INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
CERTIFIED UNDER U.S. ENVIRONMENTAL PROTECTION AGENCY (E.P.A.) JULY 1990 40 C.F. R. PART 60 AND THE OREGON DEPARTMENT OF
ENVIRONMENTAL QUALITY (D.E.Q.) PARTICULATE EMISSION STANDARDS BY E.E.M.C THESE STOVES HAVE BEEN TESTED AND LISTED BY INTERTEK
S1, S4 & S9
PEDESTAL MODELS

SAFETY INFORMATION

WARNING
!
If the information in these instructions is not followed exactly, a
fi re or explosion may result causing property damage, personal
injury or death. Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage,
bodily injury or even death. Please read entire manual before
you install and use your appliance.
This appliance has not been tested with an unvented gas log
set. To reduce risk of fi re or injury, do not install an unvented
gas log set into the appliance.
- This appliance can be very hot when burning.
- Combustible materials such as fi rewood, wet clothing, etc. placed too
close can catch fi re.
- Children and pets must be kept from touching the appliance when it is hot.
- The chimney must be sound and free of cracks. Before installing this unit,
contact the local building or fi re authority and follow their guidelines.
- Operate only with the door tightly closed.
- Burn wood behind the log retainer directly on the fi rebricks.
- Do not use an elevated grate or otherwise raise the fi re.
- At least 14 square inches (90.3 square centimeters) of outside air must
be admitted to the room or directly to the unit through a 4" (101.6mm)
diameter pipe.
- This appliance is designed to burn natural wood only. Higher effi ciencies
and lower emissions generally result when burning air dried seasoned
hardwoods, as compared to softwoods or to green or freshly cut
hardwoods.
- Do not start a fi re with chemicals or fl uids such as gasoline, engine oil,
etc.
- Do not burn treated wood, coal, charcoal, colored paper, cardboard,
solvents or garbage.
- Do not let the appliance become hot enough for any part to glow red.
- KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C). Attempts to
achieve heat output rates that exceed design specifi cations can result in
steel distortion and damage.
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com
$10.00
OPERATING INSTRUCTIONS
TESTING SERVICES TO STANDARDS: CSA B366.2, ULC S627, UL 1482.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
!
WARNING
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
1.27B
W415-1226 / 06.27.13
EN
FR
PG
41

Advertisement

Table of Contents
loading

Summary of Contents for Napoleon S1

  • Page 1: Safety Information

    Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com $10.00...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INSTALLATION OVERVIEW INTRODUCTION DIMENSIONS SPECIFICATIONS GENERAL INSTRUCTIONS GENERAL INFORMATION RATING PLATE INFORMATION PRE-INSTALLATION PREPARATION APPLIANCE PLACEMENT CLEARANCE TO COMBUSTIBLES FLOOR PROTECTION OUTSIDE AIR INSTALLATION CHIMNEY 4.1.1 CHIMNEY CONNECTION 4.1.2 SECTIONS 4.1.3 TYPICAL THROUGH THE CEILING 4.1.4 TYPICAL THROUGH THE WALL 4.1.5 TYPICAL EXISTING MASONRY FINISHING...
  • Page 3: Installation Overview

    1.0 INSTALLATION OVERVIEW Rating plate, see “RATING PLATE INFORMATION ” section. Door, see “DOOR REMOVAL AND INSTALLATION” section. Blower, see “OPTIONAL BLOWER KIT INSTALLATION” section. Draft, see “AIR CONTROL” section. Handle, see “DOOR AND HANDLE INSTALLATION AND SERVICE” section. Ash drawer, see “ASH DRAWER ADJUSTMENT”...
  • Page 4: Introduction

    2.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND IS PROHIBITED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi...
  • Page 5: Dimensions

    7 1/4" DIMENSIONS 184mm Ø 6 " 152mm 32" 812mm 12 3/4" 324mm 25 1/2" 648mm 22” S1 ILLUSTRATED 559mm 7 1/4" Ø 6 " 184mm 152mm 32" 812mm 12 3/4" 324mm 26 1/2" 25 1/2" 673mm 648mm S4 ILLUSTRATED Ø...
  • Page 6: Specifications

