- Page 1 CBA 100M-110 10 KHZ to 100 MHZ 100 wAtt AMplifier user MAnuAl 601-292A...
- Page 2 CBA 100M-110 10 KHZ to 100 MHZ 100 wAtt AMplifier user MAnuAl CBA 100M-110 User Manual...
-
Page 3: Table Of Contents
Contents Safety information Introduction CBA 100M-110 Introduction Unpacking and installation Unpacking Installation Operation Front panel Rear panel Specifications Warranty Adresses... -
Page 5: Safety Information
1 sAfety inforMAtion This apparatus has been designed and tested in accordance with BS EN 61010-1, and has been supplied in a safe condition. This manual contains some informa- tion warnings which must be followed to ensure safe operation, and to retain the apparatus in a safe condition. - Page 6 This apparatus must be disconnected from all voltage sources before it is opened for adjustment, replacement, maintenance or repair. Make sure that only fuses of the required rated current and of the specified type are used for replacement. The use of makeshift fuses and the short-circuiting of fuse holders is prohibited. CBA 100M-110 User Manual...
-
Page 7: Introduction
2 introduCtion CBA 100M-110 Introduction The CBA 100M-110 is an amplifier capable of supplying 110 W into a 50 ohm load over the frequency range 10 kHz to 100 MHz, during the course of EMC tests on electrical equipment. The amplifier is designed with sufficient gain such that it may be used with normal output levels of signal sources. - Page 8 Arcing due to high RF voltages present Always ensure that the output of the at the output connector amplifier is terminated either by the system antenna or a suitable high power RF load or attenuator. CBA 100M-110 User Manual...
-
Page 9: Unpacking And Installation
3 unpACKing And instAllAtion 3.1 Unpacking The CBA 100M-110 package should contain: 10 kHz to 100 MHz amplifier CBA 100M-110 Power cable (UK) Power cable (USA / JAPAN) Power cable (EUROPE) Spare fuse T 6.3 A time delay 20 mm... -
Page 10: Operation
170 W. On no account operate the amplifier without a proper termination or with defective cables or connectors. The centre conductor of the RF output represents a severe burn hazard to personnel. CBA 100M-110 User Manual... -
Page 11: Rear Panel
Air inlet The amplifier depends upon a free air supply for cooling. Ensure that the front air inlet is not restricted. 4.2 Rear panel Mains input The mains input is an IEC 60320 type. The cable attached to the mains input must be rated at 10 A to ensure proper operation at the minimum line voltage of 85 Vac. -
Page 12: Specifications
USB interface Optional EMC and safety Conducted and radiated emissions EN 61326 class A Conducted and radiated immunity EN 61326: 1997 table 1 Mains harmonic currents EN 61000-3-2 Voltage fluctuations and flicker EN 61000-3-3 Safety EN 61010-1 CBA 100M-110 User Manual... - Page 13 Power Supply voltage (1-phase) 85-264 Vac Supply frequency range 45-63 Hz Supply power <500 VA Mains connector IEC 320 Environmental Operating temperature range 0-40°C Mechanical Case dimensions 19 inch, 4U case, 440 mm deep Weight 20 kg Options (select at time of ordering) 341-715 Bench model with front panel mounted input/output connectors 341-815...
-
Page 14: Warranty
All information in this manual is given in good faith. However, the company shall not be liable for any loss or damage whatsoever arising from the use of this manual, the product described in it or any errors or omissions in either. CBA 100M-110 User Manual... - Page 15 notes...
-
Page 16: Adresses
Manufacturer Headquarters Teseq AG Teseq AG 4542 Luterbach, Switzerland 4542 Luterbach, Switzerland T + 41 32 681 40 40 T + 41 32 681 40 40 F + 41 32 681 40 48 F + 41 32 681 40 48 sales @ teseq.com sales @ teseq.com www.teseq.com...
