REPAIR MANUAL FOR THE ELECTRICAL SYSTEM / ELECTRONIC
MOTORCYCLES TORROT KIDS10/12
(Rev.1.0)

Advertisement

loading
Need help?

Need help?

Do you have a question about the KIDS10/12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Torrot KIDS10/12

Summary of Contents for Torrot KIDS10/12

  • Page 1 REPAIR MANUAL FOR THE ELECTRICAL SYSTEM / ELECTRONIC MOTORCYCLES TORROT KIDS10/12 (Rev.1.0)
  • Page 2 REPAIR MANUAL KIDS10/12 fdsafasdfasdf 2 of 20 www.torrotelectric.com Rev. 1.0...
  • Page 3 REPAIR MANUAL KIDS10/12 fdsafasdfasdf INDEX Connection scheme V1.0 (P.4) Connection scheme V1.1 (P.5) System elements V1.0 (P.6) System elements V1.1 (P.8) Troubleshooting V1.0 (P.10) Troubleshooting V1.1 (P.12) Battery check (P.14) Correct use of the battery (P.15) Installation modifications (P.17) Sequence of motor sensors (P.19)
  • Page 4 REPAIR MANUAL KIDS10/12 fdsafasdfasdf CONNECTION SCHEME (V1.0) CONNECTION SCHEME (V1.1) 4 of 20 www.torrotelectric.com Rev. 1.0...
  • Page 5 REPAIR MANUAL KIDS10/12 fdsafasdfasdf RESUMEN DE ELEMENTOS (V1.0) 1: BATTERY 5 of 20 www.torrotelectric.com Rev. 1.0...
  • Page 6 REPAIR MANUAL KIDS10/12 fdsafasdfasdf Cables: Red 1 and 2: Output, 48V Cables: Black 1: Common discharge Cables: Black 2: Common charge 2: CONTROLLER Power Cables: Red: Input , direct battery voltage Black: Common Double map Cables: Yellow (4): Output, 4.3V...
  • Page 7 REPAIR MANUAL KIDS10/12 fdsafasdfasdf Motor phases Cables: Yellow (Input, Phase A) Green (Input, Phase B) Blue (Input, Phase C) Winding resistance: 0,2-0,3 Ohms between terminals 5: DOUBLE MAP SELECTOR Cables: Black: Input, 4.5V White / Black: Common 6: THROTTLE Cables:...
  • Page 8 REPAIR MANUAL KIDS10/12 fdsafasdfasdf RESUMEN DE ELEMENTOS (V1.1) 1: BATTERY Cables: Red 1 and 2: Output, 48V Cables: Black 1: Common discharge Cables: Black 2: Common charge 2: CONTROLLER Power Cables: Red: Input, direct battery voltage Black: Common Double map Cables: Violet (4): Output, 4.3V...
  • Page 9 REPAIR MANUAL KIDS10/12 fdsafasdfasdf 4: MOTOR Hall connector Cables: Red: Input, 4.5V Negro: Common Amarillo (Output Hall A, 4.5V) Green (Output Hall B, 4.5V) Blue ( Output Hall C , 4.5V) Phases motor Cables: Yellow (Input, Phase A) Green (Input, Phase B)
  • Page 10 REPAIR MANUAL KIDS10/12 fdsafasdfasdf TROUBLESHOOTING (V1.0) The following table helps you to detect and solve common problems. Before using it and as a step prior to the solution of problems, make sure that the battery is fully charged and that you have entered a set of parameters known in the controller, in this order.
  • Page 11 REPAIR MANUAL KIDS10/12 fdsafasdfasdf Check connections of the dual map switch. Dual map button does not work Connection error in the switch. Replace defective parts. Check the continuity in the switch. Replace if Dual map switch defective necessary. Programme a parameter set in the controller.
  • Page 12 REPAIR MANUAL KIDS10/12 fdsafasdfasdf TROUBLESHOOTING (V1.1) The following table helps you to detect and solve common problems. Before using it and as a step prior to the solution of problems, make sure that the battery is fully charged and that you have entered a set of parameters known in the controller, in this order.
  • Page 13 REPAIR MANUAL KIDS10/12 fdsafasdfasdf Check that the resistance of the windings is One or more of the phases have the correct one and that there are no deteriorated. derivations to the chassis. Check manually if the wheel can turn easily.

  • Page 14: Battery Check

    KIDS10/12 fdsafasdfasdf BATTERY CHECK The lithium-ion battery of KIDS10/12 has an integrated electronic energy management, different from lead batteries that work without electronic control. This means that the charging and discharging battery drivers are independent from each other being able to have supply voltage in only one of them and not in the other.
  • Page 15 REPAIR MANUAL KIDS10/12 fdsafasdfasdf CORRECT USE OF THE BATTERY 1. General a. The motorcycle battery is composed of lithium-ion cells with high energy density. In no case it must be manipulated. Non-compliance with this advice involves electrical and chemical risks and can result in material damage and serious personal injuries.
  • Page 16 REPAIR MANUAL KIDS10/12 fdsafasdfasdf x. The battery is provided with internal protections against electrical hazards that can work automatically. Go to the section on battery check to know how to proceed. xi. Keep the battery clean and in good condition, carefully remove dust, dirt and other external elements that could get into the battery compartment during its use.
  • Page 17 REPAIR MANUAL KIDS10/12 fdsafasdfasdf MODIFICATIONS IN THE INSTALLATION To make the modifications listed below check the schemes of both installations and compose the installation as shown in the document. Pay special attention to the position of the cables in the contacts and to their type.
  • Page 18 REPAIR MANUAL KIDS10/12 fdsafasdfasdf 01EL-000E0-ZZ KIT ANDERSON PP30 RED 01EL-000F0-ZZ KIT ANDERSON PP30 BLACK 01EL-000G0-ZZ KIT ANDERSON PP30 YELLOW 01EL-000H0-ZZ KIT ANDERSON PP30 GREEN 01EL-000I0-ZZ KIT ANDERSON PP30 BLUE 01EL-00110-ZZ KEY SWITCHED ON REF. 6553 01EL-00210-ZZ FUESE HOLDER RUBBER WP. 30A...
  • Page 19 REPAIR MANUAL KIDS10/12 fdsafasdfasdf ANNEX 1: SEQUENCE OF MOTOR SENSORS Sequence of the motor Hall sensors (1= On, 0=Off) Hall A (Blue) Hall B (Green) Hall C (Yellow) 19 of 20 www.torrotelectric.com Rev. 1.0...
  • Page 20 REPAIR MANUAL KIDS10/12 fdsafasdfasdf 20 of 20 www.torrotelectric.com Rev. 1.0...
