Summary of Contents for Belkin F5U022

  • Page 1: User Manual

    BusPort ™ Mobile MODEL F5U022 User Manual P73280...

  • Page 2: Table Of Contents

    Table of Contents Overview Belkin BusPort ™ Mobile Features ....4 System Requirements ......4 Package Contents .

  • Page 3: Overview

    4 Port Hub, you can daisy-chain up to 127 USB devices to your notebook or PowerBook . And because it is a Belkin product, you are assured ® that it is fully compliant with current USB specifications, meets the standard of USB OHCI specifications and comes with an unbeatable Lifetime Warranty.

  • Page 4: Belkin Busport ™ Mobile Features

    CardBus PC ® ® Card Type II slot • Windows 98 or Mac OS 8.6 or higher ® ® • Not for use with PowerBook G3 1999 ® PACKAGE CONTENTS • Belkin USB BusPort ™ Mobile • User Guide...

  • Page 5: Checking Cardbus Host Controller On A Pc

    Checking CardBus Host Controller on a PC Before you can connect the BusPort Mobile, you need to confirm ™ if your notebook supports CardBus PCMCIA. To confirm whether your CardBus host controller has been installed in your notebook and works properly use the following procedures: 1.

  • Page 6: Installation For Notebook Pcs Using Windows

    Checking CardBus Host Controller on a PC (cont.) 3. If for some reason your notebook does not have PC Card PCMCIA support, then refer to your notebook PC manual on how to install the proper drivers or contact your notebook computer manufacturer.
  • Page 7 Installation for Notebook PCs using Windows 98 (cont.) ® Step 2 The following screen will prompt you that the wizard searches for new drivers for the OPTi 82C861 PCI to USB Open Host Controller. Click ‘Next>’. Step 3 The next screen displays two options. Select ‘Search for the best driver for your device’.
  • Page 8 Installation for Notebook PCs using Windows ® 98 (cont.) Step 4 Windows ® will now prompt you for the location of the driver. Insert the Windows ® 98 CD on your CD-ROM drive. From the selection window, select “Specify a Location” then type E:\WIN98 (On this example E is the drive letter for CD-ROM, it may be different on your PC).
  • Page 9 Installation for Notebook PCs using Windows 98 (cont.) ® Step 6 The next screen prompt informs that Windows ® is ready to install the drivers for the BusPort ™ Mobile. Click “Next” to install the drivers. Step 7 The following prompt informs that Windows ®...

  • Page 10: 98 Second Edition

    Installation for Notebook PCs using Windows 98 (cont.) ® Step 8 Lastly, Windows ® displays the final dialog box. Click “Finish.” Windows will finish installing the OPTi 82C861 to USB Open Host Controller and the USB Root Hub. There will be no more prompts. Congratulations you now have 2 USB ports! Installation for Notebook PCs using Windows...
  • Page 11 Installation for Notebook PCs using Windows 98 Second Edition (cont.) ® Step 1 The first dialog box informs you that Windows ® 98 has detected new hardware, “PCI Universal Serial Bus.” Step 2 Immediately a screen like the one below should appear asking you to insert the Windows 98 Second Edition CD-ROM.
  • Page 12 Installation for Notebook PCs using Windows ® 98 Second Edition (cont.) Windows ® will finish installing the OPTi 82C861 to USB Open Host Controller and USB Root Hub. There will be no more prompts. Congratulations, you now have two USB ports. To confirm whether your computer has USB ports installed please use the following instructions: 1.
  • Page 13 Installation for Notebook PCs using Windows ® 98 Second Edition (cont.) 3. From the list of devices look for “Universal serial bus controller.” Click on the ‘Plus’ sign beside it. After it expands you should see “OPTi 82C861 PCI to USB Open Host Controller.” After verifying that you have the BusPort ™...

  • Page 14: Using Your Busport

    Using Your BusPort ™ Mobile on a Notebook PC Initializing new USB Devices As soon as you start connecting a USB device through any of the USB ports of the BusPort Mobile, Windows 98 automatically ™ ® detects the presence of new hardware. Windows ®...

