NETWORK CAMERA

User Manual

SNP-6320/SNP-6320H

Advertisement

Table of Contents
loading

Related Manuals for Samsung SNP-6320

Summary of Contents for Samsung SNP-6320

  • Page 1: Network Camera

    NETWORK CAMERA User Manual SNP-6320/SNP-6320H...
  • Page 2 Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

  • Page 3: Important Safety Instructions

    overview important Safety inStructionS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

  • Page 4: Explanation Of Graphical Symbols

    overview warninG TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
  • Page 5 Battery Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. These servicing instructions are for use by qualified service personnel only.
  • Page 6 overview Please read the following recommend safety precautions carefully. y Do not place this apparatus on an uneven surface. y Do not place this apparatus near conductive material. y Do not attempt to service this apparatus yourself. y Do not install near any magnetic sources. y Do not block any ventilation openings.

  • Page 7: Table Of Contents

    Important Safety Instructions Product Features Recomended PC Specifications Recomended SD/Micro SD/ SDHC/SDXC Memory Card Specifications NAS recommended specs What’s Included At a Glance (SNP-6320) At a Glance (SNP-6320H) iNSTALLATioN & Connecting with other Device CoNNeCTioN Installation Inserting/Removing a SD/Micro SD Memory Card...

  • Page 8: Web Viewer

    overview web vieweR Connecting to the Camera Password setting Login Installing STW WebViewer Plugin Using the Live Screen Playing the recorded video SeTup SCReeN Setup Basic Setup Video & Audio setup Network Setup Event Setup NAS (Network Attached Storage) guide System Setup Viewing profile information AppeNDix...

  • Page 9: Product Features

    proDuct featureS • full HD video Quality • multi-Streaming This network camera can display videos in different resolutions and qualities simultaneously using different CODECs. • web Browser-based monitoring Using the Internet web browser to display the image in a local network environment. •...

  • Page 10: Recomended Pc Specifications

    overview recomenDeD pc SpecificationS • CPU : Intel Core 2 Duo 2.6 GHz or higher (for using 1920x1080 30 fps) Intel Core i7 2.8 GHz or higher (for using 1920x1080 60 fps) Web Plug-in is optimized to SSE 4.1 Instruction Set. •...

  • Page 11: Card Specifications

    • For the framerate over 31 fps, it is recommended to use the specification memory card of Class 10 UHS or higher. • The following models support the following SD cards: (SNP-6320 : Micro SD card, SNP-6320H : SD card) naS recommenDeD SpecS • Recommended capacity : 200GB or higher is recommended.

  • Page 12: What's Included

    Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Model Name Camera Instruction book, Installer S/W CD Quick Guide SNP-6320 or (Optional) SNP-6320H Warranty card (Optional) Used to test the camera Cable for the testing connection to a portable display monitor device...
  • Page 13 Appearance Item Name Quantity Description Model Name Template Product installation guide SNP-6320 Use when installing the camera Insulation Sheet at highly humid place Used for attaching the Hexagon screw installation base to the camera Used for fixing the installation L Wrench...

  • Page 14: At A Glance (Snp-6320)

    GLance (Snp-6320) appearance Item Description Protects the internal PTZ mechanism from the direct sunlight or external Main unit impact. Dome Cover Dome cover for the lens and unit protection. Pressing and holding this button for about 5 seconds will reset all camera Reset Button settings to the factory default.
  • Page 15 Bottom view of installation inner view of installation Base Base Item Description Alarm I/O Port Used to connect the alarm I/O cable. Video Out Port Analog video output port. (for installation) Audio Input Port Used to connect the audio input cable. Audio Output Port Used to connect the audio output cable.
  • Page 16 overview Item Description Communications Used for RS-485/422 communications. Ports ID Setup Switch Specify the camera ID. Communications Set the transfer rate and protocols. Setup Switch Network You can use a PoE+ or an Ethernet cable to connect this terminal to the Connections network.

  • Page 17: At A Glance (Snp-6320H)

    at a GLance (Snp-6320H) appearance Item Description Protects the internal PTZ mechanism from the direct sunlight, rain or Main unit external impact. Dome Cover Dome cover for the lens and unit protection. Safety Cable The cable prevents the product from dropping during installation. English _17...
  • Page 18 overview inside Item Description SD Memory Card Compartment for the SD memory card. Compartment Pressing and holding this button for about 5 seconds will reset all camera Reset Button settings to the factory default. After Service Port This is for the repair purpose only that is not available for the user. (A/S port) 18_ overview...
  • Page 19 Bottom view of installation inner view of installation Base Base Item Description Alarm I/O Port Used to connect the alarm I/O cable. Video Out Port Analog video output port. (for installation) Audio Input Port Used to connect the audio input cable. Audio Output Port Used to connect the audio output cable.
  • Page 20 overview Item Description Communications Used for RS-485/422 communications. Ports ID Setup Switch Specify the camera ID. Communications Set the transfer rate and protocols. Setup Switch Network You can use a PoE+ or an Ethernet cable to connect this terminal to the Connections network.

  • Page 21: Camera Wiring Interface Board

    ` camera wiring interface Board For the camera wiring, please refer to the picture below. Video Audio Audio Output Alarm Power Supply Alarm (SNP-6320 : AC 24V, 2.5A/ Input SNP-6320H : AC 24V, 3A) Power Input Ground Alarm output Communications ETHERNET TXD+ TXD- GND...

  • Page 22: Installation & Connection

    Check out the rated voltage and current before making connections. Rated Power Allowable Input Voltage Current Consumption (SNP-6320 : AC 24V, 2.5A/ AC 24V AC 22V ~ 26V SNP-6320H : AC 24V, 3A) If applied with both PoE+ and AC 24V power supplies, the device is powered from the first engaged supply.

