10 .....Local Rack Access LED LCD Console Installer/User Guide
The following table describes the menu control options.
Menu Control Options
Setting
Brightness/Contrast
Brightness
Contrast
Display Settings
Viewing mode
Horizontal Position
Vertical Position
Sharpness
Pixel Clock
Phase
Reset Display Settings Resets the settings to their factory default
Color Settings
Standard
Warm
Cool
Reset Color Settings
Auto Adjust
Other Settings
Language
Menu Timer
DDC/CI
LCD Conditioning
Reset Other Settings
Factory Reset/Version
Information
Description
Adjusts the brightness for the monitor
Adjust the contrast for the monitor
1:1 gives the actual pixel representation on the screen. Use this only if the resolution
is less than 1366 x 768
Aspect fills the screen to the largest amount of space without altering the aspect
ratio
Fill fills the screen completely
Click the left and right arrows to adjust the image left and right
Click the left and right arrows to adjust the image up and down
Adjust the sharpness of the image
Adjust how coarse the image is
Adjust how fine the image is
The monitor uses the standard color settings
The monitor uses the warm color settings
The monitor uses the cool color settings
Resets the color setting to their factory default
Automatically sets the monitor settings
Sets the display for English, German, Spanish, French, Japanese, Simplified
Chinese or Korean
Sets the menu timer
Enables Display Data Channel/Command Interface to permit software on your
computer to adjust the settings for the monitor
Enables LCD Conditioning to help eliminate any image retention
Resets to the other settings to the factory default
Resets the monitor to its factory default
