as shown in this image. The high-speed radiant coil element heats rapidly from a cold start. This saves power. The radiant coil elements can be unplugged and the enamelled element dishes can be removed for cleaning any spillage.
- Page 16 Always make sure that the cooker is turned off before cleaning. Always clean the stove immediately after use. Do not use a steam cleaner to clean this appliance. Do not use caustic- based cleaners to avoid damaging aluminums parts and remove the enamel. Keep enamel clean by wiping it with a soft cloth and warm soapy water.
- Page 17 Lift the enameled grill tray out. Clean the sides and bottom of compartment with hot soapy water. If stronger action is needed use a nonabrasive oven cleaner applied with a nylon scourer. Open the door fully. Remove oven shelves and side racks.
- Page 18 Clean the glass door using non-abrasive products or sponges and dry it with a soft cloth. Do not use the oven without the inner door panes fitted correctly. When re-fitting inner glass door panes ensure they go back in facing the same way they came out. The doors are coated with a very slight reflective coating to reflect the heat back into the oven cavity and keep the outer door cooler to touch.
- Page 19 Standards and Regulatory Requirements with particular reference to the New Zealand Electrical Standards. Any attempt to install this or any other Parmco product without an authorised person could result in damage to the product and a possible health hazard. Not having an authorised person install this appliance may result in all associated warranties from Parmco Appliances being null and void.
-
Page 20: 4 . I N S T A L L I N G T H E S T O V E - P O W E R C O N N E C T I O N S
Using a screwdriver, prize open tabs of the Terminal board cover. Remove the wire clamp screw. Fasten the wires beneath the corresponding screw heads, using brass ‘bridge’ for single phase supply. Fasten cable clamp and close the cover of the terminal board. ... - Page 21 You must not pull the cooker by the door handles. If the supply cord or cable is damaged, it must be replaced by an approved service agent or Parmco. Please check the product and make sure that there is no damage.
- Page 22 Connect Electricity supply/gas supply but do not turn on until installation is completed. Slide the cooker back into the anti-tilt plate so that rear cover rests against the rear wall. Then check the height and level of the cooker. If required, pull the cooker back out and adjust the leveling feet as required. Stability bolt...
-
Page 23: 16. Technical Specifications
16. Technical specifications FS54R Model Oven capacity(L) Grill capacity(L) Voltage(V) 220-240 Frequency (Hz) 50/60 Circuit breaker(A) Fush(A) Oven power（W） 1710-2030 Grill power（W） 1650-1800 Hobs power（W） Max 6000 Product dimension（mm） 540*630*1140 Gross/net weight（Kg） 63.5/54 Amps FS54CER Model Oven capacity(L) Grill capacity(L) - Page 24 Please retain this Warranty card together with receipt or other proof of purchase date when seeking service during the warranty period • Normal or scheduled maintenance including blocked filters or ducting. • Consumable items such as light bulbs. • Any damage to ceramic glass hobs caused by spills when cooking. • Any breakage or damage of glass items. Please contact Parmco at 09 573 5678 if your • Any damage caused by non recommended product used for cleaning, appliance needs servicing under warranty. Please maintaining, lubricating or similar. have your model number and proof of purchase ready. • Any aspect relating to the installation of the product, or damage caused Warranty repairs must be authorized by Parmco. during installation including blocked access for repair. • Any third party (including reseller) or consequential loss or damage (direct or indirect) however arising. Subject to updates without prior notice, please visit www.parmco.co.nz for E & O.E. 727626112014 the latest version.
