- Page 1 Personal Tracker User Manual V6.1 GT30...
-
Page 2: Table Of Contents
Contents 1.Product Overview ........................ - 3 - 2.For Your Safety ........................- 3 - 3.GT30 Characteristics ......................- 4 - 4.Getting Started ........................- 4 - 4.1 Hardware and Accessories ................... - 4 - 4.2 View ......................... - 5 - 4.3 Functional Parts ...................... -
Page 3: Product Overview
The GT30 is a GPS/GPRS based personal tracking device, which is compact and easy to use. GT30 has inbuilt GPS module to obtain accurate position data and utilizes its GSM capability to send the position data to a specified mobile phone or server base to allow users to monitor people or pets using the tracker. -
Page 4: Gt30 Characteristics
3 LED lights to show power, GPS, GSM and other status. Button 3 buttons(SOS/B/C) for making phone calls and sending SMS 4.Getting Started This section will describe how to set up your GT30. 4.1 Hardware and Accessories GT30 is supplied in a box which includes: - 4 -... -
Page 5: View
Side View Back View 4.3 Functional Parts Your GT30 has four buttons and three LEDs with three different colors to indicate the status of the unit. Red LED - indicating battery status Power is off or charging is complete Flashing (every 0.1 second) -
Page 6: First Use
- Check that the SIM Lock code is turned off - If you require the function of sending an SMS location report to the authorized phone number when it makes a call to the GT30, please make sure the SIM installed supports displaying caller ID. -
Page 7: Change Password
Check that the Red LED (Battery) is flashing 1 second on and 2 seconds off. Check that the Green LED (GSM) is flashing 0.1 second on and 2.9 seconds off. Check that the Blue LED (GPS) is flashing 0.1 second on and for 2.9 seconds off. -
Page 8: Track By Calling
Description: Get the current location of the tracker, send this SMS or make a telephone call directly to the tracker and it will report its longitude and latitude by SMS with format as follows:- Latitude = 22 32 36.63N Longitude = 114 04 57.37E, Speed = 2.6854Km/h, 2008-12-24,01:50 Example: W000000,000 - Track on Demand - Reply with a Google link... -
Page 9: Track By Ms01
Input the latitude and longitude that you receive from the tracker by SMS and click the search button. Google Earth or Google Maps will display the location for you. Example: When you receive: Latitude = 22 32 40.05N Longitude = 114 04 57.74E Type as the following picture shows: (Note: you should input the latitude and longitude as: 22 32 40.05N 114 04 57.74E) And then you can find the location of your tracker:... -
Page 10: Set Apn
Note: GPRS ID must not over 14 digits. Example: W000000,010,00001 7.6.2 Set APN Command: W******,011,APN,Username,Password Description: Set APN details for the tracker Note: 1. APN username and password are optional. If no APN username and password are required, just input APN only;... -
Page 11: Set Gprs Interval
The tracker will send every 600 seconds (10 minutes). For more information regarding GPRS tracking please refer to <GPRS Communication Protocol> 7.7 Track by GpsGate The GT30 supports GpsGate Software. Please contact us or GpsGate for more information of settings. 8. Authorization... -
Page 12: Receiving Phone Call
9.1 Receiving Phone Call Use your phone or mobile phone to call the tracker, the green LED will be on. Press SOS button to receive the incoming call or press Call B button to reject the call. 9.2 Making Phone Call After you have authorized phone numbers for SOS/Call B/Call C button, you can press one of these buttons to make a call to the preset phone number. -
Page 13: Movement Alarm
12.1 Movement Alarm Command: W******,006,XX Description: When the tracker moves out of a preset square scope, it will send an SMS alarm to the authorized phone number for SOS. Note: XX is the preset distance to the tracker’s original place =00, to turn off this function =01, 30m =02, 50m... -
Page 14: Initialization
Description: Makes the tracker into power down mode when it is inactive for a period of time. In Power Down states, GPS stops working and GSM enters sleep and stop sending out message until it is activated by message, incoming calls or triggered by buttons. Note: XX=00, to turn off this function. -
Page 15: Annex 1. Sms Command List
Annex 1. SMS Command List Note: ****** is user’s password and the default password is 000000. The tracker will only accept commands from a user with the correct password. Commands with wrong password will be ignored. Description SMS Command Example Track on Demand W******,000 W000000,000... - Page 16 =0 , to turn off this function =1, <3.3V =2 , <3.4V =3 , <3.5V (default) =4 , <3.6V =5 , <3.7V Speeding Alarm W******,005,XX W000000,005,08 Remarks: When the tracker speeds higher than the preset value, it will send an SMS to the authorized phone number for SOS. XX is the preset value of speed and in 2 digits.
- Page 17 C=0, turn off the function to automatically hang up an incoming call. C=1, turn on the function to automatically hang up an incoming call after 4 - 5 rings. D=0, turn off the function of sending an SMS when the tracker is turned on. D=1, turn on the function of sending an SMS to the authorized phone number for SOS button when the tracker is turned on.
- Page 18 XXXXX should be in five digits and in unit of 10 seconds. XXXXX=00000, to turn off this function; XXXXX=00001~65535, time interval for sending GPRS packet and in unit of 10 seconds. In this example, the tracker will send every 600 seconds (10 minutes). For more information regarding GPRS tracking please refer to <GPRS Communication Protocol>...
-
Page 19: Annex 2. Troubleshooting
Problem: Unit will not reply with SMS Possible Cause: Resolution: Green LED is flashing (1 second on and 2 Make GT30 connected to GSM network. seconds off) GSM Network is slow Some GSM networks slow down during peak time or when they have equipment problems. -
Page 20: Contacts
GPRS function of GT30 is turned off Turn on GPRS function of GT30. Incorrect IP address or Port Get the right IP address and Port and reset to GT30. GSM signal is weak Move the unit to a location with good GSM reception.
