- Page 1 SAF CFOL Series Point-to-Point User Guide SAF Tehnika A/S 2009...
-
Page 2: Table Of Contents
SMTP Settings..................20 2.4.2.2 Maintenance................... 21 System Functions ..................21 2.5.1 Firmware Update ..................22 2.5.2 Device License..................23 2.5.3 Tools....................... 25 Antenna Alignment ................... 25 Site Survey .................... 25 Link Test ....................26 SAF Tehnika A/S Contacts ................28... - Page 3 User Guide SAF CFOL Series Point-to-Point User Guide SAF Tehnika point-to-point products are designed to provide superior performance at long range distances. With a proprietary wireless driver that was written for the sole purpose of optimizing wireless point to point links, one can achieve much higher throughput, especially at longer links, than standards based products.
-
Page 4: Status
System section displays the identification information of the point-to-point unit. The Wireless section presents main wireless settings. The Ethernet section describes the point-to-point unit's network identity and connectivity. The information in the page can be updated using Refresh button. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 5: System
Local IP - displays IP address of the local unit. Remote IP - displays IP address of the remote unit. The N/A will be displayed if there is no point-to-point link established. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 6: Wireless
Associating - displays amount of time the device was in associating state from the last reboot. Running - displays the time, expressed in hours, minutes and seconds since the system was last rebooted. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 7: Statistics
TX errors - displays the total number of sent corrupted packets by the Ethernet or Wireless interface of the point-to-point link. TX drops - displays the total number of dropped packets by the Ethernet or Wireless interface of the point-to-point link. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... - Page 8 RX packets - number of received data packets The number in brackets (+xx) displays the data change since the last page refresh. TX packets - number of transmitted data packets. The number in brackets (+xx) displays the data change since the last page refresh. “CFOL Series”, User Guide © SAF Tehnika A/S 2009...
-
Page 9: Graphs
To update statistics data click Refresh button. (!) Point the mouse cursor on the diagram line and you will get the numeric expression of the particular statistic. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... - Page 10 Traffic diagram displays Incoming and Outcoming traffic statistical data: RX/TX errors diagram displays statistical data of RX drop of the Local and Remote units, TX try of the Local and Remote units: “CFOL Series”, User Guide © SAF Tehnika A/S 2009...
- Page 11 User Guide Memory diagram displays memory usage data: CPU load diagram displays device CPU load in appropriate time basis: Frequency diagram displays device operating frequency in GHz: “CFOL Series”, User Guide © SAF Tehnika A/S 2009...
-
Page 12: Configuration
VLAN ID to access the network. All non-tagged traffic will be dropped, thus reducing the risk of unauthorized access. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 13: Radio
Frequency - specify frequency at which the point-to-point link will be operating. (!) The available Frequencies list varies depending on the selected Country and Channel width. Channel width - choose the channel width in MHz [5/10/20/40]. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 14: System
Aggregation limit, bytes - specify maximal packet count in bytes to be aggregated in one radio frame. Aggregation limit, packets - specify maximal packet count in packets to be aggregated in one radio frame. System 2.3.1 Link Settings “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 15: System Date
NTP server - specify the trusted NTP server IP or hostname for synchronizing time with [IP address]. To adjust the clock settings manually, choose the configuration mode as Manual and specify the following settings: “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 16: Administrative Account
The Administrative Account menu is for changing the administrator's password. Old password - enter the old administrator password. New password - enter the new administrator password for user authentication. Verify password - re-enter the new password to verify its accuracy. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 17: System Log
Message level - specify the message level you need to trace. The level determines the importance of the message and the volume of messages generated by the SAF AP. The levels are in order of increasing importance [emergency, alert, critical, error, warning, notice, information, debug]. -
Page 18: Oled Control
(manager and agent). Enable SNMP - specify the SNMP service status. Name - displays an administratively assigned name. This System location - specify the physical location of the point-to-point unit [string]. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 19: System Alerts
System check intervals - specify interval in seconds at which the device will send notifications of unexpected system behavior. System alerts: Wireless link status change - system will send notification on Wireless link status change. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 20: Snmp Traps Settings
E-mail notification interval - specify interval in seconds at which the e-mail notification will be send from the point-to-point unit [0-86400]. If 0 specified, then device will send an e-mail notification immediately after unexpected system behavior. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 21: Maintenance
View system log - click to view current trace messages. The Syslog viewer utility provides debug information for system services and protocols should a malfunction occur. The syslog capability can help operators to locate misconfiguration and system errors. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 22: Firmware Update
Maintenance menu, select the firmware file and click the Upload button: Current version - displays version of the current firmware. Upload - click the button to select the new image and upload new firmware on the device. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 23: Device License
When the device is installed and ready for use, the valid license file should be uploaded on the device to activate a full set of the device features. The license status is displayed on the device System Information page: “CFOL Series”, User Guide © SAF Tehnika A/S 2009... - Page 24 Thus only a default setting will be used after the reboot. To manage the license file, use the Configuration | Maintenance menu: License status - displays the validity status of current license. “CFOL Series”, User Guide © SAF Tehnika A/S 2009...
-
Page 25: Tools
The Antenna Alignment test results appear when you click the Start button, and finishes when you click Stop button. Site Survey The Site Survey test shows overview information for wireless networks in a local geographic area. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... -
Page 26: Link Test
Link test can be run from either the Remote unit or Local unit. Results represent the maximum, minimum and average value of the performed test. “CFOL Series”, User Guide © SAF Tehnika A/S 2009... - Page 27 Packet sizes - specify packet sizes in bytes at which the test will be performed. Start - click to start the throughput test. Stop - click to stop the throughput test. “CFOL Series”, User Guide © SAF Tehnika A/S 2009...
-
Page 28: Saf Tehnika A/S Contacts
SAF Tehnika A/S contacts 4. SAF Tehnika A/S Contacts The most up to date contacts of SAF Tehnika A/S can be found on the web site www.saftehnika.com. SAF Tehnika A/S technical support could be reached at: Email: techsupport@saftehnika.com Telephone: +371 67046840...
