GTO Driveway Alert
Kit Includes:
• Transmitter
• Receiver
• Two Size C batteries.
• GTO Driveway Alert installation manual for general installation guidance.
Thank you for purchasing the GTO Driveway Alert. Please read the directions carefully and completely before installing.
How it works:
The Transmitter:
The Operating Voltage for the Transmitter is 3V from two batteries (LR14C 1.5V) inside the Transmitter.
There is no Power Switch for this unit. Once the batteries are installed, the unit starts to function.
The Receiver:
The Receiver is powered by external Power Adaptor ( AC120V 60Hz / DC 12V 100 mA). A rotary switch controls
the alert buzzer's volume on the receiver. There are three LEDs on the front Panel of cabinet, representing Power
(red), Visitor Alert (green) and Low Battery (red). A "RESET" button in black on Front Panel is used to clear the
alert LED after it registered passing vehicles.
For more information on GTO's full line of automatic gate openers and access controls visit our website at www.gtoaccess.com
I N S T A L L A T I O N M A N U A L
Transmitter
ACCESS
SYSTEMS
Receiver
Rev. 01/29/08 • Printed in China for GTO, Inc.
Advertisement
Table of Contents
Related Manuals for GTO Driveway Alert
Summary of Contents for GTO Driveway Alert
- Page 1 Thank you for purchasing the GTO Driveway Alert. Please read the directions carefully and completely before installing. How it works: The Transmitter: The Operating Voltage for the Transmitter is 3V from two batteries (LR14C 1.5V) inside the Transmitter. There is no Power Switch for this unit. Once the batteries are installed, the unit starts to function. The Receiver: The Receiver is powered by external Power Adaptor ( AC120V 60Hz / DC 12V 100 mA). A rotary switch controls the alert buzzer’s volume on the receiver. There are three LEDs on the front Panel of cabinet, representing Power (red), Visitor Alert (green) and Low Battery (red). A “RESET” button in black on Front Panel is used to clear the alert LED after it registered passing vehicles. For more information on GTO's full line of automatic gate openers and access controls visit our website at www.gtoaccess.com Rev. 01/29/08 • Printed in China for GTO, Inc.
- Page 2 Installation Overview Driveway TRANSMITTER/ SENSOR: Next to driveway and 18 inches above surface Correct placement maximizes range Above is a typical location that a transmitter would be placed in order to be effective for the application. NOTE: Place the transmitter immediately next to the driveway to maximize the range.
- Page 3 System Operation Receiver Operation • After the Receiver is connected to the Power through the external Power Adaptor, the Power LED on Front Panel will light up, and there will be a confirmation “Beep” tone. Receiver Transmitter/Sensor Driveway Next To Driveway Transmitter Operation • The Transmitter is placed immediately next to the driveway, so it can maximally cover the driveway condition. When a car passes in front of the Transmitter, a string of data is transmitted to its Receiver by means of 433MHz Carrier Frequency. It is of Amplitude Shift Keying (ASK) type. After receiving the data, the Buzzer would give “Beep” twice, and the Visit Alert LED (green) would flash 3 times and remain lit up, until the RESET button is pressed. When the Low Battery LED (red) lights up, the 2x C sized batteries in the transmitter should be replaced ASAP . Low Battery LED Receiver D r i v e w a y A l e r t...
- Page 4 Limited One Year Warranty GTO, Inc., gate openers and accessories are covered under warranty by the manufacturer against defects in materials and manufacturer workmanship for a period of one (1) year from date of purchase, provided the recommended installation procedures have been followed. In the case of product failure due to defective material or manufacturer workmanship within the one (1) year warranty period, the product will be repaired or replaced (at the manufacturer’s option) at no charge to the customer, if returned freight prepaid to GTO, Inc., 3121 Hartsfield Road, Tallahassee, Florida, USA 32303. IMPORTANT: Call (800) 543-1236 for a Return Goods Authorization (RGA) number before returning accessory to factory. Products received at the factory without an RGA number will not be accepted. Replacement or repaired parts are covered by this warranty for the remainder of the one (1) year warranty period or six (6) months, whichever is greater. GTO, Inc. will pay the shipping charges (equal to United Parcel Service GROUND rate) for return to the owner of items repaired under warranty. The manufacturer will not be responsible for any charges or damages incurred in the removal of the defective parts for repair, or for the reinstallation of those parts after repair. This warranty shall be considered void if damage to the product(s) was due to improper installation or use, connection to an improper power source, or if damage was caused by lightning, wind, fire, flood, insects or other natural agent.
