Sharp 21JF2-GA Service Manual

Sharp 21JF2-GA Service Manual

Colour television
Hide thumbs Also See for 21JF2-GA:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and
only parts identical to those specified should be used.
Multi 18 Systems
Full Auto Channel Preset and Auto Channel Skip
100-CH Program Memory
CATV (Hyper Band) Ready
<Used Frequency Synthesizer Tuner>
Black Stretch Circuit
On Timer / Off Timer / Reminder Timer
Blue Back Function
[1]
SPECIFICATIONS ................................. . ....... 1-1
[1]
IMPORTANT SERVICE NOTES ............ . ....... 2-1
[1]
ADJUSTMENT PRECAUTIONS ............ . ....... 3-1
[2]
ADJUSTMENT ....................................... . ..... 3-14
CHAPTER 4. MEMORY MAP
[1]
MEMORY MAP ...................................... . ....... 4-1
[1]
TROUBLE SHOOTING FLOWCHART .. . ....... 5-1
GRAM
[1]
[1]
CHASSIS LAYOUT ................................ . ....... 7-1
[1]
BLOCK DIAGRAM: CRT UNIT .............. . ....... 8-1
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power receptacle, when servicing
this chassis. To prevent electric shock, do not remove cover. No user - serviceable parts inside. Refer servicing to qualified service personnel.

SERVICE MANUAL

FEATURES
Front AV IN & Rear AV IN / OUT Terminals
Front Headphone Jack
Aperture Control Circuit
Auto Fine Tuning
NTSC Colour Comb Filter (AV THRU)
High Contrast Picture
Hotel Mode
White Temperature Select
CONTENTS
WARNING

SHARP CORPORATION

COLOUR TELEVISION
Chassis No. GA-4M
MODELS
Multi Languages OSD
(ENG / CHI / FRE / MAL / ARA / RUS)
for Model 21JF2-SF / SS Only.
(ENG / CHI / FRE / MAL / ARA)
for Model 21JF2-GA / SA Only.
(ENG / RUS)
for Model 21JF2-RU Only.
MONO
[2]
[3]
BLOCK DIAGRAM: MAIN UNIT ....................8-2
GRAM
[1]
GRAM............................................................9-1
[1]
WAVEFORMS .............................................10-1
[1]
[2]
[3]
UNIT ............................................................ 11-7
BLIES
[1]
PWB-B: CRT UNIT ......................................12-1
[2]
PWB-C: HEADPHONE UNIT ......................12-1
[3]
PWB-A: MAIN UNIT ....................................12-2
21JF2-RU/GA/SA/SF/SS
No. S95O521JF2-RU
21JF2-RU
21JF2-GA
21JF2-SA
21JF2-SF
21JF2-SS
