- Page 1 100M-1100 10 KHZ to 100 MHZ 1.1 KW AMplifier user MAnuAl 601-294A...
- Page 2 100M-1100 10 KHZ to 100 MHZ 1.1 KW AMplifier user MAnuAl CBA 100M-1100 User Manual...
-
Page 3: Table Of Contents
Safety information Introduction CBA 100M-1100 Introduction Unpacking and installation Unpacking Installation Operation Specifications Warranty Adresses... -
Page 5: Safety Information
1 sAfety inforMAtion This apparatus has been designed and tested in accordance with BS EN 61010-1, and has been supplied in a safe condition. This manual contains some informa- tion warnings which must be followed to ensure safe operation, and to retain the apparatus in a safe condition. - Page 6 This apparatus must be disconnected from all voltage sources before it is opened for adjustment, replacement, maintenance or repair. Make sure that only fuses of the required rated current and of the specified type are used for replacement. The use of makeshift fuses and the short-circuiting of fuse holders is prohibited. CBA 100M-1100 User Manual...
-
Page 7: Introduction
2 introduction CBA 100M-1100 Introduction The CBA 100M-1100 is an amplifier capable of supplying 1.1 kW into a 50 ohm load over the frequency range 10 kHz to 100 MHz, during the course of EMC tests on electrical equipment. The amplifier is designed with sufficient gain such that it may be used with normal output levels of signal sources. - Page 8 Arcing due to high RF voltages present Always ensure that the output of the at the output connector. amplifier is terminated either by the system antenna or a suitable high power RF load or attenuator. CBA 100M-1100 User Manual...
-
Page 9: Unpacking And Installation
3 unpAcKing And instAllAtion 3.1 Unpacking The CBA 100M-1100 should contain the following items housed in a 19 inch 34 U rack: Amplifier switch unit Amplifier module Amplifier input/output module Amplifier power unit Plus the following documentation: CBA 100M-1100 Operating manual (this document) Certificate of calibration Check that the equipment is complete as in the packing list above. - Page 10 N to N cables The order of connection is arbitrary. Connect the BNC to BNC cables from the centre unit to each of the amplifier units. CBA 100M-1100 User Manual...
- Page 11 Mains input is via a pre-wired IEC 60309 3-phase plug. Star configured supplied with a 5 pin plug. Delta configured supplied with a 4 pin plug If the plug requires rewiring, brown and 2 black wires are 3-phase line, blue is neutral when used in star (unused in delta configuration) and green/yellow for earth.
-
Page 12: Operation
In the case of one of these faults occurring the fans will continue to operate. The fault state is indicated by the illumination of the red fault indicator. The behaviour of the amplifier under these circumstances provides a first level diagnostic to the fault, as described in table 1. CBA 100M-1100 User Manual... - Page 13 Symptom Possible cause Course of action Fault light illuminates Excess module Let amplifier fans run for immediately temperature a while, and re-try later Air-cooling failure Check fan operation and air vents Power supply Check mains supply for failure interruption Amplifier runs for a while Excess module Check ambient tempera- and then goes into fault...
- Page 14 Dust can rapidly build up on the air inlets, these should be checked and cleaned at regular intervals to ensure continued reliable operation of the amplifier. Inter- vals should not be longer than six months but may be required more often in dusty environments. CBA 100M-1100 User Manual...
-
Page 15: Mains Input
Mains input Mains input is via a pre-wired IEC 60309 3-phase plug. Star configured supplied with a 5 pin plug. Delta configured supplied with a 4 pin plug. If the plug requires rewiring brown and 2 black wires are 3-phase line, blue is neutral when used in star (unused in delta configuration) and green/yellow for earth. -
Page 16: Specifications
USB interface Optional EMC and safety Conducted and radiated emissions EN 61326 class A Conducted and radiated immunity EN 61326: 1997 table 1 Mains harmonic currents EN 61000-3-2 Voltage fluctuations and flicker EN 61000-3-3 Safety EN 61010-1 CBA 100M-1100 User Manual... - Page 17 Power Supply voltage (3-phase) 184-264 Vac Supply frequency range 47-63 Hz Supply power <6 KVA Mains connector Appropriate IEC 60309 plug (see options) Environmental Operating temperature range 0 to 40°C Mechanical Dimensions 19 inch, 34U rack, 800 mm deep Mass 200 kg Options (select at time of ordering) 341-721...
-
Page 18: Warranty
All information in this manual is given in good faith. However, the company shall not be liable for any loss or damage whatsoever arising from the use of this manual, the product described in it or any errors or omissions in either. CBA 100M-1100 User Manual... - Page 19 notes...
-
Page 20: Adresses
Manufacturer Headquarters Teseq AG Teseq AG 4542 Luterbach, Switzerland 4542 Luterbach, Switzerland T + 41 32 681 40 40 T + 41 32 681 40 40 F + 41 32 681 40 48 F + 41 32 681 40 48 sales @ teseq.com sales @ teseq.com www.teseq.com...
