3. PARTS LIST

(R)
LOCATION PARTS NO.
DESCRIPTION
ACCESSORIES & PACKING MATERIALS
9110
613 221 0287
INST MANUAL,A6,SUMMARY MANUAL,
English,French,Spanish,German,Japanese,
Chinese (Simplified),EXCEPT VCC-HD4600PC
9110
613 221 0294
INST MANUAL,SUMMARY MANUAL A6,
Chinese (Simplified),VCC-HD4600PC ONLY
9130
613 220 5931
CAUTION SHEET,COMPLIAN A6,
EXCEPT VCC-HD4600PC
9201
645 101 6539
TERMINAL 3P
9801
645 103 4571
DISC,CD-ROM L5DB2 PC SOFT WARE,
INSTRUCTION MANUAL,Chinese (Simplified),
VCC-HD4600PC ONLY
9801
645 103 2881
DISC,CD-ROM L5DH2 PC SOFT WARE,
INSTRUCTION MANUAL,English,French,
Spanish,German,Japanese,Chinese (Simplified),
Italian,EXCEPT VCC-HD4600PC
7001
613 220 6402
CARTON CASE INNER
7002
613 184 1659
CUSHION BAG
7004
613 203 8522
LABEL RECYCLE,VCC-HD4600P ONLY
LOCATION PARTS NO.
DESCRIPTION
CABINET & CHASSIS PARTS 1
5001
613 220 9625
CABINET,BACK-L5DH2
5002
613 220 9595
COVER,TOP-L5DH2
5003
613 220 9601
COVER,BOTTOM-L5DH2
5004
613 221 0317
STAND-L5DH2
5006
613 203 9635
MOUNTING
5007
613 221 0539
COVER MOUNTING-L5DB2
5008
613 220 5603
COVER SD-L5DB2
5011
613 221 9235
COVER,DUST-L5DH2,EXCEPT VCC-HD4600P
5101
613 220 9632
DEC,WINDOW-L5DH2
5201
613 220 9618
CABINET,FRONT-L5DH2
5202
613 221 2045
DEC,LENS-L5DH2
6004
613 220 9571
HOLDER,FRONT-L5DH2
6005
613 220 9588
HOLDER,BACK-L5DH2
6006
613 220 9649
COVER,LEFT-L5DH2
6007
613 220 9663
DOOR-L5DH2
6008
636 106 8154
COVER BAT INNER-SG212/J
6009
613 221 0577
DEC,BUTTON-L5DH2
6011
613 221 2052
SPACER,HEAT TRANSFER L5DH
6012
613 220 9656
COVER,RIGHT-L5DH2
6016
613 221 7880
HEAT,SINK PW-L5DH2
6017
613 221 9334
ADHESIVE COVER R-L5DH2
6019
613 221 9914
SPACER,HEAT-L5DH2
6021
613 222 3461
SPACER,HEAT4-L5DH2
6022
613 222 3478
SPACER,HEAT3-L5DH2
6023
613 222 3485
SPACER,HEAT PW-L5DH2
NJ501
411 220 0204
SCR PAN PCS 2X3.5
NJ502
312 051 6000
SPECIAL SCREW-3X4
NJ503
411 097 9409
SCR PAN PCS 2X4
NJ504
411 133 5204
SCR PAN+SW+W 3X8
NJ505
411 097 9409
SCR PAN PCS 2X4
NJ506
411 097 9409
SCR PAN PCS 2X4
NJ507
411 098 1006
SCR S-TPG BIN 3X6
NJ508
411 177 9503
SCR S-TPG PAN PCS 1.7X3
NJ509
411 192 0202
SCR S-TPG PAN 3X10
NJ603
411 030 5406
SCR BIN 2X4
NJ604
411 030 5406
SCR BIN 2X4
NJ606
411 030 5406
SCR BIN 2X4
NJ607
411 030 5406
SCR BIN 2X4
NJ608
411 191 9404
SCR PAN 3X6
16