  • Page 23: Ethernet Connection

    electrical resistance of copper wire at [20°c (68°f)] Copper Wire Gauge (AWG) #24(0.22mm ) #22(0.33mm ) #20(0.52mm ) #18(0.83mm Resistance (Ω/m) 0.078 0.050 0.030 0.018 Drop Voltage (V/m) 0.028 0.018 0.011 0.006 Recommended Distance (m) Less than 20 Less than 30 Less than 30 Less than 30 As shown in the table above, you may encounter a voltage-sag depending on the wire length.
  • Page 24 installation & connection Connecting the installation monitor Connect the cable to the camera’s rear video output terminal and the installation monitor’s video input terminal. AUDIO OUT AUDIO IN Monitor IN1 IN2 GND IN3 IN4 GND 1.COM 1.NO 1.NC 2.COM 2.NO 2.NC The wiring varies depending on your monitor type and peripheral devices;...

  • Page 25: Installation

    & installing camera Bracket For installation guidelines for brackets and housings, refer to the installation manual that is enclosed with the bracket or housing. ` available Bracket models Model Item SNP-6320 SNP-6320H SHP-3701H Outdoor Housing SHP-3701F Ceiling-mount Housing SBP-300HM3...
  • Page 26 installation & connection installing by surface attachment SNP-6320H cannot be installed on the surface of a wall or ceiling. ` attaching template & installing installation base 1. Attach the provided template on the ceiling. Based on the template, drill a 86mm hole in the ceiling and arrange the wires through the hole.
  • Page 27 ` connect terminal wires 1. Connect the cables to the terminal block on the hinged door. Refer to “camera wiring interface Board”. (page 21) 2. Once the wiring is complete, close the hinged door. Do not connect the camera to a power outlet until the installation is complete.
  • Page 28 installation & connection - To attach or detach the camera, refer to the picture. • Attaching the Camera : Push up the camera unit and rotate it clockwise until it cannot be rotated anymore, as shown in the figure. After rotation, fasten the screws assembled to the install base.

  • Page 29: Installing By Wall Mount

    installing by wall mount ` fix the installation base with the bracket 1. Fix the base with the bracket by turning it clockwise. 2. As shown in the picture below, gently press and lift up the handle of the hinged door on the bottom of the installation base.
  • Page 30 installation & connection 4. Assemble Camera and Installation Base Assemble the installation base and camera by matching the installation direction guides. 5. Attach Camera Rotate the mounted camera unit clockwise so that the reference indicators of top and bottom are as shown in the image on the right. 6.
  • Page 31 notes for waterproofing This product is an indoor unit. If it is installed outdoors, use the outdoor housing to make it waterproof. ` installing the unit on the wall by combining the outdoor housing and wall mount 1. Install the wall mount on the vertical wall. Concrete wall If the mount is installed on an inclined Silicon...

  • Page 32: Optional Accessories For Installation

    installation & connection ` installing on the wall by combining the outdoor housing and ceiling mount adapter 1. Wrap the screw part of the housing Concrete ceiling with a sufficient amount of Teflon tape for assembly. 2. When separating the dome cover and Silicon Ceiling mount fastening it to the housing frame, make...
  • Page 33 • Wall mount (SBP-300WM) 2. If installing the camera on the ceiling • Ceiling Mount (SBP-300CM) 3. If installing the wall mount (SBP-300WM/SBP-300WM1) on an at least 80mm-long cylinder • Pole Mount (SBP-300PM) English _33...
  • Page 34 4. If installing the wall mount (SBP-300WM/SBP-300WM1) on a corner of the wall • Corner Mount (SBP-300KM) 5. If installing on a building rooftop • Parapet Mount (SBP-300LM) 6. If installing SNP-6320 outdoors • Outdoor Housing (SHP-3701H) 34_ installation & connection...
  • Page 35 7. If installing SNP-6320 on a ceiling as built-in component • Flush-Mount Indoor Housing for PTZ Dome Camera (SHP-3701F) 8. If installing SNP-6320 in the wall mount or ceiling mount • Hanging Mount (SBP-300HM3) English _35...

  • Page 36: Inserting/Removing A Sd/Micro

    SD/micro SD memory carD The following models support the following SD cards: (SNP-6320 : Micro SD card, SNP-6320H : SD card) Disconnect the power cable from the camera before inserting the SD/Micro SD memory card. inserting a SD/micro SD memory card 1.

  • Page 37: Sd Memory Card

    removing a SD memory card Gently press down on the exposed end of the memory card as shown in the diagram to eject the memory card from the slot. Pressing too hard on the SD memory card can cause the card to shoot out uncontrollably from the slot when released.

  • Page 38: Network Connection And Setup

    network connection and setup network connection and setup You can set up the network settings according to your network configurations. connectinG tHe camera DirectLy to LocaL area networKinG connecting to the camera from a local pc in the Lan 1. Launch an Internet browser on the local PC. 2.

  • Page 39: Connecting The Camera Directly To A Dhcp

    connectinG tHe camera DirectLy to a DHcp BaSeD DSL/caBLe moDem INTERNET DSL/Cable External Remote PC Modem Camera DDNS Server (Data Center, KOREA) 1. Connect the user PC directly with the network camera. 2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.

  • Page 40: Modem

    network connection and setup connectinG tHe camera DirectLy to a pppoe moDem INTERNET PPPoE Modem External Remote PC Camera DDNS Server (Data Center, KOREA) 1. Connect the user PC directly with the network camera. 2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.

