DX Air Curtain
Installation and Owner's manual
Model name:
RAV-CT100/150/200/250BH-M/L
RAV-CT100/150/200/250CH-M/L
RAV-CT100/150/200/250UH-M/L
UK) Ltd.
DX Air Curtain Built-in (Medium / Large)
DX Air Curtain Free-Hanging (Medium / Large)
DX Air Curtain Cassette (Medium / Large)
For commercial use
ENGLISH
Advertisement
Related Manuals for Toshiba RAV-CT100/150/200/250BH-M/L
Summary of Contents for Toshiba RAV-CT100/150/200/250BH-M/L
- Page 1 Carrier ( UK) Ltd. DX Air Curtain Installation and Owner's manual For commercial use Model name: RAV-CT100/150/200/250BH-M/L DX Air Curtain Built-in (Medium / Large) RAV-CT100/150/200/250CH-M/L DX Air Curtain Free-Hanging (Medium / Large) RAV-CT100/150/200/250UH-M/L DX Air Curtain Cassette (Medium / Large)
- Page 2 DX Air Curtain Owner OWNER'S: PRECAUTIONS FOR SAFETY WARNING WARNINGS ABOUT INSTALLATION Make sure to ask the qualified installation professional in electric work to install the air conditioner. If the air conditioner is inappropriate installed by yourself, it may cause water leak, electric shock, fire, and so on. Be sure to connect earth wire.
- Page 3 DX Air Curtain Owner CAUTION TO DISCONNECT THE APPLIANCE FROM THE MAINS SUPPLY This appliance must be connected to the mains by means of a switch with a contact separation of at least 3 mm. The installation fuse 40A, 25A or 16A must be used for the power supply line of this air conditioner. CAUTIONS ABOUT INSTALLATION (Be sure to confirm the following cautions.) Use an exclusive power circuit for the air conditioner.
- Page 4 DX Air Curtain Owner No function display SETTING display Displayed if there is no function even if the Displayed during setup of the timer etc. button is pushed. Air volume select display Operation mode select display The selected air volume mode is displayed. The selected operation mode is displayed.
-
Page 5: Operation Section
DX Air Curtain Owner Operation section Push each button to select a desired operation. The details of the operation needs to be set up once, afterwards, the air conditioner can be used by pushing button only. button (Air volume select button) button Selects the desired air volume mode. - Page 6 DX Air Curtain Owner OWNER'S: CORRECT USAGE When you use the air conditioner for the first time or when you change the SET DATA value, follow the procedure below. From the next time, the operation displayed on the remote controller will start by pushing the button only.
- Page 7 (Heating), in summer inwards (Fan Only). The airstreams then needs to be adjusted in a way that the air stream reaches the ground at room temperature. 7 Winter CEILING Outlet Grille Angled Outwards TOSHIBA Air Curtain HEATING Air Conditioning (HEATING) Air Conditioning HEATING...
-
Page 8: Timer Operation
DX Air Curtain Owner OWNER'S: TIMER OPERATION A type of timer operation can be selected from the following three types. (Setting of up to 168hours is enabled.) OFF timer: The operation stops when the time of timer has reached the set time. Repeat OFF timer: Every time, the operation stops after the set time has passed. - Page 9 Owner DX Air Curtain OWNER'S: MAINTENANCE WARNING Cleaning of the air filter and other parts of the air filter involves dangerous work in high places, so be sure to have a service person do it. Do not attempt it yourself. Cleaning of air filters Clogging of air filters will reduce the cooling and heating performance.
- Page 10 Owner DX Air Curtain NOTE x For environmental conservation, it is strongly recommended that the indoor and outdoor units of the air conditioner in use be cleaned and maintained regularly to ensure efficient operation of the air conditioner. When the air conditioner is operated for a long time, periodic maintenance (once a year) is recommended. Furthermore, regularly check the outdoor unit for rust and scratches, and remove them or apply rustproof treatment, if necessary.
- Page 11 Owner DX Air Curtain OWNER'S: AIR CONDITIONER OPERATIONS AND PERFORMANCE 3 minutes protection function 3-minutes protection function prevents the air conditioner from starting for initial 3 minutes after the main power switch/circuit breaker is turned on for re-starting the air conditioner. Power failure Power failure during operation will stop the unit completely.
