6-3. Do-it-yourself maintenance
Driver's side instrument panel
■
Fuse
1 STOP
2 P/W-B
3 P/SEAT1 F/L
4 D/L NO.1
5 NV-IR
6 FL S/HTR
7 WIPER
8 WIPER-IG
9 LH-IG
10 LH ECU-IG
GS450h_OM_OM30E26U_(U)
Ampere
7.5 Stop lights, high mounted stoplight
5 Power window master switch
30 Power seats
25 Power door lock system
10 Lexus night view
10 Seat heaters/ventilators
30 Windshield wipers
5 Windshield wipers
Seat belts, body ECU, AFS, overhead mod-
ule, raindrop sensor, inside rear view mirror,
lane camera sensor (LKA), head-up display,
shift lock system, intuitive parking assist, front
left-hand door ECU, driver monitor system,
10
Remote Touch screen, electric tilt and tele-
scopic steering column, power seats, moon
roof, windshield wiper de-icer, intuitive park-
ing assist switch, PTC heater, headlight
cleaner, Blind Spot Monitor buzzer
VDIM, brake system, D-SW MODULE
(Blind Spot Monitor, heated steering wheel),
10 driver support system, AFS, electric cooling
fans, EPB, air conditioning system, steering
sensor
Circuit