  • Page 41: Connecting The Camera To A Broadband Router With The

    connectinG tHe camera to a BroaDBanD router witH tHe pppoe/caBLe moDem This is for a small network environment such as homes, SOHO and ordinary shops. Camera INTERNET PPPoE or PPPoE or Broadband External Remote Cable Modem Cable Modem Router Camera DDNS Server (Data Center, KOREA) Local PC...

  • Page 42: Buttons Used In Ip Installer

    network connection and setup ButtonS uSeD in ip inStaLLer e f g Item Description Model name of the connected camera. Device Name Click the column to sort the list by model name. However, search will be stopped if clicked during the search. Alias This function is not currently implemented.

  • Page 43: Static Ip Setup

    Exits the IP Installer program. For the IP installer, use only the installer version provided in the installation CD or use the latest one if available. You can download the latest version from the Samsung web site (www.samsungcctv.com). Static ip Setup manual network Setup Run <ip installer_v2.XX.exe>...
  • Page 44 network connection and setup 3. In the <address> pane, provide the necessary information. • MAC (Ethernet) Address : The MAC address imprinted on the camera label is automatically displayed and requires no user setting. You can configure the static IP settings only if the DHCP checkbox is unchecked.
  • Page 45 if using a Broadband router • IP Address : Enter an address falling in the IP range provided by the Broadband Router. ex) 192.168.1.2~254, 192.168.0.2~254, 192.168.XXX.2~254 • Subnet Mask : The <Subnet mask> of the Broadband Router will be the <Subnet mask>...

  • Page 46: Auto Network Setup

    network connection and setup auto network Setup Run <ip installer_v2.XX.exe> to display the camera search list. At the initial startup, both [auto Set] and [manual Set] will be grayed out. For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.

  • Page 47: Dynamic Ip Setup

    Dynamic ip Setup Dynamic ip environment Setup • Example of the Dynamic IP environment - If a Broadband Router, with cameras connected, is assigned an IP address by the DHCP server - If connecting the camera directly to modem using the DHCP protocols - If IPs are assigned by the internal DHCP server via the LAN checking the Dynamic ip 1.

  • Page 48: Port Range Forward (Port Mapping)

    network connection and setup port ranGe forwarD (port mappinG) Setup If you have installed a Broadband Router with a camera connected, you must set the port range forwarding on the Broadband Router so that a remote PC can access the camera in it. manual port range forwarding 1.

  • Page 49: Connecting To The Camera From A Shared Local Pc

    Setting up port range forward for several network cameras When several network cameras are connected to one Broadband Router device, you should forward the TCP 943 port of the router to the TCP 943 port of a connected camera. If you don’t set properly the TCP 943 port of the router, you cannot get any video stream from the web page of the camera.
  • Page 50 web viewer connectinG to tHe camera normally, you would 1. Launch the Internet browser. 2. Type the IP address of the camera in the address bar. ex) • IP address (IPv4) : 192.168.1.100  http://192.168.1.100 - the Login dialog should appear. •...

  • Page 51: Password Setting

    To register your device to the <DDnS> server, visit www.samsungipolis.com and register your device first, and then set the Web Viewer’s <network> - <DDnS> to <Samsung DDnS>, as well as providing <product iD> that had been used for DDNS registration.
  • Page 52 web viewer LoGin Whenever you access the camera, the login window appears. Enter the User ID and password to access the camera. 1. Enter “admin” in the <user name> input box. The administrator ID, “admin”, is fixed and can not be changed. 2.
  • Page 53 inStaLLinG Stw webviewer pLuGin If connecting to a camera for the first time, you will see the installation message. Then, install the required WebViewer Plugin to access the camera and control the video from it in real time. 1. When the monitoring page is accessed for the very first time, the installation page is displayed.
  • Page 54 web viewer 5. Click [oK]. The old version of Web Viewer Plug-in is deleted. 6. Click [install] to begin installation of the Web Viewer Plug-in. 7. Click [finish]. STW Web Viewer Plug-in installation is completed. In your internet explorer, if you need to move to the installation screen after installing the STW webviewer plugin, check whether webviewer_...

  • Page 55: Using The Live Screen

    uSinG tHe Live Screen Item Description Monitoring Move to the monitoring screen. Move to the screen where you can search for the video recording saved in your SD Playback memory card or NAS. Setup Move to the Setup screen. Profile access You can read the profile information.
  • Page 56 web viewer Item Description Regardless of the resolution setup configured in the camera, it sets the resolution to Fix the resolution 640x480. Press it again to switch back to the default resolution. Full Screen Switch the current video to the maximum size of the monitor. Capture Saves the snapshot as an image file in the .jpg format.
  • Page 57 to capture the snapshot 1. Click [capture ( )] on the scene to capture. 2. The filed captured when you press the Capture button is saved in “My Computer  My Documents  Picture”. In Mac OS, it is saved in “~/Pictures” or “/Users/{user account}/Pictures/”.
  • Page 58 web viewer to control the ptZ 1. Press the [ptZ ( )] tab. 2. Adjust the direction of the camera by controlling the cursor [ ] of the screen moving pad, or control the zoom or focus. For further details on PTZ use, refer to “PTZ setup”.
  • Page 59 to enable the area Zoom mode : Zoom the area selected with the mouse. • : Change the current zoom factor to x1. • : Return to the previous area and settings. • : If navigated with Prev, it is switched to area and setting before navigation. •...
  • Page 60 web viewer pLayinG tHe recorDeD viDeo Before you can play the video, you must configure the record settings. For details on record settings, refer to “Storage”. (page 115) name of event search screen and its function Item Description Set the search date and time range for data saved in your SD memory card Search range setting or NAS.

