Page 1: Quick Start
383Z NETWORK VIDEO RECORDER SERIES Quick Start Please read instructions thoroughly before operation and retain it for future reference. Online manual download: www.surveillance-download.com/user/h306.swf h306_network_V1.3... - Page 3 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
- Page 4 MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO.
-
Page 5: Table Of Contents
TABLE OF CONTENTS 1. HARDWARE OVERVIEW ........................1 1.1 Front Panel..............................1 1.2 Rear Panel ..............................1 2. CONNECTION............................ 3 2.1 Camera IP Configurations by LAN (AUTO Mode)..................3 2.2 Advanced Setup ............................6 3. USER INTERFACE..........................7 3.1 Local................................7 3.1.1 NVR Status...............................7 3.1.2 Channel Status ..............................7 3.1.3 Quick Operation ...............................8... -
Page 7: Hardware Overview
HARDWARE OVERVIEW 1. HARDWARE OVERVIEW 1.1 Front Panel POWER AL AR M L AN REC O RD 1) LED indicators The NVR is power-supplied. An alarm event occurs. The NVR is connected to Internet. The NVR is connected to LAN. RECORD Recording is on. - Page 8 HARDWARE OVERVIEW...
-
Page 9: Connection
CONNECTION 2. CONNECTION 2.1 Camera IP Configurations by LAN Note: Before connecting the system and powering on the NVR, make sure a hard disk is installed in the NVR for evidentiary recording. To know how to install a hark disk, please refer to “APPENDIX 4 HARD DISK INSTALLATION’... - Page 10 CONNECTION The NVR will automatically configure the IP address of a camera connected by LAN if: The connected IP camera is our brand’s IP camera. The default IP configuration method of the camera is “DHCP”. The camera is powered on before the NVR is powered on. If the NVR doesn’t configure the IP address of your camera automatically as described above, your IP camera might NOT be: ...
- Page 11 CONNECTION 2.1.2 Static / DHCP Mode Note: SETTING Path: ADVANCED CONFIG) NETWORK LAN MODE. When the LAN port of the NVR is connected to a router (not a hub), you can: Choose “Static” when you know the network segment of your router. For example, the IP address of your router of 192.168.0.1, and the network segment of your router will be 192.168.0.xx (xx is ranged from 2 ~ 254).
-
Page 12: Advanced Setup
CONNECTION 2.2 Advanced Setup... -
Page 13: User Interface
USER INTERFACE 3. USER INTERFACE 3.1 Local 3.1.1 NVR Status Key lock Key unlock Channel lock Channel unlock USB flash drive / device connected No USB device connected Timer record on Timer record off Overwrite on Overwrite off Sequence mode on Sequence mode off PTZ mode on PTZ mode off... -
Page 14: Quick Operation
USER INTERFACE 3.1.3 Quick Operation Click to show the power off panel to either halt or reboot the system. Click to show the channel switch panel and select the channel you want. Switch to the channel you want first, and click to enter the zoom-in mode. -
Page 15: Remote
USER INTERFACE 3.2 Remote... - Page 16 USER INTERFACE...
-
Page 17: Network Configurations
NETWORK CONFIGURATIONS 4. NETWORK CONFIGURATIONS Note: Network configurations may require a person who has advanced network knowledge. It’s recommended to check with your installer for this service if possible. 4.1 Understand How Your Laptop / Computer Connect to Internet Then, connect your NVR directly to your router / hub / modem with a network cable, and power it on. If you’re using: ... - Page 18 NETWORK CONFIGURATIONS Step2: From your NVR, select (ADVANCED CONFIG), and select “Network” “WAN”. ADVANCED CONFIG CONNECTION E-MAIL DDNS CAMERA NETWORK TYPE DHCP DETECTION 192.168.1.112 ALERT GATEWAY 192.168.1.254 NETWORK NETMASK 255.255.255.0 DISPLAY PRIMARY DNS 168.095.1.1 RECORD SECONDARY DNS 139.175.55.244 NOTIFY PORT EXIT Step3: Select “DHCP”, and configure the DNS setting and port number.
-
Page 19: Modem / Hub + Modem
NETWORK CONFIGURATIONS IP Address: The IP address of the NVR, such as 192.168.1.112 in our example. Ports to Open: The port number you set for the NVR, such as 88 in our example. Check your connection Step1: Open your web browser, e.g. Internet Explorer. Step2: Enter the NVR address and the port number in the URL address box of the web browser, and see if you can access the NVR login page successfully. - Page 20 NETWORK CONFIGURATIONS Step4: (PPPOE & DHCP Only) Go to “DDNS”, and select “eagleeyes” in “SYSTEM NAME”. Note down the whole address under “CURRENT HOST ADDRESS”, such as MAC000E5318B3F0@ddns.dvrtw.com.tw. This will be the address used to access your NVR remotely. ADVANCED CONFIG CONNECTION E-MAIL DDNS...
-
Page 21: Appendix 1 Mobile Surveillance Via Eagleeyes
APPENDIX 1 MOBILE SURVEILLANCE VIA EAGLEEYES APPENDIX 1 MOBILE SURVEILLANCE VIA EAGLEEYES EagleEyes is a mobile phone program used with our surveillance system for remote surveillance. It has several advantages: It’s free (Except EagleEyes Plus for iPhone, EagleEyes Plus+ for Android, and EagleEyesHD Plus for iPad). ... -
Page 22: Appendix 2 Compatible Usb Flash Drive List
APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST Please upgrade the firmware of the NVR to the latest version to ensure the accuracy of the following table. If the USB flash drive is not supported by the NVR, you will see on the screen. -
Page 23: Appendix 3 Compatible Hard Disk List
APPENDIX 3 COMPATIBLE HARD DISK LIST APPENDIX 3 COMPATIBLE HARD DISK LIST Please upgrade the firmware of the device to the latest version to ensure the accuracy of the following table. MANUFACTURER MODEL CAPACITY ROTATION Seagate ST3320613AS 320GB 7200 rpm ST33500320AS 500GB 7200 rpm... -
Page 24: Appendix 4 Hard Disk Installation
APPENDIX 4 HARD DISK INSTALLATION APPENDIX 4 HARD DISK INSTALLATION Step1: Remove the top cover. Step2: Find the hark disk bracket in the NVR, and place the compatible hark disk in the bracket. Step3: With the PCB side facing up, connect the hard disk to the power connector and data connector. Step4: Fasten the hark disk with the supplied screws, two for each side. -
Page 25: Appendix 5 Battery Replacement
APPENDIX 5 BATTERY REPLACEMENT APPENDIX 5 BATTERY REPLACEMENT The time reset after power failure, for example, caused by a power outage, will cause the disorder of the recorded data, and users may have problems in searching the event clip they want. To keep the device time from resetting, a non-chargeable lithium battery, CR2032, is installed in the device.
