RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNINGS
•
Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. Severe burns may result.
•
Carefully supervise children in the
same room as appliance.
Listed to standards:
ULC-S610 & UL-127
Report No. 192-5166
INSTALLATION AND

OPERATION INSTRUCTIONS

43" Wood Burning Fireplaces
P/N 850,027M REV. F 01/2008
MODEL
ME43BK SP
This installation manual will enable you to obtain a safe, efficient and
dependable installation of your fireplace system. Please read and
understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circum-
stances. Any modification or alteration of the fireplace system, including
but not limited to the fireplace, chimney components and accessories,
may void the warranty, listings and approvals of this system and could
result in an unsafe and potentially dangerous installation.
Lennox™ wood-burning fireplaces are designed for use as a supple-
mental heater. They are not intended for continuous use as a primary
heat source.
•
The fireplace cannot be operated without a door.
Consult your dealer to select the correct door
model.
•
Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
•
Install the fireplace only as described in these
instructions.
PIME43-F REV. 3
ME43
WARNINGS
