Installation
and Operating
Instructions
Model:
FS54R
For your convenience, we recommend to attach the serial number label HERE.
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE.
727626032014
Advertisement
Table of Contents
Related Manuals for Parmco FS54R
Summary of Contents for Parmco FS54R
- Page 1 FS54R For your convenience, we recommend to attach the serial number label HERE. As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE.
- Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to find out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...
-
Page 3: Table Of Contents
INDEX E ............................2 S ........................... 2 N ..................2 B ............3 G ..........................3 S ..............3 N ..........................4 E ......................5 N ............................... 6 L ............................10 R ................11 N ........................12 G ................... 12 G ........................... -
Page 4: C O N D I T I O N S O F U S E
We recommend that you read the instructions in this Manual carefully before use for the best performance and to extend the life of your appliance, as it will provide you with all the instructions you require to ensure its safe installation, use and maintenance. -
Page 5: W A R N I N G S F O R U S E O F G R I L L , O V E N , A N D A P P L I A N C E H O B
Do not leave grill on unattended. Do not cover the grill dish insert with foil. Placing thick portions of food under grill can be a fire hazard. Fat left on a grill dish is a fire hazard! Keep grill clean and turn off grill immediately after use. ... -
Page 6: P R O D U C T D E S C R I P T I O N
1. Hob 2. Heat shield 3. Telescopic runner 4. Grill Drawer 5. Oven Shelf 6. Baking tray 7. Oven Inner Glass Door 8. Oven Door 9. Control Panel 10. Socket-outlet 11. Fuse holder 12. Grill Element (inside compartment) 13. Grill tray wire rack insert（reversible to adjust height） 14. -
Page 7: F I R S T T I M E U S E O F T H E A P P L I A N C E
6. Oven Temperature Control Knob • Adjusts grilling temperature. 7. Function switch Control Knob • Sets Oven Function/ Mode. 8. 120 Minute Ringer Timer (where fitted) • Sets count-down time and if oven is being used, switches the oven OFF after the cooking time set has ended. ... -
Page 8: U S I N G T H E O V E N
Always follow the instructions for putting the shelves and side racks into the oven, to avoid accidents. Do not line the oven with foil, it will damage the enamel coating. Do not place cookwares or anything else on the bottom of oven as trapped heat will damage the oven enamel coating and could damage the concealed element. - Page 9 Selection of cooking temperature is carried out by turning the knob clockwise to the required temperature, between 60°C to MAX . The “oven indicator lamp” will come on when the oven is heating up. When it goes out it means that it reaches the required temperature .
- Page 10 The following cooking guide is intended as a guide only. You may be required to set oven 10-20 degrees above or below this guide to get the result you want. Also adjustments may be needed to the cooking time to suit personal expectations. If you are new to use a Fan Forced oven, It is advisable to make these adjustments until you get to know the way your oven performs.
- Page 11 Problem Causes What to do Incorrect shelf position Select shelf that puts food in centre of oven Oven tray too large Remove oven tray. Use smaller trays or dishes Uneven cooking Trays not in centre Put trays in centre Oven fan causing uneven browning or small Rotate food during cooking, or use Conventional cakes to lean over Mode (i.e.
- Page 12 Always turn off the grill immediately after you have finished cooking and pull drawer out or remove grill tray otherwise fat left in the tray in the hot grill compartment will continue to smoke or could catch fire. Wash grill tray &...
-
Page 13: 1 . U S I N G T H E C O I L E D E L E M E N T S O F Y O U R C O O K E R
Do not use pots and pans which are unsteady, as these could overbalance. Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can damage the cook top. Do not turn on elements if there is no pot or pan on hotplate or if they do not contain food or liquids in them ... -
Page 14: 2 . T H E S O C K E T C O N N E C T I O N
Use this socket with appliances that draw ≤10 Amps. Please make sure that panel of the socket outlet is dry. First shut off the power supply to the stove. Use pliers insurance cover to open the fuse holder (Fig.1) ... - Page 15 To clean the enamelled element bowls, lift element and pull out of socket pull. Remove the bowl and wash in warm soapy water. Lift the enameled grill tray out. Clean the sides and bottom of compartment with hot soapy water. If stronger action is needed use a nonabrasive oven cleaner applied with a nylon scourer.
-
Page 16: 4 . T R O U B L E S H O O T I N G
Clean the glass door using non-abrasive products or sponges and dry it with a soft cloth. Do not use the oven without the inner door panes fitted correctly. When re-fitting inner glass door panes ensure they go back in facing the same way they came out. The doors are coated with a very slight reflective coating to reflect the heat back into the oven cavity and keep the outer door cooler to touch. -
Page 17: 5 . I N S T A L L I N G C O O K E R - P O W E R C O N N E C T I O N S
Power not turned on Switch on electricity Household fuse blown Check fuses Oven light not Circuit breaker tripped Check circuit breaker working Lamp blown or loose in socket Replace or tighten globe Heat escaping through incorrectly Check shelves or dishes are not preventing door closing sealed door properly, Check that door is fitted properly after door Oven not hot... -
Page 18: I N S T A L L I N G Y O U R N E W C O O K E R
Wire cross-sectional area(mm2) Connection mode Min6 － － Min6 Min6 － － － － Min2.5 Min2.5 Min6 Min6 Min2.5 Min1.5 Min1.5 Min6 Min6 Install an approved circuit breaker with a minimum contact opening of 3 mm, between the appliance and the mains fuse box .The circuit breaker should be sized according to the load and should comply with current regulations in New Zealand (the earth wire should not be interrupted by the circuit breaker). - Page 19 Determine position of cooker and ant-tilt plate. Securely fix the anti-tilt plate to the floor with appropriate fasteners. Fasten the stability bolt bracket to the front frame with the 2 screws supplied. Reposition the cooker back into the anti-tilt plate and then mark the position of the stability bolt hole.
-
Page 20: 17. Technical Specifications
17. Technical specifications FS54R Model Oven capacity(L) Grill capacity(L) Voltage(V) 220-240 Frequency (Hz) 50/60 Circuit breaker(A) Fush(A) Oven power（W） 1710-2030 Grill power（W） 1650-1800 Hobs power（W） Max 6000 Product dimension（mm） 540*630*1140 Gross/net weight（Kg） 63.5/54... - Page 21 09 573 5678 f: 09 573 5699 e: sales@parmco.co.nz w: www.parmco.co.nz Parmco Appliances 2 year warranty The Warranty: The Warranty is not valid: • If the product is not installed and operated in accordance with the operating • Subject to the terms and conditions contained within this instructions. warranty, if the product is not of Acceptable Quality (as • If the product is not installed to comply with the electrical, gas, plumbing defined in the Consumer Guarantees Act) within 2 years of and other Regulations and Codes of Practice in New Zealand. the date of original purchase, then Parmco Sales undertakes • If the product is operated on voltages or frequencies outside the normal range for domestic appliances in New Zealand. to repair or, at it’s sole discretion, replace the product. • If the product is not used in normal domestic use, or if it is used in a • The warranty does not cover the costs of transport, mileage...
