1.3 Measures

Power
F1 F2
Shift
38 mm
(1.50")
135.4 mm (5.33")
68.8 mm
An optional paper cutter increases the printer's total length by 28 mm (1.1").
At least 90 mm (3.5") of free space behind the printer is required for the connectors,
UBI EasyCoder 601 XP – Service Manual Ed. 1
Ready Error EasyCoder 601 XP
7 8 9
4 5 6
1 2 3
F3 F4 F5
.
0 C
259 mm (10.20")
168 mm (6.61")
335 mm (13.18")
Dot No. 0
(8 dots/mm printhead
in right-hand position)
(2.71")
and for inserting and removing a memory card.
Pause Setup
Feed Enter
Print
79 mm
(3.11")
363 mm (14.29")
481.5 mm (18.96")
Chapter 1 Models and Options
238 mm
(9.37")
Paper slot
Paper slot
20 mm
(0.79")
186 mm
(7.32")
20 mm
(0.79")
30 mm
(1.18")
12 mm
(0.47")
13
