Arboria Longevity Assembly Instructions

P L E A S E R E A D C O M P L E T E LY B E F O R E Y O U B E G I N A S S E M B LY
C H E C K B O X F O R T H E S E C O N T E N T S
Trellis Caps (16)
1
Headers (2)
2
Braces (4)
3
Lattice Side Panels (2)
4

HARDWARE

- 1" Wood screws (32)
- 2" Wood screws (16)
- 2 1/2" Wood screws (8)
- Anchoring kit.
- Brass medallion and nails (2)
T O O L S Y O U W I L L N E E D
• Phillips screwdriver (electric driver recommended)
• Small hammer
• Two bags of concrete mix (60#) to anchor the arbor
HANDY TO HAVE
• Tape measure
Needle nose pliers
•
P R E L I M I N A R I E S

ARBOR PAINTING:

If you wish to stain or paint your arbor, we recommend
that you do so before assembly, it makes the job easier.
Be careful not to cover up guide marks on top of headers

WORK AREA

Select an area close to where the arbor will be finally placed. While the assembled unit is not very heavy, it is
awkward to move far and requires two people to do so easily.
The assembly area should be relatively flat and open, at least 8'x6'. A lawn, driveway or wide path will be satis-
factory.
A S S E M B LY I N S T R U C T I O N S
Longevity Arbor
4
3
2
1 0
1