    SPECIFICATIONS SPECIFICATIONS CAPACITY 1.7 ft (0.05m 2.25 ft (0.06m 3.0 ft (0.09m APPROX. AREA HEATED* 600-1500 ft 1000-2000 ft 1000-3500 ft (56-139m (93-186m (93-325m HEAT OUTPUT (HIGH BURN) ** 55,000 BTU 70,000 BTU 85,000 BTU DURATION LOW FIRE* 7 Hours 9 Hours 12 Hours WEIGHT w/o BRICKS...
  • Page 7: General Information

    GENERAL INFORMATION WARNING DO NOT OPERATE THIS APPLIANCE WITHOUT THE PEDESTAL INSTALLED. Your appliance has been specifi cally designed over many months of research to meet the 1990 U.S.A. EPA particulate emission standards and have been extensively tested in Canadian and American laboratories. This system is the most effi...
  • Page 8: Rating Plate Information

    U.S. Environmental Protection Agency Certified to comply with July 1990, particulate emissions standards/ Certifié conforme à la norme d’ émanation de particles de juillet 1990: 40 CFR Part 60, Subpart AAA DATE CODE / DE DATE WOLF STEEL LTD. EPA1400 24 NAPOLEON ROAD, BARRIE, ON, L4M 0G8 CANADA W385-1901 W415-1226 / 06.27.13...
  • Page 9: Pre-Installation Preparation

    3.0 PRE-INSTALLATION PREPARATION APPLIANCE PLACEMENT Have an authorized dealer install the appliance. If you install the appliance yourself, have your dealer review your installation plans and/or installation. Draw out a detailed plan of the installation including dimensions and verify the dimensions with the require- ments listed in this manual.
  • Page 10: Floor Protection

    FLOOR PROTECTION EMBER PROTECTOR: This appliance must be installed on a non-combustible protector that extends to the front, sides and back of the appliance as per the minimum requirements below. NOTE: Ember protection is required for spark and ash shielding, not for limiting fl oor temperatures from the radiant heat of the appliance.
  • Page 11: Installation

    4.0 INSTALLATION WARNING WEAR GLOVES AND SAFETY GLASSES FOR PROTECTION. CAREFULLY FOLLOW THE INSTRUCTIONS FOR ASSEMBLY OF THE PIPE AND OTHER PARTS NEEDED TO INSTALL THE APPLIANCE. FAILURE TO DO SO MAY RESULT IN A FIRE, ESPECIALLY IF COMBUSTIBLES ARE TOO CLOSE TO THE APPLIANCE OR CHIMNEY AND AIR SPACES ARE BLOCKED, PREVENTING THE FREE MOVEMENT OF COOLING AIR.
  • Page 12: Chimney

    CHIMNEY WARNING NEVER INSTALL A SINGLE WALL SLIP SECTION OR SMOKE PIPE IN A CHASE STRUCTURE. THE HIGHER TEMPERATURE OF THIS SINGLE WALL PIPE MAY RADIATE SUFFICIENT HEAT TO COMBUSTIBLE CHASE MATERIALS TO CAUSE FIRE. DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY SYSTEM SERVING ANOTHER APPLIANCE. TO AVOID DANGER OF FIRE, ALL INSTRUCTIONS MUST BE STRICTLY FOLLOWED, INCLUDING THE PROVISIONS OF AIR SPACE CLEARANCE BETWEEN CHIMNEY SYSTEM AND ENCLOSURE.
  • Page 13: Chimney Connection

    4.1.1 CHIMNEY CONNECTION Your chimney connector and chimney must have the same diameter as the appliance’s exhaust fl ue outlet. The appliance pipe must be made of aluminized or cold roll steel with a minimum 24 gauge (0.6mm) thickness. It is strictly forbidden to use galvanized steel.
  • Page 14: Sections

