Family inada chair i.1 HCP-i1 A Operating Manual

Hide thumbs

Table Of Contents

Quick Links

Specifications

Product name and model number

inada chair i.1 HCP-i1 A

Power

AC120V

Power consumption

210W

Frequency

60Hz

Rated time

30 minutes

Kneading speed

6 levels: Min. approx. 17 times/min. Max. approx. 38 times/min

Tapping speed

4 levels: Min. approx. 311 times/min. Max. approx. 615 times/min

Width between the right and left rollers

3 levels (narrow, medium, wide)

Vertical traveling speed

Approx. 21 seconds for 1 round

Traveling distance

Approx. 23 inches (in the case of Partial rollers, automatic repetition will be performed in the range of approx. 6 inches)

Automatic programs

5 Health programs / 3 Well-Being programs (with Automatic Massage Points Detecting function)

Manual selection

10 Upper body modes / 3 Lower body modes

Lower body massage

Air pressure High: approx. 31 kPa Medium: approx. 26 kPa Low: approx. 21 kPa

Auto timer

Approx. 15 minutes (varies in the case of Automatic Programs)

Vibration function

Back Seat 2types toggle between High and Low

Position of footrest

Adjustable range: approx. 4 inches

Reclining

Power recline to any position between about 120 and 170 degrees.

Chair dimension

Width approx. 29 inches/Depth approx. 47(68) inches/Height approx. 45(29) inches

Weight

Approx. 167 lbs

Upholstery

PU Synthetic leather (specially processed treated for anti-bacteria and anti-contamination)

Accessories

Remote control stand

Number of manufacturing permit

31BZ0017

(medical tools)(Japan)

Technical Assistance

For technical assistance in the USA and Canada, you can reach us by calling our toll free number: 888.769.0555.

The direct dial number is 303.317.4356

We welcome comments and feedback about your buying experience and your experience in your INADA chair.

We invite you to email us at info@inada.com.

We hope you enjoy your new, world-class massage experience!

Massage points detected automatically

* ( ) shows the value at maximum recline

when footrest is horizontal

776932500

Please read this Operating Manual before use.

Keep this manual nearby so that you can refer to it anytime.

by optical sensors.

Massage program adapts

to your body size and purposes

for use.

Table of Contents

Need help?

Do you have a question about the inada chair i.1 HCP-i1 A and is the answer not in the manual?

Questions and answers

Summary of Contents for Family inada chair i.1 HCP-i1 A

Page 1: Specifications
Specifications Product name and model number inada chair i.1 HCP-i1 A Power AC120V Power consumption 210W Frequency 60Hz Rated time 30 minutes Kneading speed 6 levels: Min. approx. 17 times/min. Max. approx. 38 times/min Tapping speed 4 levels: Min. approx. 311 times/min. Max. approx. 615 times/min...
Page 2: Table Of Contents
Features And Benefits Greetings Features Thank you for purchasing the inada chair i.1. Provides a hybrid massage Equipped with a vibrator for The inada chair i.1 that you have purchased is the culmination of the best of our efforts. We have conceived function using roller pressure massaging your back and seat.
Page 3: Safety Precautions
Safety Precautions Be sure that you have read these SAFETY PRECAUTIONS thoroughly before using your inada chair i-1 for the first time. The Operating Safety Precautions: Before Use Manual contains important information about how to use the chair safely and correctly, avoiding possible damage to property or injury to Warning persons using the chair and others.
Page 4 Safety Precautions Safety Precautions: During Use Safety Precautions: During Use Warning Caution Do not wrap the power cord or the remote control cord around the chair, or place the chair on top of either cord. Do If there is a power outage or the possibility of a power outage, stop the chair immediately and set the main POWER switch to OFF.
Page 5: Parts Descriptions
Parts Descriptions ● Headrest ●Displays the current Power switch operation using text Massage roller/vibration Liquid crystal You can turn the power on or graphics. (in the backrest) and off using the remote ●For details of the display (small) control. If this switch is display, see page 17 Displays the operation being pushed during operation, the...
Page 6: Before Use
Before Use ●This chair is delivered with the backrest folded down. How to sit on the chair Before use, raise the backrest until a click is heard. Make sure that the footrest has been lowered completely. Normally the massage rollers stay at the upper part of the backrest, drawn Space requirements How to fold down the backrest back and apart from each other, being separated into left and right positions.
Page 7: Massage Types And Features
Massage Types And Features Automatic Programs /Massage Types ●The chair can be operated in a variety of Automatic Programs FULLBODY RELIEF 1 automatic modes for pre-programmed massage operations, and manual modes called Manual ●inada chair i.1 allows you to select your desired Automatic Program massage. Relaxes the muscles that affect your whole body and ●There are five different Healthcare programs, and three Well-Being programs.
Page 8 Automatic Programs /Operation Press Power The function for You can now switch. automatically fine-tune the detecting shoulder massage points position will start. (massage points). The display will be lit. To select an automatic Massage points will be detected during a once- program, close the external panel on the through operation of the rollers (a beeping Massage will...
Page 9 Manual Selection Modes /Liquid Crystal Display·Explanation Of Movements Manual Selection Modes Liquid Crystal Display [Manual selection mode operation] The Liquid Crystal Display displays the selected course, speed, You can select from the following functions: Kneading, Human Hands, Double-kneading, kneading&Tapping, Rhythm Acupressure (1 intensity, width, rotation, reverse rotation, and vertical position in words and 2), Tapping (1 and 2) and Rolling (Partial and Whole massage), lower body air massage, or you can make any combination of for 3 seconds and then displays the relevant icons.
Page 10 Manual Selection Modes /Operation Table showing the massage types which can be combined and the items which are adjustable. Press Power The operation will You can select the desired massage type from the massage menu from 1 to 5. You can also make combinations among them. switch.
Page 11: Cleaning And Storage
Cleaning And Storage ain parts Storage Cleaning ●Store the chair in a dry area after cleaning ●Plastic parts, pipes, and fabric should be cleaned by wiping with a mild detergent and a damp cloth. Wipe Before any cleaning is carried out, make sure with a dry cloth to dry the chair surface.
Page 12: Troubleshooting Guide
Troubleshooting Guide Service Please refer to the following Q&As How can I decrease the The right and left rollers are for checking your chair before Service level of stimulation? not positioned Maximum approx.0.6 inches calling for service. If this does not horizontally.
