L.B. White Therma Grow HW220 Owner's Manual And Instructions

Greenhouse heater
Hide thumbs Also See for Therma Grow HW220:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual and Instructions
Owner's Manual and Instructions
Greenhouse Heaters
Therma Grow
™
MODELS
OUTPUT (Btuh)
FUEL
Available in either
HW220
220,000
L.P. Gas Vapor
Withdrawal or
Natural Gas
Configurations.
Congratulations!
You have purchased the finest agricultural building heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and
welcome any suggestions or comments you may have...call us, toll-free,
at (800) 345-7200.
ATTENTION ALL USERS
This heater has been tested and evaluated by C.S.A. International, in
accordance with IAS U.S. Requirements for Gas-Fired Greenhouse Heaters,
for use as a direct gas-fired circulating heater for the heating of greenhouses.
If you are considering using this product for any application other than its
intended use, then please contact your fuel gas supplier, or the L.B. White
Co., Inc.
150-27595
