Page 1: Operation Manual
DCT-611 / DCR-611 Operation manual 2.4G digital two-way tour guide system CHIAYO ELECTRONICS CO., LTD. - Page 2 DCT-611 / DCR-611 2.4G digital two-way tour guide system DCT-611 Mini transmitter 8 9 10 1. Antenna 2. 2-way talking ON/OFF button 3. Volume control 4. Power/frequency synchronizing 5. Clip 6. MIC-MIX-AUX IN mode switch 7. Aux input(Ø 3.5mm) 8. Power indicator 9.
- Page 3 Instructions Instructions Power ON/OFF To turn on the transmitter, press the power button for one second. To turn off the transmitter, press and hold the power button for about 3 seconds. Power indicator Power on: Steady GREEN. ...
- Page 4 DCT-611 / DCR-611 2.4G digital two-way tour guide system DCR-611 Mini receiver 6 7 8 1. Antenna 2. Press-to-talk button 3. Volume control 4. Power/frequency synchronizing 5. Clip 6. Power indicator 7. Reception indicator 8. Earphone jack (Ø 3.5mm) 9. Mini USB charging port...
- Page 5 Press this button to talk with your guide and the conversation could be heard by other members. And release to stop. When DCT-611 disables 2-way talking, the reception indicator will be steady RED and conversation is unavailable until DCT-611 enables it.
- Page 6 Frequency synchronizing isn’t workable if the power is weak with indicator glowing RED. To begin the synchronization, press DCT-611’s power button for five seconds till the mute indicator flashes green, which implies readiness to synchronize.
- Page 7 The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Frequency: 2400~2483.5MHz , Maximal power: 8 mW CE declaration info: www.chiayo.com.tw/declaration.html...
- Page 8 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw ｜ Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 ｜ Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 ｜ Fax: 886-5-5767611 12I1476...
