Summary of Contents for Lumens DC210
- Page 1 DC210 Visual Presenter User Manual [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.lumens.com.tw/goto.htm English...
-
Page 2: Table Of Contents
EN55022 (CE Radiation) Warning ..............5 Chapter 2 Package Content ................. 6 Chapter 3 Product Overview................ 7 Relative position of the presenter and DC210 ........8 Recommend distance ................8 Incorrect use ..................9 Chapter 4 Installation and Connections ........... 10 System Diagram ................ - Page 3 7.14.3 I would like to change the setting of DC210 then capture a photo in MS-Word..............31 7.14.4 I would like to set the DC210 as a webcam for Skype ..33 7.14.5 I would like to set the DC210 as a PC Camera ..... 34 7.14.6 I would like to connect Interactive Whiteboard ......
-
Page 4: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 5: Chapter 1 Precautions
Chapter 1 Precautions Always follow these safety instructions when setting up and using the visual presenter: Do not place visual presenter in tilted position. Do not place the visual presenter on an unstable trolley, stand or table. Do not use the visual presenter near water or source of heat. Use attachments only as recommended. -
Page 6: Safety Precautions
Safety Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. This visual presenter has a 3-wire AC line Plug. This is a safety feature to ensure that the plug will fit into the power outlet. Do not try to disable this safety feature. If the visual presenter will not be used for a long period of time unplug it from the power outlet. -
Page 7: Chapter 2 Package Content
Chapter 2 Package Content DC210 Quick Start Guide English User Manual (For download of other language versions, please visit Lumens website) Base Installation Guide Download Card Remote Control Remote Control Box VGA Cable USB Cable C-Video Cable Power Cord Microscope Adapter... -
Page 8: Chapter 3 Product Overview
Chapter 3 Product Overview 8. Gooseneck 7. AF button 4. LED indicator 1. Lamp 3. Control Panel 2. Remote sensor 5. Lens 6. DIP Switch Settings (Bottom) English... -
Page 9: Relative Position Of The Presenter And Dc210
3.1 Relative position of the presenter and DC210 DC210 Presenter Document 3.2 Recommend distance * About 400 mm distance between camera and the desktop is recommended. 400 mm English... -
Page 10: Incorrect Use
3.3 Incorrect use English... -
Page 11: Chapter 4 Installation And Connections
Chapter 4 Installation and Connections 4.1 System Diagram Monitor Projector or Monitor Television English... -
Page 12: Mounting The Dc210 At Desktop
4.3.2 Step 2: Connecting with components Connecting to a projector Use VGA cable to connect VGA OUT connector on DC210 to a projector or the VGA IN connector on a monitor. Connecting to a monitor Use VGA cable to connect VGA PASSTHROUGH connector on DC210 to the VGA IN connector on a monitor. - Page 13 Connecting to a TV 1. Using C-Video cable to connect C-Video OUT connector on DC210 to 2. Adjust DIP Switch Setting. NTSC: America, Taiwan, Panama, Philippine, Canada, Chile, Japan, Korea and Mexico PAL: Country/region not listed above: <Note>: In C-Video Mode, some buttons on the machine panel and remote control are not working.
- Page 14 Connecting to a computer Use VGA cable to connect VGA IN connector on DC210 to the VGA OUT connector on the computer. Using USB cable After using the USB cable to connect to a computer, please refer to Chapter 4 Installation and Connection of the User Manual to install the application software.
-
Page 15: Start Using The Dc210
When using the remote control, aim at the receptor on the DC210, and press the power button. Once DC210 is turned on, the LED on the control panel will flash a few times and stay lit. Please contact your distributor if the LED is not 4.5 Installing remote control holder... -
Page 16: Installing Driver And Application Queue
4.6.2 Installation steps (PC) Please download the software queue at the following URL: http://www.lumens.com.tw/goto.htm Connect the DC210 to a computer through a USB interface. Refer to DC210 User Manual 4.3 Connecting Devices / Connecting to a computer / Connecting to a computer through USB. - Page 17 Press [Next] and follow the instructions on the screen to install the software. Once the installation is completed, press [Finish]. If you want to create a shortcut on the desktop, press [Yes]. English...
- Page 18 Then the program will automatically install the driver. Please follow the instructions on the screen to install the driver. The installation is completed, press [Finish] to reboot the system. English...
- Page 19 After the reboot, the [USB Composite Device] program will be installed automatically. Please follow the instructions on the screen to install the program. 10. The [Visual Presenter V1] program will be installed automatically. Please follow the instructions on the screen to install the program. English...
- Page 20 11. The [Visual Presenter V1 Memory] program will be installed automatically. Please follow the instructions on the screen to install the program. 12. All installation completed. 4.6.3 Installation steps (MAC) Please download the software queue at the following URL: http://www.lumens.com.tw/goto.htm English...
- Page 21 Connect the DC210 to a computer through a USB interface. Refer to Chapter 4 Installation and Connections 4.3 Connecting Devices / Connecting to a computer / Connecting to a computer through USB. Turn on the DC210. Select [queue] to begin installation and follow the screen instructions.
- Page 22 4.6.4 Verifying the installation is completed (PC) 1. Find queue on the desktop of the computer. 2. Double click the queue shortcut on the desktop or click [Start] / [Programs] / [queue]. <Remark> Please refer to the User Manual of queue for how to use it. 4.6.5 Verifying the installation is completed (MAPC) 1.
