Summary of Contents for Audio international SCD-012-01-x
- Page 1 Installation and Operation Manual SCD-012-01-x Single Compact Disc Player Document # 540106 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540106, Rev B, 06/2001...
-
Page 3: Table Of Contents
Audio International, Inc. SCD-012-01-x Installation & Operation Manual Table of Contents Section Description Page General Information………………………………………….. Introduction……………………………………………………... Purpose of the Equipment……………………………………. Operational Features………………………………………….. Optional Equipment……………………………………………. Technical Specifications………………………………………. Application……………………………………………………… CD Player Care………………………………………………… Handling Compact Discs……………………………………… Installation…….………………………………………………. Prior to Installation…………………………………………….. Unpacking and Inspection…………………………………….. - Page 4 Audio International, Inc. SCD-012-01-x Installation & Operation Manual SCD-012-01-x Single Compact Disc Player Document # 540106, Rev B, 06/2001 Page 3 of 16...
-
Page 5: General Information
20Hz to 20kHz (±1 db). A removable cover bezel allows customization of the unit to other décor. The SCD-012-01-x can be mounted in a cabinet or bulkhead. A unique strapping feature allows up to four (4) similar devices to be used in the same system at the same time while maintaining independent control. -
Page 6: Optional Equipment
SCD-012-01-x Installation & Operation Manual Optional Equipment The SCD-012-01-x can be optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 7: Document # 540106, Rev B
Audio International, Inc. SCD-012-01-x Installation & Operation Manual Typical Application 6.2.1 This system is fully compatible with Audio International’s proprietary RS-485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RC1-17xxxx and IFR-485. -
Page 8: Cd Player Care
Audio International, Inc. SCD-012-01-x Installation & Operation Manual CD Player Care Cleaning the CD Player • If the front panel gets dirty, turn off the power and wipe the panel with a dry silicon cloth or soft cloth. • As dust tends to accumulate in the CD slot, clean it every once in a while. -
Page 9: Installation
• Access for service repair (if applicable) • Convenience for user interface (if applicable) The SCD-012-01-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 10: Cautions & Warnings
International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 11: Wiring Requirements
AI’s Proprietary RS-485 Data Bus 4.3.1 The SCD-012-01-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with the standard military specification of MIL-DTL-27500 or equivalent. -
Page 12: Electrical Characteristics
+5 VDC, Digital Logic Level Data Bus Type AI Proprietary RS-485 The SCD-012-01-x utilizes one (1) 15-pin connector for electrical connections. This connector provides power, left/right audio output, data bus control, infrared input, and four infrared strapping pins for alternate configuration of infrared digital command codes. -
Page 13: Post-Installation Test
Audio International, Inc. SCD-012-01-x Installation & Operation Manual Pinout Assignment and Descriptions Pin # Description + 28 VDC Power Power Ground R+ Audio Output R- Audio Output L+ Audio Output L- Audio Output Data Bus (A) Data Bus (B) Infrared Input +... - Page 14 Audio International, Inc. SCD-012-01-x Installation & Operation Manual Troubleshooting Chart Problem Possible Cause Solution • # SCD-012-01-x is No sound Verify +28 VDC power and audio improperly input is present installed • Insert audio material in source # No audio material...
-
Page 15: Reference Drawings
Audio International, Inc. SCD-012-01-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the SCD-012-01-x. Document # 540106, Rev B, 06/2001 Page 14 of 16... -
Page 16: Operation
ILLUSTRATION OF SCD-012-01-x FRONT PANEL To Load a CD into the CD Slot Insert a CD into the CD slot. The SCD-012-01-x will gently ‘pull’ the CD into the PLAY position. Power turns on automatically when the CD is inserted into the CD slot. -
Page 17: Operating Instructions
Audio International, Inc. SCD-012-01-x Installation & Operation Manual Operating Instructions Button – Press the (Stop/Eject) button to stop CD playback. Press the button a second time to eject the CD from the CD slot. Button - Press the (play/pause) button to play a CD. Press the button a second time to pause the CD in playback.
