Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
This 9.6V cordless driver drill is the sister version of the
existing Model 6095D and more efficient for light work than
Model 6095D.
(ex.driving 1-5/8" drywall screw,drilling small hole)
Its brief benefits are;
*Compact design
*Light weight
*Equipped with electric brake
Model Battery
6096DW 9000(Ni-Cd)
6096DWE 9000(Ni-Cd)X2
6096DWBE 9033(Ni-MH)X2
S
pecifications
Motor
Battery
No load speed
Chuck capacity
Max.drilling
capacities
Max.driving capacity
Max.fastening
torque (drill-mode) High speed 4N-m(40Kgf-cm)(2.9ft-lbs)
Net weight
S
tandard equipment
Philips Bit 2-45 ------------------- 1 pc. (manufactured in U.K.)
+- Bit 2 45 ------------------------- 1 pc. (manufactured in U.S.A.)
Battery Cover --------------------- 1 pc.
Plastic Carrying Case ------------ 1 pc.
<Note>The standard equipment may differ from country to country.
O
ptional accessories
Drill Bit 1.5,2,3,4,5,6
Philips Bit 1-65,2-45,2-65,2-110,2-150,2-250,3-45,3-65,3-110
Slotted Bit 5-45,5-82,6-70,6.35-45, 8-45,8-70
Socket Bit 7-55,8-55,10-55
Foam Polishing Pad 125
Battery 9000, 9033, 9002
Fast Charger DCl411, DC1209, DC9700, DC9701
Fast Automotive Charger DC1412
F
eatures and benefits
See the attached sheets for more information.
The standard equipment for the tools shown may differ form country to country
6096D
Cordless Driver Drill
Fast Charger
DC9700
DC9700(DC9700A)
DC9701
DC 9.6V magnet motor
Battery 9000 (Ni-Cd,9.6V,1.3Ah)
Battery 9033 (Ni-MH,9.6V,2.2Ah)
High:0 - 1100rpm Low:0-350rpm
0.8mm(1/32") - 10mm(3/8")
Steel 10mm(3/8")
18mm(11/16")
Wood
5.5mm(7/32")X55mm(2-3/16")
Low speed 12N-m(120kgf-cm)(8.7ft-lbs)
1.3Kg(2.9lbs)
Rubber Pad Assembly
Drill Bit for wood 9,12,15
Wool Bonnet 100
New Tool
210mm (8-1/4")
