Whirlpool Europe S E R V I C E AWG 273 WH-F Customer Services Service Manual SECHE-LINGE A EVACUATION AWG 273 WH-F MODELE AWG 273 WH-F VERSION 8537 273 29010 Page DONNEES TECHNIQUES LISTE DE PIECES VUE ECLATEE 4 - 7...
08.01.1997 / Page 2 Whirlpool Europe S E R V I C E Doc. No: 4812 713 10984 Customer Service DONNEES TECHNIQUES DIMENSIONS MOTEUR HAUTEUR 85,0 ASYNCHRONE 4 POLES AVEC ROTATION DANS LES DEUX SENS LARGEUR 59,6 AVEC PROTECTEUR THERMIQUE 130 ˚C...
Whirlpool Europe 08.01.1997 / Page 3 S E R V I C E Customer Service Doc. No: 4812 713 10984 LISTE DE PIECES Model AWG 273 WH-F Service No. 853727329010 Version 853727329010 Pos. No. 12NC Code Description Pos. No. 12NC Code...
08.01.1997 / Page 8 Whirlpool Europe S E R V I C E Doc. No: 4812 713 10984 Customer Service SCHEMA DE CABLAGE Programmateur NOIR Bornier MARRON Câble d’alimentation ROUGE Connecteur ORANGE Condensateur JAUNE Moteur VERT Elément chauffant BLEU MRTL Thermostat réarmable...
