Land Pride AFM4522 Features And Benefits

Features and Benefits
All Flex Mowers

Features

Counter rotation on left hand deck
Narrow 9'-6" transport width
4 1/2" Deck overlap
Sleek frame design, including single
beam hitch and compact deck overlap
Automatic transport wing locks
P27560SR Transport tires
with tapered bearings
Removable transportation tire spindles
Back wheels on side decks even with
transportation tires
Rigid rear side deck tires
Large deck flotation tires with sealant
1/4" Gauge wheel arms
Low pivot points on deck
Deflectors built into mower decks
Rear discharge
Cat. 4 CV main driveline
Cat. 3 slip-clutch wing drivelines
Slip clutch protection
Heavy center gearbox mounting plate

Gearbox HP Rating

Gearbox warranty

Easy to grease blade spindles
Middle spindle sits towards the
back of the mower deck
Spring loaded idlers
Easy belt tension release
High blade tip speed

Choice of Blade

(Medium lift standard)
Others available thru parts dept.
Designs, specifications, features and information are subject to change without notice.
11/14/08
AFM4522 Model
Spreads grass clippings more evenly. Wing decks throw grass away from the rear
deck. Rear deck doesn't get covered up nor does it get bogged down by cut grass.
Transport width allows unit to be transported with ease.
Eliminates blade skips when turning. Tighter turns can be made.
Design allows operator to make tighter turns without leaving windrows and skips.
The AFM virtually becomes a zero turn mower.
When wings are raised in the full transport position, the wings lock in place. No
need to get off the tractor to lock. Pull rope from tractor seat to un-lock.
Large Transport tires offer smooth roading and less grass compaction. Allows
grass to stand up. Tapered roller bearings offer longevity.
Allows a spindle to be replaced by simply removing two bolts.
Allows tighter turns without skips.
Rigid wheel yokes holds hills and slopes better. Safer unit than the competition.
Optional 15" tires for great flotation or 18" tires for even greater flotation. The larger
the tire the less compaction in pounds per square inch allowing grass to stand up.
Sealant in the tires minimizes flats.
Gives the cutter gauge wheel arms a great deal of "hidden" strength.
The lower the pivot points are to the ground, the more side to side swing, allowing
for excellent flotation from each deck.
Safety features meet ANSI standards. Many competitors use chains for protection.
Once chains are removed the unit may not meet ANSI specifications.
Even dispersal, discharged items are always aimed downward. No rear chains are
needed, which tend to clump damp grass.
Constant velocity main driveline allows for tighter turns without harming U-joints in
driveline.
Reduces start-up torque that is put on the driveline, gearbox and gearbox support.
Guards against premature gearbox failure. Protects mower deck spindles.
Handles start up torque.
65 - 100 HP
S/N 368187- one year on all gearbox components
S/N 368188+ 5 years on gearbox housing, gears and shafts, 3 years on bearings
and seals on gearbox.
No guards to remove for routine greasing of blade spindles.
Uses less horsepower and allows material to escape the mower deck easier. The
discharge of the material is more even. Design eliminates windrowing.
Applies constant tension to belt to run efficiently.
Easily release belt tension for changing belt or for winter storage.
(18,498 fpm) Lifts the grass up for a clean cut and efficient discharge of material.
Tip rates as high or higher than the competition.
Low Lift - Highly recommended in sandy soils where lifting isn't crucial. Disturbs
the soil very little, allowing blades to wear longer.
Medium Lift - Medium suction for lifting grass. Requires less HP than high lift.
High Lift - Greatest suction for lifting grass before cutting. Can take higher HP in
tall dense grass. Not recommended in sandy soils.
Mulching - Perfect for leaf mulching.

Benefits

315-360F
5