    4.1.2 SECTIONS Add chimney sections, according to the manufacturers installation instructions. The chimney must extend at least, 3 feet (0.9m) above its point of contact with the roof and at least 2 feet (0.6m) higher than any wall, roof, building or obstacle within 10 feet (3.1m) horizontally. LESS THAN 10 FEET (3.1m)
  • Page 15: Typical Through The Ceiling

    4.1.3 TYPICAL THROUGH THE CEILING Move the stove into position with the fl ue centered, midpoint between two joists to prevent having to cut them. Use a plumb bob to line up the center. Cut and frame an opening in the ceiling to provide a 2” (50.8mm) clearance between the outside of the chimney and any combustible material.
  • Page 16: Typical Through The Wall

    4.1.4 TYPICAL THROUGH THE WALL If possible, design the installation so that the connector does not pass through a combustible wall. If during your installation you must pass through a combustible wall, check with your building inspector before you begin. Also check with the chimney connector manufacturer for any specifi c requirements. Consult with your dealer regarding special connection components available for use for wall pass-throughs.
  • Page 17: Typical Existing Masonry

    4.1.5 TYPICAL EXISTING MASONRY You can also install your appliance using your existing masonry chimney. To do so, follow the guidelines below. Use a factory-built thimble, or construct your own brick thimble. If you are using a masonry chimney, it is important that it be built in compliance with the specifi...
  • Page 18: Finishing

    5.0 FINISHING DOOR REMOVAL / INSTALLATION Ensure to have a fi rm grip of the door at all times. NOTE: We recommend having two people perform this installation. Remove the bottom door hinge retainer by removing the screw, as shown below, then loosen the top door hinge retainer.
  • Page 19: Door And Handle Installation And Service

    DOOR AND HANDLE INSTALLATION AND SERVICE WARNING BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD THAT MAY RESULT IN A HOUSE AND OR CHIMNEY FIRE. DO NOT STRIKE OR SLAM DOOR. NEVER REMOVE THE DOOR WHEN THE APPLIANCE IS HOT. Remove the two screws securing the latch block to the door.
  • Page 20: Bricks And Baffle Installation

    BRICKS AND BAFFLE INSTALLATION WARNING OPERATION OF THE APPLIANCE WITHOUT THE BAFFLES CAN RESULT IN EXCESSIVE TEMPERATURES THAT COULD DAMAGE THE APPLIANCE, CHIMNEY AND THE SURROUNDING ENCLOSURE. With appliance and chimney installation completed, move the bricks into place for your appliance as illustrated.
  • Page 21 S1, S4 & S9 (All Firebricks are 1 1/4” (32mm) Thick) PART # PART # FIREBRICK FIREBRICK DIMENSIONS DIMENSIONS 4 1/2” x 9” W090-0001 W090-0001 W090-0015 2 1/4” x 9” W090-0018 W090-0018 W090-0018 (114mm x 229mm) (57mm x 229mm) 3” x 9” (Molded)
  • Page 22: Ash Drawer Adjustment

    ASH DRAWER ADJUSTMENT NOTE: If ash drawer adjustment is necessary there are adjustment areas located on the sides and bottom of the ash drawer, as illustrated below. Remove the ash drawer from the appliance by pressing the drawer disconnect lever down on the right side and upwards on the left side then pull the ash drawer out from the pedestal.
  • Page 23: Optional Kit Installations

    6.0 OPTIONAL KIT INSTALLATIONS BLOWER KIT INSTALLATION WARNING RISK OF FIRE AND ELECTRICAL SHOCK. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THIS APPLIANCE. USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
  • Page 24: Door Trim Kit

    DOOR TRIM KIT Open the door of the appliance. Remove the left side screw, holding the top door hinge retainer in place. Place one shim against the door, on the left side. Set the trim on the top of the door, align to the holes, and secure. TOP DOOR HINGE RETAINER DOOR TRIM...
  • Page 25: Operation

