Before commencing assembly please read these instructions thoroughly
Wing Span:28.7 in
Wing Area:310 sq in
Flying Weight:28.5 oz
Fuselage Length:42.7 in
Requires: Outrunner Motor and Ducted Fan Propulsion
3-cell power system recommendations: Outrunner Motor 28/31 (KM0283111), 30A (burst 35A) Brushless
4-cell power system recommendations: Turbo Outrunner Motor For Ducted Fan (KM0283120), 40A
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
.
www thewingsmaker com
GM034XMPO29431311
,
Specifications
Specifications
/
730 mm
/
20 sq dm
/
805 g
/
1085 mm
Unit (PL6800010), 4-channel "mixing radio" (elevator
and aileron) w/ 3 micro servos (SV2031), Brushless
ESC, Li-Po battery and charger
ESC, 3 cells 11.1V 20C 2100mAh Li-Po battery and charger
(burst 45A) Brushless ESC, 4 cells 14.8V 20C 2100mAh
Li-Po battery and charger
.
I NSTRUCTI ON M ANUAL
( GM034XM )
.
Advertisement
Table of Contents
Related Manuals for Wings Maker J-10B Fighter GM034XM
Summary of Contents for Wings Maker J-10B Fighter GM034XM
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA...
-
Page 2: Before You Begin
INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.10 SAFETY PRECAUTIONS P.10 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. - Page 3 Parts List 1.MAIN WING -- 1 pair 7. FUEL TUBE d2xD4x4mm -- 1 pc. HINGES -- 8 pcs STRAPER PL4112106 -- 1 pc. PLASTIC BRACKET 36.5x36.5x2mm -- 2 pcs FRONT LANDING GEAR Ø1.8x137mm -- 1 set FRONT WHEEL Ø23mm -- 1 pc. 2.SCREW PA1.7x8mm -- 8 pcs COLLAR Ø2.1mm w/ Set Screw -- 2 sets SERVO MOUNTING PANEL PL5310020 -- 1 pair...
-
Page 4: Aileron Servo
Main Wing Hinge Setting Hinge Plastic Bracket 2x36.5x36.5 Hinge Bottom View Bottom View Aileron Servo PA1.7x8mm Screw PA1.7x8mm Fuel Tube d2xD4x4mm Straper Clevis Pushrod Ø1.4x102mm Fuel Tube d2xD4x4mm Horn TWM PL8210010 CLEVIS WRENCH Bottom View Please choose either (02L & 02R) or (03L & 03R) or (04L & 04R) that suits your servo. GM034XMPO29431311... -
Page 5: Rudder Pushrod
Vertical Fin / Rudder Hinge Setting Hinge Hinge A=A' Completed Rudder Pushrod TWM PL8210010 CLEVIS WRENCH Clevis Pushrod Ø1.4x558mm Horn Fuel Tube Completed d2xD4x4mm GM034XMPO29431311... - Page 6 Ducted Fan Propulsion Unit with 28/31 Motor PM2.5x8mm Screw Make sure rotating motor casing is not in contact with wirings or anything. d3xD7mm Washer PM2x4mm HEAT SHRINK TUBE M3x6mm Optional Parts HEAT SHRINK TUBE D5x30mm Solder Ducted Fan Insulation Propulsion Unit PL6800010 Electric Wire Completed &...
- Page 7 Main Wing & Front Wing & Main Landing Gear & Missile PA2.3x8mm Screw Collar 2.6mm Aileron Servo Lead Carbon Fiber Tube Ø4x360mm Missile Missile Bottom View Collar Ø2.6mm Main Wheel Ø40mm PA2.3x8mm 1.5mm M3x3mm Landing Wire Straps Main Landing Gear Completed Bottom View GM034XMPO29431311...
-
Page 8: Front Wheel
Front Landing Gear Front Wheel Collar Ø2.1mm Front Landing Gear Ø23mm Ø1.8x137mm M3x3mm M3x3mm Collar Ø2.1mm Set Screw Set Screw Completed Bottom View Battery Tie Pushrod Ø1.2x106mm Steering Arm PL4112215 Top View Steering Arm PL4112215 M25x3mm Set Screw Collar Ø2.1mm Front Pushrod Linkage... -
Page 9: Radio Equipment
Radio Equipment Install and arrange the equipment as shown in the picture. Ducted Fan KP0011310 Solder Solder Battery KP0011210 Front Solder Solder Battery Tie Rudder Servo Battery Mat 2x50x150mm Battery Receiver Brushless ESC Completed Canopy Pilot Battery Cover Canopy Completed GM034XMPO29431311... - Page 10 Decals Top View Bottom View GM034XMPO29431311...
- Page 11 Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference. Rudder 15 mm 15 mm Ailerons/Elevator 18 mm 18 mm C.G. The ideal C.G. position is 101.6mm(4 in.)behind the leading edge measured at where the wing meets the fuselage.
-
Page 12: Optional Parts
Optional Parts ACCESSORIES) Ducted Fan Propulsion Unit without Motor Clevis Wrench Code No. Size Package Code No. Size Package PL6800010 1 set PL8210010 1 set Small Clevis Large Clevis Special tool for clevis installation. -Operating Voltage / Current : 12V / 30A (35A Burst) Suitable for standard and small -Thrust : Approx. - Page 13 THE WINGS MAKER GM034XMPO29431311...