-
Page 23: Chapter 5 Dip Switch Settings
Chapter 5 DIP Switch Settings <Note>: You must re-start DC210 for DIP switching configuration to take effective. 5.1 Connecting to a projector or monitor 5.1.1 XGA output (default values): 5.1.2 SVGA output 5.1.3 Reserved 5.1.4 Reserved English... -
Page 24: Connecting To A Tv
5.2 Connecting to a TV 5.2.1 NTSC: America, Taiwan, Panama, Philippines, Canada, Chile, Japan, Korea and Mexico 5.2.2 PAL: Countries/regions not listed above <Remark> It doesn’t support C-Video and VGA simultaneously. Once C-Video is on, VGA OUT is not supported. English... -
Page 25: Chapter 6 Control Panel/Remote Control And Setting Menu
Chapter 6 Control Panel/Remote Control and Setting Menu 6.1 Functions of control panel and remote control <Remark> The below functions are listed alphabetically Name Function Descriptions Operation Turn on and off the visual presenter. Remote control / Control panel , , , Remote control / Move up, down, left or right to select the needed function. -
Page 26: Setting Menu
6.2 Setting Menu 6.2.1 VGA Mode <Remark>: Press [Menu] on the remote control or control panel to enter the setting menu; The bold underlined values in the following table are the defaults. Level Level Level Function Descriptions Major Minor Items Adjustment values Items Display... - Page 27 6.2.2 C-Video Mode Level Level Level Function Descriptions Major Adjustment Minor Items Items values Focus 0~A~200 Manually tune the focus Gamma Photo/Text Select Photo/Text Mode Display Image Normal/Gray Select Normal/Gray Mode Freeze On/Off Freeze the image on the screen Lamp On/Off Select Lamp On or Off Full Range...
-
Page 28: Chapter 7 Descriptions Of Major Functions
Chapter 7 Descriptions of major functions 7.1 I would like to switch image sources The default of image source is Live Image. Press [SOURCE] on the remote control or the control panel to switch to Live Image (Default) and computer in turns. 7.2 I would like to make text clearer and photos more colorful The default of [Gamma] is Photo (Photo Mode). -
Page 29: I Would Like To Adjust The Brightness
7.5 I would like to adjust the brightness If you use the remote control or the control panel: 1. Press [BRT +] to make it brighter 2. Press [BRT -] to make it darker 7.6 I would like to turn on / off the lamp Control panel 1. -
Page 30: I Would Like To Delete Captured Images
4. Press [ ] or [ ] to turn to the previous/next image. 5. Press [PLAYBACK] to exit. 6. Press [MENU] to exit. 7.11 I would like to delete captured images Control panel 1. Press [PLAYBACK]. 2. Press [ ] or [ ] or [ ] or [ ] to select the thumbnail you want you delete. -
Page 31: Computer-Related Functions
7.14 Computer-related functions Ensure that the USB cable is connected and the drivers are installed before using the computer-related functions. Refer to DC210 User Manual Chapter 4 Installation and Connections 4.3 Connecting Devices and 4.6 Installing Driver and Application queue 7.14.1 I would like to insert a photo in MS-Paint... -
Page 32: I Would Like To Change The Setting Of Dc210 Then Capture A
2. Select [Visual Presenter V1] and click [Custom Insert]. 3. Click [Get Picture]. It will capture the photo of live image. 7.14.3 I would like to change the setting of DC210 then capture a photo in MS-Word 1. Click [Insert / Image / From Scanner or Camera] in MS-Word. - Page 33 3. A window showing a live image (see below) will be displayed: 4. Press [Setting]. To control the DC210 via the Camera Settings interface. The operating procedure is the same with the remote control and control panel of the DC210. Refer to...
-
Page 34: I Would Like To Set The Dc210 As A Webcam For Skype
7.14.4 I would like to set the DC210 as a webcam for Skype The DC210 can be used as a webcam for teleconferencing software such as Skype and MSN. The following instructions use Skype as an example: 1. Open Skype and enter [Tools] > [Options]. -
Page 35: I Would Like To Set The Dc210 As A Pc Camera
7.14.5 I would like to set the DC210 as a PC Camera 1. Click My computer window and select [Visual Presenter V1] to open live screen. 7.14.6 I would like to connect Interactive Whiteboard 1. System Diagram English... - Page 36 2.4 Press [StarBoard] / [Mode] / [TWAIN] Please refer to the operations of 7.14.2 I would like to insert a photo in MS-Word and 7.14.3 I would like to change the setting of DC210 then capture a photo in MS-Word English...
- Page 37 3.1 Press [Insert] / [Picture From Scanner] 3.2 Please refer to the operations of 7.14.2 I would like to insert a photo in MS-Word and 7.14.3 I would like to change the setting of DC210 then capture a photo in MS-Word English...
-
Page 38: Chapter 8 Connecting To Microscope
3.1.4. Press [ ] or [ ] to the [Microscope]. 4 If the image is not clear. 4.1. Please adjust the focus of microscope 4.2. Press the [AF] button on the DC210 camera head of main unit to activate the auto focus English... -
Page 39: Chapter 9 Troubleshooting
Chapter 9 Troubleshooting This chapter describes problems you may encounter while using DC210. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact our distributors or service center. - Page 40 10 MAR, 2009 Version:01 P/N : 5080096-50...