  • Page 61: To Play The Content After Searching By Event

    to play the content after searching by event 1. Click the [playback ( )] button. 2. Specify the start time and end time of your search. 3. Select an event type for your search within the specified period. 4. Click the [event search] button. The search results will be displayed in the list.
  • Page 62 web viewer name of time search screen and its function Item Description Time bar The section in the specific period is played by moving the time bar. Set the search date using the calendar. Search date setting If there is data saved in your SD memory card or NAS on the day, it is marked as a box on the calendar.

  • Page 63: To Play After Searching By Time

    Item Description Video information Time data of the replayed video is displayed on the screen. Set the desired date to make a backup copy of video data saved in your SD Backup memory card or NAS. Can be set as up to 5 minutes. to play after searching by time 1.
  • Page 64 web viewer 6. Move [time bar ( )] to a desired time point of the video before playing it. The time containing a normal recoding file will be highlighted in blue; the time with the event recording will be highlighted in red. to back up the searched video 1.
  • Page 65 The following models support the following SD cards: (SNP-6320 : Micro SD card, SNP-6320H : SD card) (1) SD/micro SD memory card 1. Separate the SD/Micro SD memory card from the camera. Before separating the SD/Micro SD memory card, set the <Device> to <Off> in the “Setup ...
  • Page 66 web viewer (2) naS (network-attached Storage) 1. In Windows browser, use \\<ip address>\ to access. ex)\\192.168.20.31\defaultfolder\ch01\ img\2013_07_02\AVI 2. Go to <computer>  <network drive connection>  Enter 1. 3. Connected to the NAS. The directory structure is same as the directory structure for a SD/Micro SD memory card.

  • Page 67: Basic Setup

    setup screen Setup You can configure the video & audio, network, event and system settings of the camera in the network. 1. In the Live screen, click [ Setup ( ) ] . 2. The Setup screen appears. The setting page for preview video requires the STW web viewer plug-in to be installed on the PC. If not installed already, automatically moves to the Silverlight setup.
  • Page 68 setup screen 4. Select each profile properties. For more details, refer to “to add/change the video profile”. (Page 70) 5. Click the input box of each item and enter / select a desired value. The context menu may differ depending on the selected codec type. •...
  • Page 69 • ATC sensitivity : Affect the transfer rate according to the variance in the network bandwidth. The transfer rate will be adjusted to the fastest if the bandwidth is <very high>, and adjusted to the latest if the bandwidth is <very low>. •...

  • Page 70: To Add/Change The Video Profile

    setup screen to add/change the video profile The profile setup can be added or modified to accommodate various profiles depending on the recording conditions. 1. Select one from the <video profile> options. 2. Provide the name and select a codec. 3.
  • Page 71 • Encoding priority : You can set the priority of video transmission to frame rate or compression. • GOV length : It specifies the distance (in terms of number of frames) between two consecutive I-Frames in a video sequence when H.264 codec was selected. (One I-Frame + 0~Several P-Frames) •...
  • Page 72 setup screen user 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <user>. 3. Provide the necessary user information. • Administrator password change : Change the password for the administrator. For the security purposes, you are recommended to use a combination of numbers, alphabets uppercase and lowercase and special characters for...
  • Page 73 If the existing password is not matched, when you change the admin password, you cannot change the password. After changing your password, if there is a camera connected to a CMS or NVR client, then you need to re-register it with the newly changed password. If the camera is still connected with the same password, then the account may be locked because a client uses the previous password.

  • Page 74: Date & Time

    setup screen Date & time 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <Date & time>. 3. Specify the time and date that will be applied to the camera. • Current system time : Displays the current time settings of your system.
  • Page 75 ip & port 1. From the Setup menu, select the <Basic ( )> tab. 2. Click <ip & port>. 3. Set the <ipv4 setup>. • IP type : Select an IP connection type. - Manual : Specify the IP address, Subnet mask, Gateway, DNS1, and DNS2.

  • Page 76: Event Setup

    65535 as your HTTPS port.) • RTSP : Used to transfer videos in the RTSP mode; the default is 554. • Device port : Set a port used to transfer video signals with the Samsung protocols.

