- Page 1 DIGITAL FULL HD SPLITTER SC-09HDS User's Manual SC-09HDS...
-
Page 2: Precaution And Safety Guidelines
Precaution and Safety Guidelines Please read this user’s manual thoroughly prior to use the unit for its easy and convenient use. • Do not install the product in the following places: extremely low or high temperature conditions; places exposed to rain, snow, or high humidity; places containing or exposed to oil and gas;... - Page 3 1. Introduction 1-1. Overview The SC-09HDS, a Digital Full HD Splitter, offers a high resolution display for video signals received from nine (9) SD (standard definition) CCTV cameras with 720*480 Pixel. And it splits the screen in various formats from full screen to 9 screens display mode, without deterioration.
-
Page 4: Product Parts And Peripheral Device Connection
3. Product Parts and Peripheral Device Connection 3-1. Name of Parts and Function 3-1-1. SC-09HDS Front Side ③ ④ ⑤ ⑥ 각 채 널 에 해 당 되 는 버 튼 을 누 르 면 해 당 채 널 을... - Page 5 Split Mode # of Split Split Screen Display Mode Screen 3-1-1-1 Mouse Channel Selection - To select the video channel you want with the mouse, put the mouse icon on the video screen you want to select and then click the left button of the mouse.
- Page 6 3-1-2. SC-09HDS rear side (Connection) Please connect the camera, the monitor and related devices as below. ①② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① VIDEO INPUT: Connect the nine (9) cameras ② VIDEO OUT (Loop Through): It distributes the nine (9) input video signals to other devices by loop through.
- Page 7 - Control DATA Code ASCI Function Remarks 0x30 ~ 0x39 0 ~ 9 CH 01 ~ 09 Full Display Full Display Control 0x47 Multi Screen 〃 0x48 Menu 0x49 Enter 0x4A Display in quad (4 split) 0x50 Display Control Display in six splits 0x51 〃...
-
Page 8: Remote Control
3-1-5. Display Mode in Motion or Pattern Change Detection When a motion or pattern change is detected, - it displays in full screen if the changes are detected in one single channel; - it displays in 16 splits mode indicating the detected channel in yellow frame, if the changes are detected in more than 2 channels. -
Page 9: Specification
- Direction Buttons: Press these buttons to set the value of each menu. - Set Value change: Press these buttons to change the menu set value. 4. Specification MODEL SC-09HDS 75Ω 1 Vp-p(BNC-F) Ⅹ 9 INPUT Looped Through Output 75Ω 1 Vp-p(BNC-F) Ⅹ 9 OUTPUT HDMI Ⅹ... -
Page 10: Menu Setup
- Using the Front buttons or the remote control: Press the menu button and the menu setting will appear in the screen. ※ Please refer to the button function of SC-09HDS front side (3-1-1). ① ②... -
Page 11: Menu Structure
④ Setting Menu: To go to the menu setting mode, click the menu icon, or press the front menu button, or the menu button of the remote control. - Log-in Window: If you set use mode in password menu (5-5-1), log-in window appears as below (The password in default is “1111”) 5-1. -
Page 12: Date Display Format
Then, press [ENTER] and select Korean or English by pressing +/ - buttons. 5-2-2. System ID When controlling SC-09HDS at long distance or short distance, you can use the System ID. You can insert from 1 to 255. - Using the mouse: Click the right button of the mouse > click Menu> click System set>... -
Page 13: Date/Time Set
5-2-4. Date / Time Set In this menu, it is possible to set date / time. - Using the mouse: Click the right button of the mouse > click Menu> click System set> and then set Date & Time. - Using the front button or the remote control: Press Menu > press ◀▶ buttons and [ENTER] in System set >... -
Page 14: Time Display
5-3. Display Set In Display set, it is possible to set Time, Channel name, Sequence time, Video format (NTSC/PAL), HDMI resolution, HDMI display position, Spot display. 5-3-1. Time display In this menu, it is possible to set the current date and time indication. - Using the mouse: Click the right button of the mouse >... - Page 15 - Using the front button or the remote control: Press Menu > press ◀▶ buttons and [ENTER] in Display set > press ▲▼ buttons and [ENTER] in Video input type > Press +/ - buttons to change the set value. 5-3-5.
-
Page 16: Channel Set
5-4. Channel Set In this menu, it is possible to set up the Channel select, Channel name, Brightness, Contrast, Hue, Motion detect, Pattern change det. etc. 5-4-1. Channel Select You can select the channel you want to set up. - Using the mouse: Click the right button of the mouse > click Menu> click Channel Set>... - Page 17 5-4-3. Brightness It sets the brightness of each channel (0~99). - Using the mouse: Click the right button of the mouse > click Menu> click Channel Set> and then set the brightness. - Using the front button or the remote control: Press Menu > press ◀▶ buttons and [ENTER] in Channel set >...
- Page 18 Detection Set the activation or deactivation of - Using the mouse, click the set value, Function Motion/Pattern change detection then click the right and left direction function. arrow to change the set value. Select among OFF, Motion and Pattern. - Using the front function button, press the button ▲/▼...
-
Page 19: Alarm Input
5-4-7. Alarm Input In this menu, you can set whether you want to use the alarm or not. To use the alarm, it should connect the Alarm Interface unit (SC-16AIU) to the RS-232 communication port. The instruction on the alarm input should be referred to the user’s manual of the Alarm Interface Unit (SC-16AIU). -
Page 20: Password Enable
5-5-1. Password Enable You can set the password you want to use. Use this menu in case that only the authorized administrator can handle the menu setting. In case of selecting the password use mode, whenever you enter to the menu, the Login window appears and you should enter the password set. - Using the mouse: Click the right button of the mouse >... - Page 21 5-6. Exit After setting the menu, select Exit to return to the previous display screen displayed before entering the menu.
-
Page 22: Connection Diagram
6. Connection Diagram Please connect the devices as below diagram. When you want to extend the transmission of the HD video, please use our SC-HDT0801 and the SC-HDR0801 and connect the devices as below. HD Video Splitter (SC-16HDS) -
Page 23: Warranty Certificate
7. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide 12 months warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period One (1) year from the date of purchase Name Purchaser Address...