  • Page 15: Troubleshooting On A Notebook Pc

    Troubleshooting on a Notebook PC Q: Why does Windows ® 98 not detect the BusPort Mobile? A: Normally, Windows 98 will automatically detect the BusPort ® ™ Mobile as a “PCI Universal Serial Bus” after inserting it in your notebook’s PCMCIA slot. If Windows ®...

  • Page 16: Installation Using Macintosh Powerbook

    Mobile on the PowerBook ’s ™ ® PCMCIA slot. An icon named USB will appear on your screen. 3. Connect the 7-inch dongle with two USB ports to the Belkin BusPort ™ Mobile. 4. Connect your USB device(s) (e.g. USB Mouse, USB Keyboard, USB Floppy Drive, etc.) to any of the USB ports of the 7-inch...

  • Page 17: Troubleshooting On A Mac

    Troubleshooting on a ® PowerBook ® Q: How do I make the BusPort Mobile work on my ™ PowerBook ® A: 1. First, make sure that your PowerBook is compatible ® with the BusPort ™ Mobile. Check the compatibility list provided in this manual.

  • Page 18: Compatibility List

    Compatibility List PC Laptop List Acer Extensa 390 series (391C, 391T, 392C, 392T, 393C, 393T, 394T, 395T) Acer Extensa 650 series Acer Extensa 670 Series (670CD, 671CDT) Acer Extensa 900 Series AST Ascentia A AST Ascentia M5000 Series AST Ascentia A60+ or A70/70+ AST Ascentia P80 Compaq Armada 1500 Series (1505DM, 1510DM, 1520DM, 1530DM, 1550DMT, 1560DM, 1571DM, 1573DM, 1580DMT,...
  • Page 19 Compatibility List (cont.) Compaq Presario 1600 Series (1610, 1620, 1621, 1622, 1670, 1672, 1680, 1681) Compaq Presario 1900 Series (1900, 1900T, 1920, 1925) Compaq Prosignia 160 Compaq Prosignia 165 Series Dell Inspiron 3000 Dell Inspiron 7000 Dell Latitude CP Dell Latitude CPi A Dell Latitude LT Dell Latitude XPi CD (P150) Digital HiNote Ultra 2000 MMX (VTX5166M, GTX 5166M)
  • Page 20 Compatibility List (cont.) Gateway Solo 9150 Hitachi VisionBook Pro 7300 Series (7340) Hitachi VisionBook Pro 7700 Series (7755) HP OmniBook 2000 Series HP OmniBook 2100 HP OmniBook 3000 HP OmniBook 3100 HP OmniBook 4100 HP OmniBook 4150 HP OmniBook 5700 HP OmniBook 7100 HP OmniBook 7150 HP OmniBook 800CT (w/MMX)
  • Page 21 Compatibility List (cont.) IBM ThinkPad 390E IBM ThinkPad 560X IBM ThinkPad 560Z IBM ThinkPad 600 IBM ThinkPad 760XL or 760XD IBM ThinkPad 765D or 765L IBM ThinkPad 770 IBM ThinkPad i 1700 Series (1700, 1721) Micron GoBook 2 Micron Millennium TransPort XKE Micron TransPort Trek 2 NEC Versa 5000 (5060, 5060X) NEC Versa 6000H, 6030H, or 6030X...
  • Page 22 Compatibility List (cont.) Note: The Toshiba Satellite Family will work on the BusPort ™ Mobile but you cannot disconnect and reconnect the card while your Notebook is “ON.” ® Laptop List PowerBook ® 100 series Duo (200 and 2300) 5300c and 500 series. PowerBook G3, 233, 250, 292 312, 314.

  • Page 23: Fcc Statement

    Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge, provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
  • Page 24 Fax: +44 (0) 1604678330 Belkin Components B.V. Diamantlaan 8 • 2132 WV Hoofddorp • The Netherlands Tel: +31 (0) 235698765 Fax: +31 (0) 235612694 © 2000 Belkin Components. All Rights Reserved. All Trade Names Are Registered Trademarks Of Respective Manufacturers Listed. P73280...
