Land Pride 701-069A Assembly Instructions Manual

Lift Motor, Snow Blade

Assembly Instructions

Treker NT & ST TrekerSeries
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
Your Lift Motor, Snow Blade is exclusively designed for
your Land Pride NT & ST Treker. Please read these
installation instructions and your NT & ST Treker
Operator's Manual thoroughly before beginning.
Especially read information relating to safety concerns.
Also included in the Operator's Manual is important
information on operation, adjustment, troubleshooting,
and maintenance for this attachment (some manual
sections do not apply to all accessories).
General Information
These assembly instructions apply to the following Lift
Motor, Snow Blade Accessories listed below:
701-069A Lift Motor, Snow Blade

Further Assistance

Your dealer wants you to be satisfied with your new Lift
Motor, Snow Blade. If for any reason you do not
understand any part of this manual or are not satisfied
with the service received, the following actions are
suggested:
1. Discuss the matter with your dealership service
manager making sure he is aware of any problems
you may have and that he has had the opportunity to
assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
© Copyright 2007 Printed 06/21/07
THANK YOU FOR YOUR PURCHASE OF OUR SNOW
PLOW
ENCLOSED IN THIS KIT IS THE UNIVERSAL
ELECTRIC LIFT HARDWARE 701-069A
TO HAVE A COMPLETE PLOW ASSEMBLY, YOU
MUST HAVE AT LEAST FOUR BOXES:
1. MODEL SPECIFIC ATTACHING HARDWARE KIT.
TO ATTACH UNIVERSAL PUSH TUBE TO
MACHINE.
2. UNIVERSAL PUSH TUBE
3. BLADE OF YOUR CHOICE (COLOR, STYLE, &
SIZE)
4. YOUR CHOICE OF BLADE LIFT METHODS,
A. ELECTRIC BLADE LIFT
B. USE YOUR WINCH TO RAISE AND LOWER YOUR
BLADE.
OPERATING INSTRUCTIONS READ BEFORE
OPERATING
CUSTOMER MUST RECEIVE COPY OF OPERATING
INSTRUCTIONS AT TIME OF SALE.
!
DANGER
Exercise EXTREME CAUTION when plowing and always
at a slow speed.
!
WARNING
TO AVOID SERIOUS INJURY OR DEATH:
1. DO NOT EXCEED 5 MPH WITH BLADE
INSTALLED.
2. OPERATE WITH EXTREME CAUTION ON
SLOPES, STEEP GRADES AND ROUGH
TERRAIN.
3. KEEP AWAY FROM BLADE AND MOVING PARTS
DURING OPERATION.
4. WHEN PLOWING SNOW OR DIRT INTO A PILE
START BACKING UP BEFORE RAISING THE
BLADE.
5. DO NOT RAM THE BLADE INTO THE PILE. **
SLOW DOWN BEFORE HITTING PILE. **
6. BE AWARE OF POSSIBLE HIDDEN OBJECTS
UNDER SNOW.
Manual No. 701-149M
