Summary of Contents for MK MK-1280
-
Page 1: Part List
MK-1280 ELECTRIC SERIES BRICK/PAVER SAW OWNERS MANUAL & PART LIST Revision 100 10.2010 Manual Part No. 168786 Caution: Read all safety and operating instructions before using this equipment. This owners manual MUST accompany the equipment at all times. -
Page 2: Exploded View
MK-1280 ELECTRIC SAW EXPLODED VIEW FIGURE 1 - MK-1280 PAVER SAW - P/N 167492... -
Page 3: Parts List
156837 SCREW, 5/16 - 18 X 3/8 SOCKET HEAD SET 157084 WASHER, SQR, 7/16 X 1 - 1/4 X 3/16 157567 BLADE, MK-414PBSL 16 X 125 X 1 160765 BELT GUARD, OUTER, ARBOR, COMP 160888 PULLEY, 10J28 X 5/8 BORE... - Page 4 MK-1280 ELECTRIC SAW EXPLODED VIEW FIGURE 2 - MK-1280 PAVER SAW - P/N 166561...
- Page 5 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 2 - MK-1280 PAVER SAW - P/N 166561 ITEM DESCRIPTION PART# OWNERS MANUAL, MK-1280 168786 ASSY, ARBOR, ELEC 1280 168712 GUARD, BELT, INNER 168713 MOUNT, MOTOR, ELEC 1280 168714 MTR, 2HP 115/230V 60 HZ...
- Page 6 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 3 - ASSY, TABLE - P/N 166577 ITEM DESCRIPTION PART# WHEEL, CONVEYOR CART 133090 SCREW, HEX HD, 1/4 - 20 X 3/4 152370 NUT, HEX W/WSHR, 1/4 - 20 153941 NUT, HEX, TW, 5/16 - 18...
- Page 7 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 4 - ASSY, ARBOR - P/N 166579 ITEM DESCRIPTION PART# KEY, 3/16 SQ X 1 - 1/8 150344 BEARING, ARBOR HOUSING 154594 CASTING, 2000/5000 ARBPR - COMP 154637 SCREW, 5/16 - 18 X 3/8 SOCKET HEAD SET...
- Page 8 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 5 - ASSY, 16” BLADE GUARD - P/N 166581 ITEM DESCRIPTION PART# ELBOW, 1/4 MNPT STREET 154615 FITTING, 1/4 MNPT X 3/8 BARB 154659 SCREW, HEX HEAD 3/8 - 16 X 1 - 1/2 LG.
- Page 9 MK-1280 ELECTRIC SAW PARTS LIST FIGURE 6 - ASSY, CART - P/N 167437 ITEM DESCRIPTION PART# NUT, 3/8 - 16 HEX 101188 WASHER, FLAT, USS, 3/8 101360 WASHER, 3/8 SPLIT LOCK 150925 NUT, 3/8 - 16 NYLOK HEX 152505 SCREW, 3/8 - 16 X 2-1/4 HEX HEAD...
- Page 10 NOTES...
-
Page 11: Ordering Information
ORDERING & RETURN INSTRUCTIONS ORDERING INFORMATION You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. NOTE: There is a $25.00 minimum order when ordering direct from MK Diamond. All purchases must be made using VISA, MasterCard or American Express. - Page 12 MK-1280 ELECTRIC SAW SERIES OWNERS MANUAL & PART LIST MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 845-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.mkdiamond.com...
