Summary of Contents for Torrot KidsE10
- Page 1 User Manual Maintenance+Warranty V1 012015...
- Page 3 S10 for young riders! In this manual you will find information about how to use and how to do the maintenance of your KIDS. You will also find information about the Torrot Electric’s two years warranty that your new motorcycle has.
- Page 4 KIDS 2 YEARS YOUNG POWER FROM BRUSHLESS BRAKE DISCS LITHIUM SCHOOL MAPPING TORROT ELECTRIC 350 TO 1050W GEARED 48V BATTERY ELECTRIC MOTOR WARRANTY...
-
Page 5: Table Of Contents
User Manual INTRODUCTION Table of THE KIDS contents SPECIFICATIONS COMPONENTS CONTROLS BEFORE USING IT MAINTENANCE BATTERY RECHARGE FAIRING REMOVAL BATTERY REMOVAL ECU MAPPING WIRING DIAGRAM WARRANTY DEALERS KIDS... -
Page 6: Introduction
From Torrot Electric, we insistently advise you to use always a helmet and the proper protection equipment to have a satisfactory, funny and 100% secure experience. -
Page 7: The Kids
This trial motorbike can turn into a E10 off-road motorbike with the special kit. Take it into account! The enduro electric motorbike of Torrot Electric has no rivals. Devilishly beautiful, they will delight any child (and so do their parents), because of... -
Page 8: Specifications
User Manual SPECIFICATIONS E10 SPECIFICATIONS CHASSIS TUBULAR CrMo STEEL FRAME FRONT SUSPENSION EBR HYDRAULIC FORK REAR SUSPENSION STEEL SWING ARM – 100mm SHOCK ABSORBER HANDLEBAR WIDTH 580mm BRAKES NIFO FRONT/REAR DISC BRAKES TRANSMISSION CHAIN MOTOR BRUSHLESS GEARED 48V POWER 350W-1050W / TOP SPEED 40KM/H CLUTCH ELECTRONIC BATTERY... - Page 9 User Manual SPECIFICATIONS T10 SPECIFICATIONS CHASSIS TUBULAR CrMo STEEL FRAME FRONT SUSPENSION EBR HYDRAULIC FORK REAR SUSPENSION STEEL SWING ARM – 100mm SHOCK ABSORBER HANDLEBAR WIDTH 580mm BRAKES NIFO FRONT/REAR DISC BRAKES TRANSMISSION CHAIN MOTOR BRUSHLESS GEARED 48V POWER 350W-1050W / TOP SPEED 40KM/H CLUTCH ELECTRONIC BATTERY...
- Page 10 User Manual SPECIFICATIONS S10 SPECIFICATIONS CHASSIS TUBULAR CrMo STEEL FRAME FRONT SUSPENSION EBR HYDRAULIC FORK REAR SUSPENSION STEEL SWING ARM – 100mm SHOCK ABSORBER HANDLEBAR WIDTH 580mm BRAKES NIFO FRONT/REAR DISC BRAKES TRANSMISSION CHAIN MOTOR BRUSHLESS GEARED 48V POWER 350W-1050W / TOP SPEED 40KM/H CLUTCH ELECTRONIC BATTERY...
-
Page 11: Components
User Manual COMPONENTS HANDLEBAR MUDGUARD FORK TYRE BRAKE DISC BRAKE CALIPER CHASSIS FOOTREST SHOCK ABSORBER SWING ARM SIDESTAND SEAT CHAIN CHAIN TENSIONER ON/OFF SWITCH POWER MODE SWITCH CONTROLLER MOTOR BATTERY SERIAL NUMBER CHARGING PLUG KIDS... -
Page 12: Controls
User Manual CONTROLS To turn on the motorcycle press the red The KIDS has a switch in the lower left- “ON/OFF” button placed in the handlebar, next hand part of the number plate. You can choose to the throttle grip. When pushing it inwards the between the full power option (100% of power) or limit it to 50% of power. -
Page 13: Before Using It
User Manual BEFORE USING IT If you receive your KIDS in a box, verify that it contains the following When we assemble each motorcycle in our factory Vidreres, we test the elements: proper operation one by one. However, we want to ask you to check again some components and fit them to your necessities and tastes: KIDS Motorbike with the handlebar disassembled. - Page 14 User Manual BEFORE USING IT BRAKES The KIDS are equipped with a cable-actuated disc brakes system. Check that both front and rear brakes work properly using the left and right brake levers while moving the motorcycle slightly. If the brake lever is far from your child’s fingers, you can bring them closer to the grip using the screw with an allen key.
