Rustibus 400 AIR 040-3000 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERAtiON MANuAL
040-3000
Rustibus® 400 AiR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 400 AIR 040-3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Rustibus 400 AIR 040-3000

Summary of Contents for Rustibus 400 AIR 040-3000

  • Page 1 OPERAtiON MANuAL 040-3000 Rustibus® 400 AiR...

  • Page 2: Declaration Of Conformity

    Machine may vary from pictures Genuine Rustibus® parts only! DECLARAtiON OF CONFORMitY DECLARAtiON OF CONFORMitY Manufacturer: Manufacturer: Dalseide shipping services As Dalseide shipping services As bekkjarviksundet 1 bekkjarviksundet 1 N-5397 bEKKJARViK N-5397 bEKKJARViK NORWAY NORWAY The authorised representative The authorised representative...
  • Page 3 If they are not there, they’re not GENUINE PARTS. Use only the best, don’t settle for less. RUSTIBUS® If they are not there, they´re not genuine spares. Use only the best, don´t settle for less.
  • Page 4 Machine may vary from pictures Genuine Rustibus® parts only! HELPFuL iDENtiFiERs in addition to information on installation and operation, this instruction manual may contain WARNiNGs and CAutiONs pertaining to user safety, and NOtEs on important, useful operating guidelines. A WARNiNG indicates a potentially hazardous situation, which if not avoided, could result in death or serious injury.
  • Page 5 Never operate the Rustibus® de-scaling tool while wearing loose hanging chains, hanging iD/security badges or garments that may be caught in the rotating parts. Never start the Rustibus® de-scaling machine before it´s cables or hoses are properly secured and safely located.

  • Page 6: Safety Considerations

    • ALWAYS THINK SAFETY FIRST WHEN oPERATINg MAcHINE. bEFORE stARtiNG tHE OPERAtiON Congratulations on your new Rustibus® de-scaling machine. in order to ensure your full benefit and safety of operation we recommend you to read this operation manual carefully before starting.