  • Page 77: Ptz Setup

    ptZ setup You can change the direction of lens and activate the zoom. 1. Select the <Basic ( )> tab from Setup menu. 2. Click <ptZ setup>. 3. Click [▼ Show]. 4. Click the cursor [ ] on the screen moving pad to control movement of the screen.
  • Page 78 setup screen To add the home position 1. Move to a desired start screen point and press [ The point will be set to the home position. 2. Click [ ] in the home position. You will move to the predetermined home position. 3.
  • Page 79 To configure the detailed settings for the preset 1. Select the number of preset that you want to configure. 2. Click the <preset edit setup> tab. • Camera setup : You can change the camera setting to the environment of the selected preset.
  • Page 80 setup screen to use the motion Detection (mD) function 1. Select the <mD / va> type on the <preset edit setup> tab. 2. Select the <motion detection> mode. 3. Select <on>. 4. Select the sensitivity of separating movement from the background. You can select 5 levels of sensitivity (very low/low/normal/high/very high).
  • Page 81 to use the intelligent video analysis (va) function 1. Select the <mD / va> type on the <preset edit setup> tab. 2. Select the <video analytics> mode. 3. Select <on>. 4. Select the sensitivity of separating movement from the background. You can select 5 levels of sensitivity (very low/low/normal/high/very high).
  • Page 82 setup screen 6. Select the type of analysis. • Passing : The system detects the change in which an object passes the preset line. • Entering/Exiting : The system detects the change in which an object passes the preset area. •...
  • Page 83 to set the video analysis rules ` passing 1. Set the type to <passing>. 2. Click the start and end point on the screen to set the base line. You can cancel the line while drawing an area by right-clicking the mouse. 3.
  • Page 84 setup screen ` appearing (Disappearing) 1. Set the analysis type to <appearing (Disappearing)>. 2. Drag the desired location of the image. The dragged grey area will be set as an area of interest. • Appearing/Disappearing : It detects event of appearing object that appears in the area and remaining for a certain time period while not passing through the area borders, and opposite case of disappearing of objects...
  • Page 85 To configure the swing settings Swing is a monitoring function that moves between two preset points and enables you to trace the motion. 1. Select <Swing> in <Sequence setup>. The menu screen will switch to the swing setting screen. 2. Select a swing setting mode. •...
  • Page 86 setup screen To set a group The group function enables you to group various presets before calling them in sequence. Six groups can save a total of 128 presets each. 1. Select <Group> in <Sequence setup>. The menu screen will switch to the group setting screen.
  • Page 87 To configure the tour settings The tour function enables you to call groups of your presets in sequence. 1. Select <tour> in <Sequence setup>. The menu screen will switch to the tour setting screen. 2. Configure the tour settings in detail. •...
  • Page 88 setup screen 3. Press the [ ] button. Selected tracing number will be saved. 4. Move the navigation path of saving using the pan/tilt/zoom. 5. Press the [ ] button. Saving is terminated. 6. Press the [ ] button. Selected tracing number will be activated as set. To set the auto run This feature will activate the predefined sequence function if the user does not manipulate anything on the product for a certain time.

  • Page 89: Video Setup

    viDeo & auDio Setup video setup 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <video setup>. 3. Select a <video source> mode. • Flip/Mirror : Displays the video from the camera upside down or reversely. •...
  • Page 90 setup screen to set the privacy zone You can specify a certain area of the camera video to be protected for your privacy. 1. Set it to <on>. 2. Select the color masking of desired privacy area. 3. When done, click [apply ( 4.

  • Page 91: Audio Setup

    audio setup You can configure the I/O settings of the audio source from the camera. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <audio setup>. 3. Set the audio input value. • Source : Sets the audio input. - Line : Connect the cable to the audio device.

  • Page 92: Camera Setup

    SSDr (Samsung Super Dynamic range) Setup In a scene where the difference between bright and dark is severe, you can increase the brightness of the dark area alone to regulate the overall brightness.
  • Page 93 white balance Setup You can correct the image colors based on white under any lighting conditions. 1. Select <white balance>. 2. Select <mode>. • ATW : Corrects the colors of the camera video automatically. ATW does not work under mercury/ sodium lamps.
  • Page 94 setup screen BLc Setup You can specify a desired area on the video manually and set the area to be displayed more clearly. 1. Select <Back light>. 2. Set <mode> to <BLc>. If you select BLC, the Box adjustment screen and the BLC Box step are displayed on the PTZ Control screen.
  • Page 95 wDr Setup You can set to display a sharp image of the objects in a scene where both bright and dark areas exist. 1. Select <Back light>. 2. Set <mode> to <wDr>. 3. Select each item and set it properly. •...
  • Page 96 setup screen For the best WDR performance, it is recommended to set the Iris mode to <Auto>. Since the auto focus operation can be repeated depending on the lighting condition if user backlight compensation is used, it is recommended to use the focusing mode of <One Shot AF> or <Manual>.
  • Page 97 Special Setup 1. Select <Special>. 2. Select each item and set it properly. • DIS : Automatically compensates for the flicker on the screen. DIS cannot be used if VA/MD and tempering detection are used. Digital zoom cannot be used if DIS is used. •...

  • Page 98: Focus Setup

    setup screen focus Setup 1. Select <focus>. 2. Select each item and set it properly. • Mode - Manual : The focus will be adjusted manually according to the zoom factor. - Auto : The focus will be adjusted automatically according to the zoom factor. - One Shot AF : Auto Focus will be performed once after the zooming operation.
  • Page 99 oSD Setup 1. Select <oSD>. 2. Select each item and set it properly. • Camera title : Specify whether or not to display the camera title on the screen. You can enter up to 15 characters for the title. • Camera title X, Y : Specify the coordinates where the camera title is displayed on the screen.
  • Page 100 setup screen Smart codec Set a desired area of the video incoming from the camera as ROI area and specify the detection sensitivity for the area. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <Smart codec>. 3.
  • Page 101 pt limit You can specify restrictions on the pan or tilt function. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <pt limit>. 3. Decide if you want to limit the PT operations. If so, specify the details. •...
  • Page 102 setup screen auto tracking setup You can set up as per setup environment as appropriate to camera auto tracking or change settings. 1. From the Setup menu, select the <video & audio ( )> tab. 2. Click <auto tracking setup>. 3.
  • Page 103 To set the auto tracking area You can set up the area to be excluded from auto tracking objects. (You can set up to 8 non detection areas.) 1. Click [▼ Show]. 2. Mouse-click on the image, and drag to set the desired area.
  • Page 104 setup screen It may be unable to track a target or lead to misoperations under the following situations. When multiple moving objects exist in the shot area When it is hidden or overlapped by other moving objects or facilities When there is no little difference between moving object and background An object too small or too large When an object moves too fast or too slow When a moving object passes right below the installed camera...

