PLEASE READ COMPLETELY BEFORE YOU BEGIN ASSEMBLING
HARDWARE LIST
A
PARTS LIST
Base assembly (2)
Braces (4)
IMPORTANT: The side panel width will determine the location of the braces. For 17½" width
arbors (Rosedale, Astoria, Nantucket and the Longevity) attach inside arbor base assembly arms.
Refer to STEP 2A. For 24" width arbors (Victoria, Glendale, and the Casablanca) attach outside
arbor base assembly arms. Refer to STEP 2B for .
STEP 1
Attach 2 braces to each base assembly. Braces
may go on outside of arms depending on Arbor
width.
820.3163
Arbor Base
Division of LWO Corp. / P.O. Box 17125 / 3841 North Columbia Boulevard / Portland, Oregon
IDLE WI LD COLLECT ION
ASSEMBLY INSTRUCTIONS
2½" Wood screws (16)
A
503-286-5372 / fax 1-503-286-4092 / www.arboria.com
ARBOR BASE
Assembled arbor base with planters
STEP 2A
Attach braces to inside of arbor base assembly,
then to arbor frame.
1 of 2
A
A
updated
09/09/2005
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arboria Arbor Base
Summary of Contents for Arboria Arbor Base
- Page 1 IMPORTANT: The side panel width will determine the location of the braces. For 17½” width arbors (Rosedale, Astoria, Nantucket and the Longevity) attach inside arbor base assembly arms. Refer to STEP 2A. For 24” width arbors (Victoria, Glendale, and the Casablanca) attach outside arbor base assembly arms.
- Page 2 STEP 2B Attach braces to the outside of arbor base assembly, then to arbor frame. 820.3163 Arbor Base Division of LWO Corp. / P.O. Box 17125 / 3841 North Columbia Boulevard / Portland, Oregon STEP 3 Place large planters (minimum of 40 lbs. per side recommended) on both sides of the arbor.
