System requirements

PC system requirements:
• At least 1 GHz processor
• At least 1 GB RAM main memory
• At least 25 MB free hard disk space
• 1 free USB port for connecting the HELIX Optical & USB Interface
• Screen resolution of at least 1024 x 768 pixels or greater
The software has been tested on the following operating systems: Windows XP, Windows Vista
(32 bit) and Windows 7.
PP50 DSP system requirements:
• You require the HELIX Optical & USB Interface (Part No. H424493)
• The relevant SETUP FILE must be installed in the PP50 DSPFile name: "PP50 DSP PC-Tool
Software Rev X.X.af1"Detailed instructions are provided in the PP50 DSP user manual.
P-DSP system requirements:
• You require the supplied USB cable
• The most recent version of the SETUP FILE must be installed in the P-DSPFile name: P-DSP
PC-Tool Software Rev X.X.af1Detailed instructions are provided in the P-DSP user manual.
Recommended equipment for correct in-vehicle sound measurement:
A device is required to measure frequency responses in order to optimize the PP50 DSP to your
vehicle. There are now very reasonably priced systems which operate on a PC/Notebook/Netbook
and make it affordable for everyone to achieve reliable readings. The following list of components
and software have been tested by us and judged to meet the operational requirements.
• Behringer ECM8000 measuring microphone
• T-BONE Micplug USB microphone-USB interface with phantom power
• Praxis measurement software from Liberty Instruments (freeware)
• A music CD containing a pink noise test signal
Further information can be found under "Recommended measuring equipment", "Measuring fre-
quency responses" and "Operating the measurement software".