  • Page 105: Network Setup

    - User name : Enter the user name for the DDNS service. - Password : Enter the password for the DDNS service. 5. When done, click [apply ( If selected <Quick connect>, be sure to select Samsung DDNS service. English _105...

  • Page 106: Registering With Ddns

    DDnS to register your product with the Samsung DDnS 1. Visit the iPOLiS web site (www.samsungipolis.com) and sign in with a registered account. 2. From the top menu bar, select <DDnS Service> - <my DDnS>. 3. Click [proDuct reGiStration].
  • Page 107 Samsung DDnS in camera setup 1. From the DDNS setup page, set <DDnS> to <Samsung DDnS>. 2. Provide the <product iD> that you registered product ID with the DDNS site. 3. Click [apply ( When the connection is successfully made, you will see the message of <(Success)>...
  • Page 108 setup screen ip filtering You can create a list of IPs that you want to grant or deny access to them. 1. From the Setup menu, select the <network ( )> tab. 2. Click <ip filtering>. 3. Select <filtering type>. •...
  • Page 109 You can select a secure connection system or install the public certificate for this purpose. 1. From the Setup menu, select the <network ( )> tab. 2. Click <SSL>. 3. Select a secure connection system. To access the camera using HTTPS mode, you have to type the IP address for the camera in the form of “https://<Camera_IP>”.
  • Page 110 setup screen 802.1x When connecting network, you can choose whether using 802.1x protocol, and then install the certification. 1. From the Setup menu, select the <network ( )> tab. 2. Click <802.1x>. 3. Set the <ieee 802.1x setting(eapoL using eap-tLS)>. •...
  • Page 111 You can specify the priority to secure a stable transfer rate for a specific IP. 1. From the Setup menu, select the <network ( )> tab. 2. Click <QoS>. 3. Click the [add ( )] button. The IP list will be created. 4.
  • Page 112 setup screen • Enable SNMP Trap : SNMP trap is used to send important events and conditions to the Admin. - Community : Enter the trap community name to receive messages. - IP address : Enter the IP address to which messages will be sent. - Authentication failure : It specifies whether an event shall be generated when the community information is invalid.
  • Page 113 • UPnP discovery : It specifies Able or Disable for UPnP Discovery. • Friendly name : Display the camera name. Friendly name is displayed in the format of SAMSUNG-<Model Name>-<MAC Address>. In the Windows operating system which basically supports UPnP, the cameras connected to the network are displayed.
  • Page 114 setup screen event Setup ftp / e-mail You can configure the FTP/E-mail server settings so that you can transfer the images taken with camera to your PC if an event occurs. 1. From the Setup menu, select the <event ( )>...
  • Page 115 • E-mail configuration - Server address : Enter the IP address of the email server that you transfer the alarm or event images to. - Use authentication : Select whether to use authorization. - Use SSL : Specify the use of SSL. - ID : Enter the user ID for logging into the email server.
  • Page 116 If you insert a SD card saved in another saving file type (AVI/STW), you will need to format it before use. - STW : It is Samsung Techwin’s unique file format. - AVI : It is the conventional avi format.
  • Page 117 4. Specify the <normal record setup>. • Always : Always save recorded video in the SD memory card. If set to Always, the activation time cannot be changed. • Only scheduled time : Records only on the specified time of the specified day of week. •...
  • Page 118 setup screen Confirm that the NAS IP address and the camera IP address are in the same format. ex) The NAS & camera subnet mask initial value is 255.255.255.0. If the IP address is 192.168.20.32 then the NAS IP address should be in the range of 192.168.20.1~192.168.20.255.
  • Page 119 naS (network attached Storage) guide When you use the NAS, you might be unable to save data due to temporary network disconnections. If the setting allows a SD memory card and the NAS to be simultaneously connected for use, the higher priority for recording goes to the NAS.
  • Page 120 setup screen 3. Click the <Shared folder> in the file sharing and privilege menu. 4. Click the [create] button. 5. After entering the shared folder name(ID), click the [oK] button to create a shared folder. In this example, the shared folder name is [testDirectory].
  • Page 121 8. After clicking the [create] button, enter name(ID) and password. In this example, name(ID) is set to [testiD] and password is also set to [testiD]. According to the NAS recommendations, when you use Netgear’s NAS equipment, do not allocate the capacity for use. 9.

  • Page 122: Alarm Output

    setup screen alarm output 1. From the Setup menu, select the <event ( )> tab. 2. Click <alarm output>. 3. Set the camera’s type of alarm output. If you change the alarm output type, the alarm out button on the monitoring page and alarm output type displayed on Event Setup page will be changed accordingly.

  • Page 123: Alarm Input

    alarm input You can set the alarm input type, activation time, and operation mode. 1. From the Setup menu, select the <event ( )> tab. 2. Click <alarm input>. 3. Select the alarm input number. 4. Set whether or not to <enable>. 5.
  • Page 124 setup screen 7. Specify an operation that will perform if an alarm occurs. • FTP : Specify the use of FTP transfer in the alarm input setup. Refer to “FTP / E-mail” for more details. (page 114) • E-mail : Specify the use of email transfer in the alarm input setup. Refer to “FTP / E-mail”...

  • Page 125: Time Schedule

    time schedule You can set to save the video data at a certain interval as scheduled regardless of the actual occurrence of the event. 1. From the Setup menu, select the <event ( )> tab. 2. Click <time schedule>. 3. Set whether or not to <enable>. 4.

