Specifications & Capacities
Box Scrapers
Working Width
Capacity
Weight
Weight (with hydraulics)
Number of Shanks
Shank Material
Shank Penetration
Shank Tip Construction
Shank Beam
Lift Mechanism
Moldboard
Side Panels
Depth of Bucket
Cutting Blades
Maximum H.P. Rating
3-Point Hitch Construction
3-Point Hitch Type
Designs, specifications, features and information are subject to change without notice.
29
HR35 & HRL35 Series (Retractable)
19" Lowback
HRL3578
78"
26 cu. ft.
972 lbs.
981 lbs.
8
3/4" x 2 1/2" heat treated spring steel
3- positions (1", 3" & 5" below scraper end plates)
Replaceable heat treated dimpled-on tips
Pivots to lift shanks up; transport lock on shank tube
Roll-Formed Moldboard -17"
1/2" thick x 19" high x 30" deep
28"
2 ea. 1/2" x 6" high carbon, heat treated cutting edges; reversible and replaceable
Harden bushings in upper and lower hitch points
MRL3572 Not Shown
24" Highback
Hydraulic cylinder
Roll-Formed Moldboard - 23"
1/2" thick x 24" high x 30" deep
65 HP
Category l & II
HR3584
84"
31 cu. ft.
1117 lbs.
1119 lbs.
8
27 1/2"
26995
7/26/10
305-054S
