Summary of Contents for Teseo CBA 3G-100
- Page 1 3G-100 800 MHZ to 3.1 GHZ 100 wAtt AMplifier user MAnuAl 601-290A...
- Page 2 3G-100 800 MHZ to 3.1 GHZ 100 wAtt AMplifier user MAnuAl CBA 3G-100...
-
Page 3: Table Of Contents
Safety information Introduction CBA 3G-100 introduction Unpacking and installation Unpacking Installation Operation Front panel Rear panel Specifications Warranty Adresses... -
Page 5: Safety Information
1 sAfety inforMAtion This apparatus has been designed and tested in accordance with BS EN 61010-1, and has been supplied in a safe condition. This manual contains some informa- tion warnings which must be followed to ensure safe operation, and to retain the apparatus in a safe condition. - Page 6 This apparatus must be disconnected from all voltage sources before it is opened for adjustment, replacement, maintenance or repair. Make sure that only fuses of the required rated current and of the specified type are used for replacement. The use of makeshift fuses and the short-circuiting of fuse holders is prohibited. CBA 3G-100...
-
Page 7: Introduction
2 introduction CBA 3G-100 introduction The CBA 3G-100 is an amplifier capable of supplying 100 W into a 50 ohm load over the frequency range 800 MHz to 3.1 GHz, during the course of EMC tests on electrical equipment. The amplifier is designed with sufficient gain such that it may be used with normal output levels of signal sources. - Page 8 Arcing due to high RF voltages present Always ensure that the output of the at the output connector. amplifier is terminated either by the system antenna or a suitable High power RF load or attenuator. CBA 3G-100...
-
Page 9: Unpacking And Installation
3 unpAckinG And instAllAtion 3.1 Unpacking The CBA 3G-100 package should contain: CBA 3G-100, 800 MHz to 3.1 GHz amplifier Power cable (UK) Power cable (USA / Japan) Power cable (Europe) Spare fuse T 10 A time delay 20 mm... -
Page 10: Operation
150 W. On no account operate the amplifier without a proper termination or with defective cables or connectors. The centre conductor of the RF output represents a severe burn hazard to personnel. CBA 3G-100... -
Page 11: Rear Panel
Air inlet The amplifier depends upon a free air supply for cooling. Ensure that the front air inlet is not restricted. 4.2 Rear panel Mains input The mains input is an IEC 60320 type. The cable attached to the mains input must be rated at 10 A to ensure proper operation at the minimum line voltage of 85 Vac. -
Page 12: Specifications
Harmonics at 90 W output Better than -20 dBc (80 MHz to 3 GHz) Output impedance 50 Ohms Stability Unconditional Output VSWR tolerance Infinity:1 Input VSWR RF Connector style Type N female Safety interlock BNC female, s/c to mute USB interface Optional CBA 3G-100... - Page 13 EMC and safety Conducted and radiated emissions EN 61326 class A Conducted and radiated immunity EN 61326: 1997 table 1 Mains harmonic currents EN 61000-3-2 Voltage fluctuations and flicker EN 61000-3-3 Safety EN 61010-1 Power Supply voltage (single phase) 90-264 Vac Supply frequency range 47-63 Hz Supply power...
-
Page 14: Warranty
All information in this manual is given in good faith. However, the company shall not be liable for any loss or damage whatsoever arising from the use of this manual, the product described in it or any errors or omissions in either. CBA 3G-100... - Page 15 notes...
-
Page 16: Adresses
Manufacturer Headquarters Teseq AG Teseq AG 4542 Luterbach, Switzerland 4542 Luterbach, Switzerland T + 41 32 681 40 40 T + 41 32 681 40 40 F + 41 32 681 40 48 F + 41 32 681 40 48 sales @ teseq.com sales @ teseq.com www.teseq.com...