  • Page 126: Tampering Detection

    setup screen tampering detection You can set to detect tampering attempts and trigger events, such as sudden change of camera’s framing direction, blocked lens and other overall change of scenes from the video. 1. From the Setup menu, select the <event ( )>...
  • Page 127 mD / va Events of motion detection and video analysis can be set to trigger event signal output. 1. From the Setup menu, select the <event ( )> tab. 2. Click <mD / va>. 3. Specify the activation time and activation condition.

  • Page 128: Face Detection

    setup screen face detection You can set to detect recognized face and trigger an event accordingly. 1. From the Setup menu, select the <event ( )> tab. 2. Click <face detection>. 3. Set whether or not to <enable> . 4. Select <Sensitivity> tab to set the sensitivity level.

  • Page 129: Audio Detection

    audio detection You can set to detect sound over the specified level and trigger an event accordingly. 1. From the Setup menu, select the <event ( )> tab. 2. Click <audio detection>. 3. Set whether or not to <enable> . 4.

  • Page 130: Auto Tracking

    setup screen auto tracking You can set the system to generate event signals when you activate the auto tracing function. 1. From the Setup menu, select the <event ( )> tab. 2. Click <auto tracking>. 3. Specify the activation time and activation condition.

  • Page 131: System Setup

    SyStem Setup product information 1. From the Setup menu, select the <System ( )> tab. 2. Click <product information>. 3. Check the camera information, or provide details according to your network environment. • Model : Model name of the product. •...
  • Page 132 setup screen upgrade / reboot 1. From the Setup menu, select the <System ( )> tab. 2. Click <upgrade / reboot>. 3. Select a desired item and set it appropriately. • Upgrade : Performs upgrading the system. • Factory default : Resets the system to the factory default.
  • Page 133 If you forcibly terminate the upgrade process, upgrade will not be completed properly. During restarting the system, accessing with web viewer will not be made. You can download the latest version from the Samsung web site (www.samsungcctv.com). to back up the current settings 1.
  • Page 134 setup screen You can check the system log or event log. 1. From the Setup menu, select the <System ( )> tab. 2. Click <Log>. 3. Select a log type. • System : You can check the system logs where any system changes are recorded including the time information.
  • Page 135 open SDK A user can install an application on their camera to execute additional functions. 1. From the Setup menu, select the <System ( )> tab. 2. Click <open SDK>. 3. Click the [Browse ( button to select the *.cap file from the user folder.
  • Page 136 setup screen viewinG profiLe information profile access You can check the profile information. 1. Click [Status ( )] on the live screen. 2. The profile information screen is displayed. • Profile access : Show the information of the newly added profile. - Profile : Show the information of the newly added codec.

  • Page 137: Dip Switch Setting

    appendix Dip SwitcH SettinG How to set up protocols and iD Dip Switches You can control various settings of the camera system using the Communication and ID DIP switches. Before installing the product, please set up the DIP switches according to the installation environment.

  • Page 138: Protocol Settings

    Transfer Method (RS-485/422) Settings Termination Settings 1 Termination Settings 2 Reserved • protocol Settings Select a communication protocol for the camera. Protocol SW2-#1 SW2-#2 SW2-#3 SW2-#4 Samsung(Default) Pelco-D Pelco-P Samsung Elec. Panasonic Vicon Honeywell BOSCH Reserved Reserved Reserved Reserved Reserved Reserved 138_ appendix...

  • Page 139: Baud Rate Settings

    • baud Rate Settings Select the transfer speed of a selected communication protocol. Baud Rate (BPS) SW2-#5 SW2-#6 2400 4800 9600 (Default) 19200 • Communication Method Settings Select a communication method for the camera. Function SW2-#7 Transfer Mode Switch RS-422(4Wire) RS-485(2Wire) •...

  • Page 140: Camera Id Chart

    appendix camera iD Dip Switch Settings (Sw1) To set up camera IDs, refer to the “camera iD chart” next. • Camera iD Chart SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 ON/OFF 140_ appendix...
  • Page 141 SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 English _141...
  • Page 142 appendix SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 142_ appendix...
  • Page 143 SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 English _143...
  • Page 144 appendix SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 144_ appendix...
  • Page 145 SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 English _145...
  • Page 146 appendix SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8 146_ appendix...
  • Page 147 camera wirinG control Signal connection • RS-485 Communications Camera Controller TXD+ TXD- • RS-422 Communications Camera Controller TXD+ TXD- TXD+ RXD+ TXD- RXD- communications cable For the camera to communicate with the controller, a RS-485/422 communications line is required. A 30m or shorter length is recommended for the connection. The communication cable is not enclosed with the camera.
  • Page 148 Specification Description Items SNP-6320 SNP-6320H Imaging Device 1/2.8” Progressive Scan CMOS Total Pixels 1952(H) x 1236(V) 2.41M Effective Pixels 1944(H) x 1224(V) 2.38M Scanning System Progressive Scan Video Color : 0.3 Lux (1/30sec, F1.6, 50IRE) Min. Illumination B/W : 0.03 Lux (1/30sec, F1.6, 50IRE)
  • Page 149 Auto (ICR) / Color / B/W Backlight Compensation Off / BLC / HLC Wide Dynamic Range 120dB Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On) Digital Noise Reduction SSNRIII (2D+3D Noise Filter) (Off / On) Digital Image Stabilization Off / On Defog...
  • Page 150 Description Items SNP-6320 SNP-6320H y File upload via FTP and E-Mail y Notification via E-Mail, TCP and HTTP Operational Alarm events y Local storage(SD/SDHC/SDXC) recording at Network disconnected & Event (Alarm Triggers) y External output Ethernet RJ-45 (10/100BASE-T) Video Compression Format H.264 (MPEG-4 Part 10/AVC), Motion JPEG...
  • Page 151 802.1x Authentication Streaming Method Unicast / Multicast Max. User Access 15 users at Unicast Mode SD/SDHC/SDXC (SNP-6320 : Micro-SD Type, SNP-6320H : SD Type) Memory Slot - motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS(Network Attached Storage)
  • Page 152 Description Items SNP-6320 SNP-6320H AC24V : -50°C ~ +55°C (-58°F ~ +131°F) / ~ 90% RH PoE+ : -30°C ~ +55°C (-22°F Operating Temperature / -10°C ~ +55°C (+14°F ~ ~ +131°F) / ~ 90% RH Humidity +131°F) / Less than 90% RH...