-
Page 15: Maintenance
User Manual MAINTENANCE CHAIN TENSION EXAM The lifespan of the chain depends on its correct lubrication and adjustment. A bad maintenance can cause a premature wear or damages to the chain and to the rear/front sprockets. Before doing the maintenance to the chain, turn OFF the ON/OFF switch and put the sidestand. -
Page 16: Battery
The KIDS is provided with a LiMnCo 48v and 6Ah (288Wh of capacity) battery which supplies the motor. - Use only the charger provided by Torrot Electric to charge the battery. This kind of battery does not have the ‘memory effect’ and can be recharged even if they are not fully discharged. -
Page 17: Recharge
User Manual RECHARGE Recharge plug To recharge the battery, follow these steps: - First ensure that your motorbike is turned off with the ON/OFF switch outwards. - Then plug the 3 pin connector to the KIDS. The charge connexion for the battery is located in the front side of the chassis. -
Page 18: Fairing Removal
User Manual FAIRING REMOVAL We explain you here how to remove the fairing to have 10mm WRENCH access to the battery in case you want to disconnect it or change it for a new one. 5mm ALLEN KEY First locate the screw that is used to attach the saddle to the subchassis (only in the E10/S10 E10/S10... -
Page 19: Battery Removal
User Manual BATTERY REMOVAL Having the all the fairing removed, now is the moment to disconnect the cords: Remember to remove the main fuse! - First, disconnect the terminals connected to the ground (the chassis) - Unplug the connector that goes to the recharge point - Finally disconnect the red cord (battery positive) of the fuse holder In this moment you can remove the battery. -
Page 20: Ecu Mapping
Once you have the cord connected to the computer and to the controller, and you have turned on the computer and the motorbike, open the software THE EASIEST THING IS TO GO TO YOUR CLOSEST TORROT ELECTRIC DEALER AND LET THEM CONFIGURE THE CONTROLLER AS YOU WANT. - Page 21 User Manual ECU MAPPING Torrot ePower allows you to control three parameters: MAX MOTOR POWER In this tab you can regulate the max power supplied by the KIDS’ motor. 100% corresponds to full power (1050W) and 0% corresponds to 0W.
-
Page 22: Wiring Diagram
User Manual WIRING DIAGRAM 100% FUSE FUSE 0,5A 220/230V AC FUSE KIDS... -
Page 23: Faq
We explain you how to do it in pages 20 and 21 of this manual. If you still have doubts, the easiest thing you can do is turn to an official Torrot Electric No, these motorbikes are not allowed to ride in the street legally. You can dealer and let them configure the controller. -
Page 24: Warranty
Two (2) years warranty for: or higher value in the original model, at the discretion of - The use of the Torrot Electric vehicles in competition, Torrot Electric Europa S.L. This warranty begins on the unusual and/or commercial activities different from the Chassis/frame and swing arm in the electric bicycle, pur chased date. - Page 25 Manual. o by post to Torrot Electric Europa S.L. It is necessary the each country or region dictates, subject to the Spanish purchase ticket, the receipt or any other evidence of the manufacturer and the importers of the other countries.
- Page 26 - Vehicles repaired in points of sale or dealers not authorised by Torrot Electric Europa S.L., or without the Torrot Electric Europa S.L. original parts. This warranty does not cover the periodical and...
-
Page 27: Dealers
Torrot Electric After Sales Service INTERNATIONAL DISTRIBUTORS ANDORRA ISLE OF MAN SPAIN E. LECLERC ANDORRA SMARTECH TORROT ELECTRIC EUROPA Avda. Meritxell 93 38 Ballyscullion road, Pol. Ind. Vidreres B-7 AD500 Andorra la Vella Toomebridge co. 17411 Vidreres (Girona) T (+376) 822 377... - Page 28 Torrot Electric After Sales Service SPANISH DEALERS CÁDIZ GIRONA ALICANTE BARCELONA GALICIA MOTORLAND OFFROAD URBAN FUN CASTRO MOTOCICLETA MOTOS FERRAN BOUTIQUE TODO OCIO San ramón 59-65 Salvador Espriu 81 Del Transport 26 Ctra. de la Gandara 13 Avda. Ronda de Vigilancia s/n...
- Page 29 C/ Fragua 2 Poligono La Paz 26 Ctra. Benetuser 43, Pol. Ind. Pascualeta UPDATED INFORMATION AT WWW.TORROTELECTRIC.COM/EN/STORES 28993 Móstoles FIND YOUR TORROT CLOSEST DEALER AND GO THERE FOR THE BEST AFTER- 21007 Huelva 46200 Paiporta T 916 140 910 SALES SERVICE ;-)
- Page 30 TRANSLATION WITHOUT PRIOR WRITTEN PERMISSION IS PROHIBITED, EXCEPT AS ALLOWED UNDER THE COPYRIGHT LAWS. NO CONTRACTUAL IMAGES. DUE TO OUR CONSTANT IMPROVEMENT POLICY TORROT ELECTRIC EUROPA SL, RESERVES ITS RIGHTS TO INTRODUCE CHANGES IN THE PRODUCTS, SPECIFICATIONS AND EQUIPMENT WITHOUT NOTICE.
- Page 32 Serious fun. TORROT ELECTRIC (0034) 972 850 797 info@torrotelectric.com torrotelectric @torrotelectric...
