- Page 1 DC210 Visual Presenter Quick Start Guide [Important] To download the latest version of quick start guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.lumens.com.tw/goto.htm English -...
- Page 2 1. Package Content Quick Start Guide DC210 English User Manual (Multilanguage) (For download of other language versions, please visit Lumens website) Base Installation Guide Download Card Remote Control Remote Control Box VGA Cable USB Cable C-Video Cable Power Cord Microscope Adapter...
- Page 3 2. System Diagram Monitor Projector Monitor English -...
-
Page 4: Mounting The Dc210 At Desktop
<Note>: Appearance of power cord may vary with countries/regions. 4.2 Step 2: Connecting Peripherals 4.2.1 Connecting Projector Use VGA cable to connect VGA OUTconnector on DC210 to a projector or the VGA IN connector on a monitor. 4.2.2 Connecting Monitor Use VGA cable to connect VGA PASSTHROUGH connector on DC210 to the VGA IN connector on a monitor. - Page 5 4.2.3 Connecting TV 1. Using C-Video cable to connect C-Video OUT connector on DC210 to TV. 2. Adjust DIP switch configuration For USA, Taiwan, Panama. Philippines, Canada, Chile, Japan, Korea and Mexico, please use NTSC: For other countries or regions, please use PAL: <Note>: In C-Video Mode, some buttons on the machine panel and...
- Page 6 4.2.4 Connecting to Computer Use VGA cable to connect VGA IN connector on DC210 to the VGA OUT connector on the computer Using USB cable After plugging in the USB cable, please refer to DC210 User Manual install the application software...
- Page 7 5. Start Using the Product 5.1 Turn on the Power Control Panel Remote Control If you are using the remote control, please point the remote control at the receiver and press the Power button. Once the power is turned on, the LED on the control panel will flash a few times and stay lit.