  • Page 153: Product Overview

    ` Snp-6320 Unit : mm (inch) Ø152(5.98) Ø133.2(5.24) English _153...
  • Page 154 appendix ` Snp-6320H Unit : mm (inch) 1-1/2 inch PF TAP [Diameter (max) = 47.803mm, Pitch=2.3091mm] Ø220(8.66) 154_ appendix...

  • Page 155: Troubleshooting

    trouBLeSHootinG PROBLEM SOLUTION y Check to make sure that the camera’s Network settings are appropriate. y Check to make sure that all network cables have been connected properly. I can’t access the camera from a y If connected using DHCP, verify that the camera is able to acquire web browser.
  • Page 156 appendix PROBLEM SOLUTION Can I define event rules even y Yes, it can be. You can set rules for events despite of the intelligent when I don’t use <Motion video analysis setting. detection / Video analytics>? No signal is found at the Alarm Output port even when an y Check alarm output port settings.

  • Page 157: Gnu General Public License

    Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
  • Page 158 You may charge a fee for the physical act of transferring a Subsection b above.) The source code for a work means copy, and you may at your option offer warranty protection in the preferred form of the work for making modifications exchange for a fee.
  • Page 159 enD of termS anD conDitionS application of that system ; it is up to the author/donor to decide if he or she is willing to distribute software through How to apply these terms to your new programs any other system and a licensee cannot impose that choice. This section is intended to make thoroughly clear what is If you develop a new program, and you want it to be of believed to be a consequence of the rest of this License.
  • Page 160 preamble “Licensees” and “recipients” may be individuals or organizations. The GNU General Public License is a free, copyleft license To “modify” a work means to copy from or adapt all or part for software and other kinds of works. The licenses for of the work in a fashion requiring copyright permission, most software and other practical works are designed to other than the making of an exact copy.
  • Page 161 2. Basic permissions. d) If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the All rights granted under this License are granted for the term Program has interactive interfaces that do not display of copyright on the Program, and are irrevocable provided Appropriate Legal Notices, your work need not make the stated conditions are met.
  • Page 162 favor of coverage. For a particular product received by c) Prohibiting misrepresentation of the origin of that a particular user, “normally used” refers to a typical or material, or requiring that modified versions of such common use of that class of product, regardless of the material be marked in reasonable ways as different from status of the particular user or of the way in which the the original version;...
  • Page 163 10. automatic Licensing of Downstream recipients. covered work and works based on it. A patent license is “discriminatory” if it does not include within the scope of its Each time you convey a covered work, the recipient coverage, prohibits the exercise of, or is conditioned on the automatically receives a license from the original licensors, non-exercise of one or more of the rights that are specifically to run, modify and propagate that work, subject to this...

  • Page 164: End Of Terms And Conditions

    15. Disclaimer of warranty. you can change the software and use pieces of it in new free programs; and that you are informed that you can do THERE IS NO WARRANTY FOR THE PROGRAM, TO THE these things. EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT To protect your rights, we need to make restrictions that HOLDERS AND/OR OTHER PARTIES PROVIDE THE...
  • Page 165 Although the Lesser General Public License is Less protective the facility is invoked, then you must make a good of the users’ freedom, it does ensure that the user of a faith effort to ensure that, in the event an application program that is linked with the Library has the freedom and does not supply such function or table, the facility still the wherewithal to run that program using a modified version...
  • Page 166 Library (because it contains portions of the Library), rather e) Verify that the user has already received a copy of than a “work that uses the library”. The executable is these materials or that you have already sent this user a therefore covered by this License.
  • Page 167 If any portion of this section is held invalid or unenforceable DAMAGES, INCLUDING ANY GENERAL, SPECIAL, under any particular circumstance, the balance of the section INCIDENTAL OR CONSEQUENTIAL DAMAGES is intended to apply, and the section as a whole is intended ARISING OUT OF THE USE OR INABILITY TO USE THE to apply in other circumstances.
  • Page 168 Computer Science Department at University College - Redistributions in binary form must reproduce the above London copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials 4. Neither the name of the University nor of the Department provided with the distribution.

  • Page 169: Openssl License

    and/or sell copies of the Software, and to permit persons from this software without prior written permission. to whom the Software is furnished to do so, subject to the For written permission, please contact openssl-core@ following conditions: openssl.org. 5. Products derived from this software may not be called THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, “OpenSSL”...
  • Page 170 THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ‘‘AS OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND IS AND ANY EXPRESS OR IMPLIED WARRANTIES, ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR WARRANTIES OF MERCHANTABILITY AND FITNESS OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
  • Page 171 Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
  • Page 172 SALES NETWORK SAMSUNG TECHWIN CO., LTD. Samsung Techwin R&D Center, 6, Pangyo-ro 319beon-gil, Bundang-gu, Songnam-si, Gyeonggi-do 463-400, Korea TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660...

This manual is also suitable for:

Snp-6320h

Table of Contents