  • Page 7: Installation And Setup

    • Start and Stop the machine and check that rotation is correct according to marking on machine. Step 4: oPERATIoN oF RUSTIBUS® MAcHINE. • For the best results from your Rustibus® machine you should run the machine forward and backward over the area until appropriate result is achieved •...
  • Page 8 Genuine Rustibus® parts only! FiLLiNG tHE LubRiCAtOR the Rustibus® machines are simple to use and simple to operate. When being well maintained a machine can be of operational standard for many years. FiLLiNG tHE stANDARD OiL-Mist LubRiCAtOR Lbs WitH OiL Fig1.
  • Page 9 When the Rustibus® 400 Air is stowed away after use, it should be filled with 0,1 litres of lube oil to ensure functionality upon next time of use. Fill the oil into the t-pipe (040-4021) by removing the cap (040-4020).
  • Page 10 Machine may vary from pictures AiR QuALitY, LubRiCtiON AND FiLtRAtiON THE RUSTIBUS TooL/MAcHINE cAN oPERATE IRRISPEcTIVE oF cLIMATIc coNDITIoNS. PRoVIDED THE AIR SUPPLIED To oPERATE THE TooL/MAcHINE IS oF A SUITABLE QUALITY To Do So. Ensure that your machine is always run with air that is properly filtered for moisture and particles and to a quality that is suitable for use with pneumatic motors of its type.
  • Page 11 Genuine Rustibus® parts only! Machine may vary from pictures AiR HOsE CONNECtiONs On all Air Hose Connections there are holes to allow you to attach a safety pin through both sections. Holes for Safety pin Safety pin ! HIgHLY REcoMMENDED...
  • Page 12 (2). the entire handle can be adjusted to fit various positions (3), depending on users requirements for comfort or operation area. the Rustibus® 400 unit uses a Disposable Chain Drum. this Chain Drum is designed for one-time-use only and does not require any spares replacement.
  • Page 13 Genuine Rustibus® parts only! sEt uP Your Rustibus®400 machine is fitted with a protective cover. this cover offers the operator greater protection; decreases the spreading of waste and debris and increases the efficiency of the vacuum system when used on the machine.
  • Page 14 Genuine Rustibus® parts only! Machine may vary from pictures REPLACiNG tHE CHAiN DRuM to use the Disposable Chain Drums, an adapter is required (040-0157). this is mounted on the shaft of the electro motor. When replacing Chain Drums (040-0156) check and tighten bolts on adaptor first and put the chain drum on.
  • Page 15 Machine may vary from pictures Genuine Rustibus® parts only! sPARE PARt List – Rustibus® 400 AiR 040-0012 040-0013 040-4009-1 040-4010-1 040-4016-1 040-0010 040-0014 040-0202 040-0158...
  • Page 16 Machine may vary from pictures Genuine Rustibus® parts only! sPARE PARt List – Rustibus® 400 AiR 040-4002 040-4012 040-4019 040-4018 040-4006 040-4019 040-4003 040-4017 040-4004 040-4016-1 040-4019 040-4006 040-4008 040-4019 040-4006 040-4008 040-4010-1 040-4007 040-4007 040-4009-1 040-4008 040-4008 040-4001 040-4020...
  • Page 17 Machine may vary from pictures Genuine Rustibus® parts only! sPARE PARt List – Rustibus® 400 AiR PARTS TO RUSTIBUS® 400 AIR UNIT 040-0010 CHASSIS 400 040-0012 PLASTIC COVERS FROM HANDLES 040-0013 HANDLE ASSEMBLy 040-0014 PROTECTIVE COVER ONLy 400 040-0015 HANDLE (UPPER SECTION)
  • Page 18 Machine may vary from pictures Genuine Rustibus® parts only! sPARE PARt List – Rustibus® 400 AiR 040-4140 BEARING, DRIVE END 040-4150 DOWEL PIN (4 PCS) 040-4160 END PLATE, DRIVE 040-4170 BODy GASKET ( 2 PCS) 040-4180 BODy 040-4190 040-4200 ROTOR ASSEMBLy...

  • Page 19: Additional Features

    PARts tO AiR MOtOR ADDitiONAL FEAtuREs RUSTIBUS® 400 VAcUUM SYSTEM the Rustibus® 400 machine features a newly modelled vacuum system attachment. it is built right into the very foundation of the machine itself. its vacuum port has been designed to be easy to use and not get in the way or hinder the operation of the machine.
  • Page 20 Machine may vary from pictures Genuine Rustibus® parts only! ScENARIoS PoTENTIAL SoLUTIoNS REASoNS spare part list – Rustibus® 2000-3000. Rustibus® machine - Dirt, foreign materials 1)Check that there are no restrictions on Does not run. - internal corrosion / rust the hose.
  • Page 21 50 M Cable 2X1,5 + E 040-3000 Rustibus® 400-Air, Complete W/Air filter-Lubricator & Regulator 040-X3000 Rustibus® X400 Air (EX), Complete W/Air filter-Lubricator & Regulator 040-5000 Rustibus® 400, Complete single Phase-110V – 60Hz incl. 50 M Cable 2X1,5 + E...
  • Page 22 Dalseide Shipping Services cannot be held liable for any damages (to Rustibus® machines or personnel) as a result of use of non genuine parts. We reserve the right to refuse any claims on parts or Rustibus® machinery unless it can be proven that genuine parts only have been used on Rustibus® machines.

  • Page 23: Contact Information

    Machine may vary from pictures Genuine Rustibus® parts only! CONtACt iNFORMAtiON NoRWAY: Dalseide Shipping Services AS Bekkjarviksundet 1 NO - 5397 Bekkjarvik Norway Tel: + 47 5618 1200 Fax: + 47 5618 1201 E-mail: bergen@rustibus.com ANTWERP: Rustibus N.V. Noordersingel 7...
