- Page 1 Installation and Operation Manual DVD-401-01-x Dual Digital Video Disc Player Document # 540254 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540254, Rev IR, 10/2002...
-
Page 3: Table Of Contents
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Table of Contents Section Description Page General Information……………………………………………… Introduction…………………………………………………………. Purpose of the Equipment………………………………………… Operational Features……………………………………………… Optional Equipment……………………………………………….. Technical Specifications………………………………………….. Application………………………………………………………….. Video/Audio Disc Care……………………………………………. Installation……..………………………………………………… Prior to Installation…………………………………………………. Unpacking and Inspection………………………………………… Cautions & Warnings………………………………………………... -
Page 4: I General Information
Audio CD, CD-R, CD-RW, VCD, MP3, DVD-ROM, and DVD Audio. The DVD-401-01-x can be mounted in a cabinet or bulkhead. A unique strapping feature allows up to four (4) similar devices to be used in the same system at the same time for a total of eight (8) selectable players, while maintaining independent control. -
Page 5: Operational Features
Digital audio fiber optic output capability Optional Equipment The DVD-401-01-x can be optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 6: Application
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Application Introduction The DVD-401-01-x operates between +18 and +32 VDC with a power consumption of less than 1A at +28 VDC. In addition, the DVD-401-01-x is capable of withstanding power interruptions in duration of 200 msec or less. -
Page 7: Video/Audio Disc Care
(i.e. entertainment control panels). The panels are on AI’s proprietary RS-485 digital data bus system and configured to control the operational features of the DVD-401-01-x. Video/Audio Disc Care When playing a disc for the first time, ensure that there are no burrs stuck in the center hole of the disc. -
Page 8: Installation
• Length of cable runs • Location of other aircraft systems (oxygen delivery) The DVD-401-01-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 9: Cautions & Warnings
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Cautions & Warnings It is important to do a pin-to-pin power and ground check on all connectors. Ensure that power and ground are applied only where specified. Damage to the unit may result if power or ground is applied to the wrong points. -
Page 10: Wiring Requirements
M17/94-RG179 or equivalent. AI’s Proprietary RS-485 Data Bus 4.4.1 The DVD-401-01-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair... -
Page 11: Physical Characteristics
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Digital Audio Lines All digital audio cabling shall be 100/140 µm (core/cladding) multi-mode fiber optic cabling. All fiber optic connectors/couplers shall use ceramic ferrules to minimize adverse reflection effects. BRAND-REX P/N: OC-1011 or equivalent fiber optic cabling is recommended for use for all digital audio cabling. - Page 12 Audio International, Inc. DVD-401-01-x Installation & Operation Manual The DVD-401-01-x utilizes two (2) 15-pin connectors for electrical connections. These connectors provide power, data bus control, infrared input, and three (3) infrared strapping pins for alternate configuration of infrared digital command codes, respectively.
-
Page 13: Post-Installation Test
Load DVD1 with a disc. If the disc does not start playing automatically, then use the DVD-401-01-x front panel controls or the handheld remote control unit to select PLAY. Verify a picture can be viewed on the appropriate monitor and that the audio can be heard through the speaker/headphone system. -
Page 14: Troubleshooting Guide
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Troubleshooting General Troubleshooting Procedures Many problems can be isolated with the following general techniques: • Verify +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. - Page 15 Audio International, Inc. DVD-401-01-x Installation & Operation Manual Troubleshooting Chart Problem Possible Cause Solution ½ Unit is improperly • No sound / No picture Verify +28 VDC power and video installed input is present ½ No disc in source unit.
-
Page 16: Reference Drawings
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-401-01-x. Document # 540254, Rev IR, 10/2002 Page 15 of 18... -
Page 17: Operation
SECTION III – OPERATION General Information The DVD-401-01-x can be operated via front panel buttons or optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 18: Front Panel Controls
FRONT PANEL CONTROLS ILLUSTRATION OF DVD-401-01-x FRONT PANEL The names and functions of the DVD-401-01-x are as follows: Eject button – Press to eject a disc from the disc tray or to load a disc. Play button – From Main Menu, pressing PLAY selects the highlighted choice. -
Page 19: Basic Playback
Audio International, Inc. DVD-401-01-x Installation & Operation Manual Basic Playback To play a disc, press the EJECT button on the front panel. Gently pull out the disc tray. Place the desired disc on the disc tray with the playback side down. Ensure that the disc is placed on the center snap and clicks into position.