    7.0 OPERATION WARNING ALWAYS OPERATE THIS APPLIANCE WITH THE DOOR CLOSED AND LATCHED EXCEPT DURING START UP AND RE-FUELING. ALWAYS WEAR GLOVES TO PREVENT INJURY. DO NOT LEAVE THE FIRE UNATTENDED WHEN THE DOOR IS UNLATCHED AS UNSTABLE WOOD COULD FALL OUT OF THE FIRE CHAMBER CREATING A FIRE HAZARD TO YOUR HOME.
  • Page 26: Air Control

    You can now add larger pieces of wood and operate the appliance normally. Once the appliance is entirely hot, it will burn very effi ciently with little smoke from the chimney. There will be a bed of orange coals in the fi rebox and secondary fl...
  • Page 27: Lighting A Fire

    LIGHTING A FIRE 7.3.1 FLASH FIRE A fl ash fi re is a small fi re burned quickly when you don't need much heat. After your kindling has "caught", load at least 3 pieces of wood, stacked loosely. Burn with the draft control fully open or closed only slightly.
  • Page 28: Maintenance

    8.0 MAINTENANCE WARNING TURN OFF THE POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. Check your chimney and chimney connector for creosote and soot buildup weekly until a safe frequency for cleaning is established.
  • Page 29: Creosote Formation And Removal

    CREOSOTE FORMATION AND REMOVAL When wood is burned slowly, it produces tar and other organic vapors, which combine with expelled moisture to form creosote. The creosote vapors condense in the relatively cooler chimney fl ue of a slow-burning fi re. As a result, creosote residue accumulates on the fl...
  • Page 30: Chimney Cleaning

    CHIMNEY CLEANING Both the chimney and the appliance must be inspected and cleaned if necessary at least once a year. For serious wood burners, chimney cleaning must be done as needed to avoid chimney fi res; the venting systems for controlled combustion appliances may need cleaning as often as once a month. These rates, however, depend on the burning habits of the individual operating the appliance.
  • Page 31: Secondary Air Tube Replacement

    Remove the rear bricks, then remove the baffl e. Remove the 2 nuts and bolts securing the secondary air tube in place for the S1 and S4 and 4 nuts and bolts on the S9, refer to the illustration below.
  • Page 32: Care Of Glass

    CARE OF GLASS If the glass is not kept clean permanent discolouration and / or WARNING blemishes may result. Normally a hot fi re will clean the glass. The most common reasons for dirty glass include: not using HOT GLASS WILL suffi...
  • Page 33: Wood

    WOOD THIS APPLIANCE IS DESIGNED TO BURN NATURAL WOOD ONLY. DO NOT BURN TREATED WOOD, COAL, CHARCOAL, COLOURED PAPER, CARDBOARD, SOLVENTS OR GARBAGE. THIS APPLIANCE HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG SET. TO REDUCE RISK OF FIRE OR INJURY, DO NOT INSTALL AN UNVENTED GAS LOG SET INTO THE APPLIANCE.
  • Page 34: Replacements

    9.0 REPLACEMENTS Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. WARNING FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM. FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS When ordering replacement parts always give the following information:...
  • Page 35 ACCESSORIES REF # DESCRIPTION DTS4-SS DOOR TRIM EP65 BLOWER W415-1226 / 06.27.13...
  • Page 36: Troubleshooting

    10.0 TROUBLESHOOTING WARNING TURN OFF THE ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. WHEN CHECKING CONNECTIONS, INSTALLING JUMPER WIRES (FOR TEST PURPOSES ONLY) OR REPLACING COMPONENTS, UNPLUG HEATER FROM THE RECEPTACLE TO PREVENT ELECTRICAL SHOCK OR DAMAGE TO THE COMPONENT.
  • Page 37: Warranty

    All parts replaced under the President’s Limited Lifetime Warranty Policy are subject to a single claim. During the fi rst 10 years NAPOLEON® will replace or repair the defective parts covered by the lifetime warranty at our discretion free of charge. From 10 years to life, NAPOLEON®...
  • Page 38: Service History

    12.0 SERVICE HISTORY 43.1 W415-1226 / 06.27.13...
  • Page 39: Notes

    13.0 NOTES 44.1 W415-1226 / 06.27.13...
