- Page 1 DCT-511 DCR-511 2.4G DIGITAL TWO-WAY TOUR GUIDE SYSTEM OPERATION MANUAL ISO 9001:2008 REGISTERED INTERNATIONAL 14001 ISO 14001 REGISTERED INTERNATIONAL OHSAS 18001 OHSAS 18001 Green Product...
- Page 2 DCT-511 Mini transmitter Parts and functions 1. Antenna 2. Mute button 3. Volume control 4. Power/pairing button 5. MIC-MIX-AUX IN mode switch 6. Aux input(Ø 3.5mm) 7. Power indicator 8. Mute indicator 9. Earphone jack (Ø 3.5mm) 10. Mini USB charging port 7 8 9 11.
- Page 3 ISO 9001｜ISO 14001｜OHSAS 18001 External audio input To add music as background music, just input your audio signal to AUX IN In a museum tour, ►MP3/MP4 player you may also input the respective prerecorded introductions for various galleries. Audio mode switch 1.
- Page 4 DCR-511 Mini receiver Parts and functions 1. Antenna 2. Press to talk 3. Volume control 4. Power/frequency synchronizing 5. Power indicator 6. Reception indicator 7. Earphone jack (Ø 3.5mm) 8. Mini USB charging port 9. Reset 5 6 7 Turning on the receiver 1.
- Page 5 ISO 9001｜ISO 14001｜OHSAS 18001 Press to talk Press the talk button to talk with your guide and the conversation could be heard by other < 25cm members. And release to stop. Reception indicator The LED stays green within the reception GREEN : signal OK range from the tour guide.
- Page 6 2. Press DCT-511’s power 1. Turn off DCT-511 and 3. The mute indicator DCR-511 button for 5 seconds flashes green to imply readiness to pair.
- Page 7 ISO 9001｜ISO 14001｜OHSAS 18001 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 8 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan｜Tel:886-2-27415741｜Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan｜Tel:886-5-2711000｜Fax:886-5-5767611...
