- Page 1 MEILIGAO GPS Vehicle Tracker USER MANUAL V5.0 VT300 Updated on 26/12/2008...
-
Page 2: Table Of Contents
5.1.1 Position Report 5.1.2 Set Interval for Automatic Timed Report 5.1.3 Stop Automatic Timed Report 5.2 GPRS Settings by SMS 5.2.1 Set ID for VT300 5.2.2 Set APN 5.2.3 Set IP Address and Port 5.2.4 Set Time Interval for Sending GPRS Packet 5.2.5 Enable GPRS Tracking Function... -
Page 3: Product Overview
Safe Driving - Drivers should not operate this product while driving. Qualified Service - Only qualified personnel can install or repair VT300. Water Resistance - VT300 is not water resistant. Keep it dry. Install it inside the vehicle or use waterproof bag if necessary. -
Page 4: Getting Started
Flashing (on for 1 second and off for 2 seconds) SOS Button Press it to send SMS alert 4.3 Connecting and Installation Read this manual before using your VT300 and check if all parts are included in the packaging box. - 4 -... - Page 5 - If you require the function of sending an SMS location report to the authorized phone number when it makes a call to the VT300, please make sure the SIM installed supports displaying caller ID. Before inserting SIM card, cut off the power for the AVL unit.
- Page 6 MEILIGAO GPS Descriptions of PINs: Color Function DC In (power input). Input voltage: 9V~35V. 12V suggested. Black White Input Blue Output Yellow SW1: Connect with power switch Yellow SW2: Connect with power switch An example of Input and Output application:...
-
Page 7: Sms Command
The default password is 000000. 5.1 Basic SMS Commands 5.1.1 Position Report Description: To know the location of your VT300, send an SMS or make a telephone call directly to VT300 and it will report its location by SMS. Command: W<password>,<000>... -
Page 8: Set Id For Vt300
Command: W<password>,010,ID Note: Tracker ID must not over 14 digits. Example: W000000,010,123456789 VT300 will then reply with an SMS (‘Set SIM Ok/123456789’) to confirm this setting. 5.2.2 Set APN by SMS Command: W<password>,011,APN,APN Name,APN Password Note: If no APN name and password required, input APN only. - Page 9 MEILIGAO GPS Input the latitude and longitude that you receive from the tracker by SMS and click the search button. Google Earth will display the location for you. Example: When you receive: Latitude = 22 32 40.05N Longitude = 114 04 57.74E Type as the following picture shows: (Note: you should input the latitude and longitude as: 22 32 40.05N 114 04 57.74E)
-
Page 10: Troubleshooting
Cancel sleeping mode Wrong password in your SMS or wrong SMS format Write correct password or SMS format The SIM in VT300 has run out of credit Replace or top up the SIM card No SIM card Insert a working SIM card. Check in phone that the SIM can send SMS message. -
Page 11: Sms Command List
Unit does not have clear view of the sky Move the antenna of the unit to a location where the sky is visible. VT300 is in an inner place Wait for the target to come out Battery is low Recharge the unit and the GPS will start working. - Page 12 4 - 5 rings. D=0, Turn off the function of sending an SMS when VT300 is turned on. D=1, Turn on the function of sending an SMS to SOS number when VT300 is turned on. E=0, reserved E=1, VT300 shuts down automatically when the power voltage lower than 3V.
- Page 13 MEILIGAO GPS Presetting by SMS for GPRS tracking (Ensure that your SIM card supports GPRS connection prior to setting) Set ID for VT300 W******,010,ID Tracker ID must not over 14 digits. Set APN W******,011,APN,APN Name, name password Password required, just insert APN only;...
