Summary of Contents for SAGEMCOM D770
- Page 1 D770 - D770A QUICK START GUIDE...
- Page 3 Dear customer, You have just acquired a new generation Sagemcom telephone. Thank you for placing your confidence in us. This device has been manufactured with the utmost care. This product follows a strategy of continuous development. We reserve the right to make changes, modifications and improvements without notice to the products described in this quick start guide.
-
Page 4: Recommendations And Safety Instructions
Only use the power unit supplied and connect it to Your D770/A has anti-skid pads that should leave no the electricity mains in accordance with the traces on your furniture and ensure stability. -
Page 5: Your Phone
Discover... Your phone The pack Check that you have the following items in your pack: D770 D770A base according to model, a rechargeable battery (type NiMH 2.4 V 600 mAh), a telephone connection cord, a mains power supply with connection cord, ... -
Page 6: The Base
The base Handset(s) Search / Pairing key. • Long press: pairing of handsets. • Short press: paging of handsets. Handset location. Indicator light. Indicator light operation: handset on line. Fixed - or - answering machine activated * New message(s) on your answering machine * - or - Accessing the answering machine menu from the Blinking... -
Page 7: The Handset
The handset 1 Loudspeaker 9 Microphone 10 Cancel / Intercom key: • back to the previous menu 2 Graphic screen • Correct the entry/ Cancel • Call an additional handset (from the standby screen) 3 Browser 11 "pick up" key 12 key 1 •... - Page 8 Browser To access the phone menu, press When choosing menus, press the up or the down the left the right of the browser. In the list of options, press the up or the down of the browser. From the standby screen: From the standby screen: Access to received call list...
-
Page 9: Connect The Base
Set-up... Connect the base Before making connections, please see the safety instructions at the start of the booklet. Take the telephone connection cord, click it into its socket and connect the other end of the cord to the telephone socket. Take the power adapter. -
Page 10: Handset Set-Up
Handset set-up 2.4V 2.4V 600mAh 600mAh Ni-MH Ni-MH Black wire Red wire Take the battery provided in the packaging. Insert the connector into its housing complying with the positions of the wires. Slide the battery pack into its housing. Fit the battery compartment cover to the handset. -
Page 11: Charging The Handset
Charging the handset Gently lower the handset onto the base charging blade.Contacts within the body of the blade ensure electrical contact with the handset. Slide the handset downwards. Perform a complete battery charging cycle. The battery charging icon moves to inform you that charging is in progress. The icon display stops moving when the batteries are charged. -
Page 12: The Handset Screen
The handset screen In standby mode or during use, your phone screen informs you of your phone’s current state through icons, and in particular: Status icons: Indicates your phone’s current state. Information field: • Standby screen :in the normal state, displays the name of the Handset 1 handset and the current time and date. -
Page 13: Browsing Through The Menus
Browsing through the menus The multifunction keys Your telephone has two multifunction keys which you can use in several ways: From the standby screen In a menu To access the telephone menu. To enter a menu, to validate an action in a menu. To return to the previous menu. - Page 14 Example To browse through menus, use the browser arrows and the two multifunction buttons: Press the key . The main menu is displayed on the screen. Press the up or down or the left or the right of the browser to scroll through the menus and access the desired menu.
- Page 15 Scroll through the menus to the Date & Time menu by pressing the up or down of the browser. Confirm your choice by pressing the key Scroll through the menus to the Set Time/Date menu by pressing the up or down of the browser.
-
Page 16: Locating Your Handset
Making and receiving When the battery charge icon is at calls... minimum, the hands-free function is not Managing a call available until the next charging cycle. Making a call Adjusting the volume ETHOD To increase the volume, press Dial your contact’s number. To decrease the volume, press If you make a mistake, press the key to... -
Page 17: Enabling/Disabling The Answering Machine
Erasing your outgoing message Specify the required information by confirming at each step with Greeting Go to the menu Answer Machine > Msg. Play OGM Answ & Record > > Listening and Recording Answer Only (D770A) During playback personal announcement used, press Enabling/disabling the answering Playing messages machine... -
Page 18: Menu Tree Structure
Menu tree structure Display Phonebook Alarm Handset Name Screensaver New Entry Alarm X Contrast Option Alarm On/Off Calling Number Time Settings Edit Entry Melody View Entry Date & Time Copy Entry Time Format Copy All Date Format Delete Entry Answer Machine Set Time/Date Delete All Play messages... -
Page 19: The Product
Environment Environmental protection and sustainable development is an important priority for Sagemcom. Sagemcom has a policy of using environmentally- friendly systems and makes environmental protection an essential part of the life-cycle of its products – from manufacturing, to installation, operation and disposal. -
Page 20: Terms And Conditions For United Kingdom & Ireland Only
Please make sure that you use your equipment only for the purpose for which it was designed and under normal usage conditions. Sagemcom do not accept any liability for the equipment if used outside the frame of its original designed purpose or any consequence that may arise from this usage. - Page 21 Usage of new versions of software without the previous approval of Sagemcom • Work on any equipment or software modified or added without the prior written consent of Sagemcom • Malfunctions not resulting from the Equipment or from software installed in user workstations for the purpose of use of the equipment.
- Page 22 In the cases set forth in B) as well as after expiry of the guarantee period, the customer must ask the Authorised Sagemcom Repair Centre for a cost estimation prior to work being carried out. In such cases, the repair and delivery costs will be invoiced to the customer.
- Page 24 Sagemcom Broadband SAS Headquarters: 250, route de l'Empereur 92848 Rueil-Malmaison Cedex - France Tel. +33(0)1 57 61 10 00 - Fax: +33(0)1 57 61 10 01 www.sagemcom.com...
