- Page 1 DCT-511 DCR-511 2.4G DIGITAL TWO-WAY TOUR GUIDE SYSTEM OPERATION MANUAL ISO 9001:2008 R EG ISTER ED IS O 140 01 ISO 14001 R EG ISTER ED O H S A S 180 01 OHSAS 18001 Green Product...
- Page 2 DCT-511 Mini transmitter Parts and functions 1. Antenna 2. Mute 3. Volume control 4. Power/frequency synchronizing 5. MIC-MIX-AUX IN mode switch 6. Aux input(Ø 3.5mm) 7. Power indicator 8. Mute indicator 9. Earphone jack (Ø 3.5mm) 10. Mini USB charging port 7 8 9 11.
- Page 3 ISO 9001｜ISO 14001｜OHSAS 18001 DCR-511 Mini receiver Parts and functions 1. Antenna 2. Press to talk 3. Volume control 4. Power/frequency synchronizing 5. Power indicator 6. Reception indicator 7. Earphone jack (Ø 3.5mm) 8. Mini USB charging port 9. Reset 5 6 7 Instructions 1.
- Page 4 Both mute and reception indicators will glow green after the setting is completed. 5. DCT-511’s mute indicator will stop flashing after a setting period of about twelve seconds. 6. DCR-511’s reception indicator will stop flashing after a setting period of about twelve seconds.
- Page 5 ISO 9001｜ISO 14001｜OHSAS 18001 LED status of DCT-511 Part LED Function Antenna Signal transmission MUTE button Muting ON / OFF Volume Control +- Loudness Power / Synchronization Power ON / Off or Synchronization MODE switch MIC – MIX – AUX IN position switch AUX IN AUX IN (3.5mm)
- Page 6 2. When power is ON, Press power button of receiver for about 3 second During charging RED goes off Battery is fully charged Before synchronization Transmitter DCT-511 Action Power LED Indication (next to antenna) Press transmitter POWER 1. RED 1. Battery weak, not ok for button...
- Page 7 During Synchronization Synchronization indicator LEDs to watch: Transmitter MUTE indicator LED (next to Earphone IN) Receiver Reception indicator LED (next to Earphone IN) Action Indication Press transmitter DCT-511 MUTE indicator flashes Transmitter is ready for power button for 5 GREEN synchronization...
- Page 8 (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan｜Tel:886-2-27415741｜Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan｜Tel:886-5-2711000｜Fax:886-5-5767611...
