TUMBLE DRYER
EN
English
IDVA 735
IDVA 735 S
www.indesit.co.uk
This symbol reminds you to read this
!
instruction manual.
!
Keep this manual at hand for immediate reference whenever
necessary. Always store this manual close to the tumble dryer and
remember to pass it on to any new owners when selling or tran-
sferring the appliance, so they may familiarise with the warnings
and suggestions herein contained.
!
Read these instructions carefully: the following pages contain
important information on installation and useful suggestions for
operating the appliance.
Contents
Before you start your dryer
Warnings, 4
Saving energy and respecting the environment
Special programmes
Laundry, 13
Troubleshooting, 14
EN
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Indesit IDVA 735
Summary of Contents for Indesit IDVA 735
-
Page 1: Table Of Contents
Cleaning the tumble dryer Description of the tumble dryer, 7 IDVA 735 Front side Rear side IDVA 735 S Control panel How to carry out a drying cycle, 9 Starting and selecting a programme Programmes and options, 10 Programme chart... -
Page 2: Iinstallation
Installation Where to install the tumble dryer Wall ventilation hole 1. Leave an opening in the wall Install the dryer far • to the left of the tumble dryer from gas ranges, stoves, installation site. radiators or hobs, as 2. Make the hose as short and flames may damage it. -
Page 3: Electrical Connections
Model ! The power cord must not be bent or IDVA 735 (UK) IDVA 735 S (UK) squashed. Rated capacity of cotton laundry for the "standard cotton ! If the plug being replaced is a non-rewirable programme"... -
Page 4: Warnings
Warnings warm items inside. This appliance has been designed and built according to international safety standards. These warnings are given for • Clean the filter after each use (see safety reasons and must be followed carefully. Maintenance). General safety • Do not allow lint to collect around the dryer. •This appliance can be used by children •... - Page 5 rubber (also known as latex foam), or similarly textured rubber like materials. Foam rubber materials can, when heated, produce fire by spontaneous combustion. • Fabric softener or similar products should not be used in a tumble dryer to eliminate the effects of static electricity unless the practice is specifically recommended by the manufacturer of the fabric softener product.
-
Page 6: Care And Maintenance
Care and maintenance Disconnecting the power supply Do not use solvents or abrasives. Have the dryer checked regularly by authorised technical ! Disconnect the dryer when not in use or personnel in order to ensure that the electrical and mechani- during cleaning and maintenance operations. -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Front side Rear side Control panel Drum Air inlet Rating Plate Serial number and model Caution, high number Filter Connection for temperature ventilation hose Control panel Options On/Off buttons and Start/Pause button button indicator lights and indicator light Programme Clean filter... -
Page 8: Indicator Lights
ON/OFF/Reset button Pressing the button normally will cause the machine to switch on or off. If the button is pressed for 3 seconds while the dryer is in function, the machine will switch off and the running cycle will reset. Programme selection knob Allows for setting the programme: turn until the indicator points towards the desired programme (see Starting and selecting a programme). -
Page 9: How To Carry Out A Drying Cycle
How to carry out a drying cycle Starting and selecting a programme 1. Plug the dryer into the power supply socket. 2. Select the programme according to the type of laundry (see Laundry). 3. Open the door, ensure that the filter is clean and securely placed. 4. -
Page 10: Programmes And Options
Programmes and options Programme chart Max. load Cycle Programme Compatible options (kg) duration Daily 1 Ready to wear Max. Pre anti-crease – Post anti-crease – Delay start 130’ 2 Standard Cotton Max. Pre anti-crease – Post anti-crease – Delay start 120’... - Page 11 Sport Intensive Programme This programme is designed for safely drying garments such as tracksuits and shorts bearing the symbol. It is ideal for clothes which do not need to be dried fully. We suggest turning garments inside out before drying them. ! The duration of this program will depend on the size of the load and the spin speed used in your washer.
-
Page 12: Options
Options The options allow for customising the selected programme according to one’s own needs. Delay start The start of some programmes (see Programmes and options) may be delayed up to 9 hours. Press the button repeatedly to enter the desired delay time. Before setting a delayed start, make sure that the filter is clean. Post Anti-Crease When this option is selected, the drum rotates garments at intervals after the COOL TUMBLE cycle has ended, in order to avoid creases forming on garments if they cannot be immediately removed at the end of the programme. -
Page 13: Laundry
Laundry Sorting laundry Drying times • Check the symbols on the care labels of the various gar- Drying times are approximate and may vary depending on ments to verify whether the garments can be safely tumble the following: dried. • Sort laundry according to the type of fabric. •... -
Page 14: Troubleshooting
Troubleshooting If you feel that the dryer is not working properly, consult the following troubleshooting suggestions before contacting the Technical Assistance Centre (see Assistance). Problem: Possible causes / Solutions: The dryer does not start. • The plug has not been inserted far enough into the socket to make contact. •... -
Page 15: Assistance And Guarantee
Assistance Spare parts Before contacting the Technical Assistance Centre: • Follow the troubleshooting guide to check whether pro- This dryer is a complex machine. Attempting to repair it per- blems can be solved personally (see Troubleshooting). sonally or having an unqualified person may put the safety or •... -
