Meiligao GT30X User Manual

Gps tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Updated on 04/01/2009
GPS
Tracker
USER MANUAL
V5.0
GT30X
MEILIGAO GPS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT30X and is the answer not in the manual?

Questions and answers

Related Manuals for Meiligao GT30X

Summary of Contents for Meiligao GT30X

  • Page 1 MEILIGAO GPS Tracker USER MANUAL V5.0 GT30X Updated on 04/01/2009...

  • Page 2: Table Of Contents

    5.1.2 Set Interval for automatic timed report 5.1.3 Stop automatic timed report 5.1.4 SOS/Call B/Call C 5.2 GPRS Setting by SMS 5.2.1 Set ID for GT30X 5.2.2 Set APN 5.2.3 Set IP Address and Port 5.2.4 Set Time Interval for Sending GPRS Packet 5.2.5 Enable GPRS Tracking Function...

  • Page 3: Product Overview

    Read these simple guidelines. Not following them may be dangerous or illegal. Read the full user manual for more information. Switch on Safely - Do not switch on GT30X when wireless phone use is prohibited or when it may cause interference or danger.

  • Page 4: Getting Started

    - User Manual - Other document or software if required 4.2 Light and Button Functionality Your GT30X has four buttons and three LED lights with three different colors to indicate the status of the unit. Red LED - indicating power status Power is off or charging is complete Flashing (every 0.1 second)

  • Page 5: First Use

    GPS when you turn on the device. Check that the Red LED (power) on GT30X is flashing (on for 1 second and off for 2 seconds). Check that the Green LED (GSM) is flashing (on for 0.1 second and off for 2.9 seconds).

  • Page 6: Sms Command

    5.1 Basic SMS Commands 5.1.1 Return the location of the tracker Description: To know the location of your GT30X, send an SMS or make a telephone call directly to GT30X and it will report its location by SMS. Command: W<password>,<000>...

  • Page 7: Sos/Call B/Call C

    SMS sent: W000000,003,3,1,123456789 SMS received: Set Tel Ok/3,1,123456789 Meaning: When the SOS button is pressed, GT30X will send an SMS to telephone number “123456789” and also make a phone call to it. When a call is coming in, the green light is on. Press SOS button to receive the incoming call and then talk with the caller by earphone.

  • Page 8: Set Ip Address And Port

    MEILIGAO GPS Note: If no APN name and password required, input APN only. Example: W000000,011,CMNET GT30X will reply with an SMS (like ‘Set APN Ok/CMNET’) to confirm this setting. 5.2.3 Set IP Address and Port Command: W<password>,012,IP,PORT Example: W000000,012,202.116.11.12,8000 GT30X will then reply with an SMS (‘Set IP Ok/202.116.11.12,8000’) to confirm this setting.

  • Page 9: Troubleshooting

    MEILIGAO GPS Input the latitude and longitude that you receive from the tracker by SMS and click the search button. Google Earth will display the location for you. Example: When you receive: Latitude = 22 32 40.05N Longitude = 114 04 57.74E Type as the following picture shows: (Note: you should input the latitude and longitude as: 22 32 40.05N 114 04 57.74E)
  • Page 10 Wrong password in your SMS or wrong SMS format Write correct password or SMS format The SIM in GT30X has run out of credit Replace or top up the SIM card Problem: Green LED is Flashing (on for 1 second and off for 2 seconds)

  • Page 11: Sms Command List

    Remarks: ****** is user’s password and the default password is 000000. Description Command Remarks Get current location W******,000 Get current location of GT30X Change user’s password W******,001,###### ****** is old password ###### is new password Set interval for automatic W******,002,XXX XXX is the interval in minute.
  • Page 12 4 - 5 rings. D=0, Turn off the function of sending an SMS when GT30X is turned on. D=1, Turn on the function of sending an SMS to SOS number when GT30X is turned on. E=0, reserved E=1, GT30X shuts down automatically when the power voltage lower than 3V.
  • Page 13 GSM enters Example: standby mode stop If XX=10, GT30X will enter power sending out message until it saving mode after it is immobile for 10 is activated by an SMS or an minutes. incoming call)
  • Page 14 MEILIGAO GPS time difference in minute directly. For example, W000000,032,120 ‘-‘is required for those behind GMT. For example, W000000,032,-120. Set character for SOS alert W******,033,P,Char P is the button number. message P=1, SOS button P=2, Call B P=3, Call C.
