Samurai Industrial Floor Stripper Operator's Manual

Samurai industrial floor stripper

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

DO NOT operate this equipment until you have read and

understood all the enclosed Operator's Manual.

READ ALL the sections in this manual PRIOR to attempting to

service, maintain or operate this equipment.

Industrial Floor Stripper

Operator's Manual

Table of Contents

Summary of Contents for Samurai Industrial Floor Stripper

Page 1 Industrial Floor Stripper Operator’s Manual DO NOT operate this equipment until you have read and understood all the enclosed Operator’s Manual. READ ALL the sections in this manual PRIOR to attempting to service, maintain or operate this equipment. Copyright 2006.
Page 2 Warranty Statement The SAMURAI Industrial Floor Stripper, is guaranteed to be free from any manufacturer’s defects in material and workmanship for a period of six (6) months from the date of purchase. This warranty is exclusive of any normal wear and tear and/or consumable parts, such as, but not limited to, rubber bushings and blades. All normal wear and tear and/or consumable parts are protected from manufacturer’s defects in material and workmanship for a period of...
Page 3 Congratulations for purchasing the SAMURAI Industrial Floor Stripper to meet all your tough jobsite needs! Please ﬁ le your original bill of purchase for this unit in a safe place. For warranty service of the SAMURAI you will need to pro- vide a copy of this document to conﬁ...
Page 4 Fold along dotted line Place Stamp Here SAMURAI Warranty Programme c/o Uniquip Canada Inc. North American Authorized Dealer 4101 boul.Industriel Laval QC H7L 6G9 ATTN: TECHNICAL SERVICE...
Page 5: Table Of Contents
B. Attaching the 4” blade C. Attaching the 9” blade General principles in using the SAMURAI ﬂ oor stripper Using the SAMURAI on stairs and other difﬁ cult to maneuver areas Using the SAMURAI with the handle extension Storing the SAMURAI...
Page 6: Pre-Operation Note
Pre-Operation Note Thank you for your purchase of the SAMURAI Industrial Floor Stripper. This ﬂ oor stripper has been designed and manufactured to our highest quality demands for durability and performance. We are committed to offering durable products and quality after-market service. The SAMURAI Industrial Floor Stripper is warranted to be free from manufacturer’s defects in material and workmanship for a period of six (6) months...
Page 7: Safety Precautions
Safety Precautions 1. READ AND UNDERSTAND OPERATOR’S MANUAL PRIOR TO USE OF FLOOR STRIPPER. 2.Before operating ﬂ oor stripper, ensure that it is structurally and mechanically safe by checking the following: a. Is the motor functioning within acceptable tolerances? b. Are the bushings for the enclosure and vibrating plate showing excessive wear and tear or uneven wear patterns? c.
Page 8 ALWAYS guard against electrical shock. DO NOT come into contact with grounded surfaces, such as pipes, radiators, refrigerators etc. c. ALWAYS wear protective eyewear and gloves when using the SAMURAI Floor Stripper. Removing ﬂ ooring materials creates a dusty environment in which the operator should always be protected.
Page 9: Guide To Parts Breakdown
This guide aims to serve as a representational guide to the SAMURAI. Any other uses or application beyond the scope of this document are strictly prohibited. While every attempt has been made to maintain its accuracy, SAMURAI reserves the right to update and modify the equipment without prior notiﬁ...
Page 10: Parts Breakdown
Parts Breakdown...
Page 11 Parts Breakdown cont’d ... Diagram Item Qty. Req’d for Description Reference # Number Each Machine SA-01 Lower Enclosure SA-02 Vibrating Plate SA-03 Upper Enclosure SA-04 Brush Cap SA-05 Motor Brush SA-06 Electrical Control Protection Plate SA-07 7/8” Fan Cap SA-08 Bracket for Top Handle SA-09 Lower Support Bracket for 9”...
Page 12 M6×25 Bolts for Vibrating Plate Counterweight SA-67 Steel Inserts SA-68 Protector Caps for Brushes Technical Support Hotline c/o Technical Service Uniquip Canada Inc. SAMURAI North American Authorized Dealer www.uniquip.ca French Service English Service T : 1-800-332-4012 T : 1-888-332-4012 F : 1-866-825-2221 F : 1-866-567-0956...
Page 13: Information On Safety Decals
If you have any questions, please do not hesitate to contact your local authorized service centre for further assistance. SAMURAI-LABEL01: Qty Required = 1 SAMURAI-LABEL02: Qty Required = 1...
Page 14: Contents List
DO NOT ATTEMPT ASSEMBLY OR OPERATION WITHOUT ANY OF THESE LISTED PARTS! Pre-Operating Procedures Before using the SAMURAI Industrial Floor stripper, please perform the following procedures for the per- sonal and property safety of the operator and jobsite and for optimal performance.
Page 15: Operating Procedures
D. Up to 400’ ft. = 8 AWG Operating Procedures Installing the blades and support mounts for the SAMURAI 1. Ensure that the ﬂ oor stripper is completely turned off, cooled, and at a complete stop prior to adjusting or relocating the unit.
Page 16 (Fig.4) iv. Using the nut driver included with the SAMURAI, tighten down each bolt such that the blade is securely “sandwiched” in between the top mount and the vibrating plate. DO NOT OVERTIGHTEN BOLTS.
Page 17 Fig.14: Verify that beveled edges on blades are facing the right direction. When attaching any of the blades to the SAMURAI Floor Stripper, the beveled edge of the blade must be used as shown in Fig.14.
Page 18: B. General Principles In Using The Samurai Fl Oor Stripper
General principles in using the SAMURAI ﬂ oor stripper The SAMURAI ﬂ oor stripper is designed for use either as a standalone unit for small or difﬁ cult jobs, such as stairs, or with the handle extension for clearing large areas. The following instructions apply to both usages.
Page 19: C. Using The Samurai On Stairs And Other Difﬁ Cult To Maneuver Areas
(Fig.17). 4. Guide the machine in the direction required to strip the material. 5. Consult “General principles in using the SAMURAI ﬂ oor stripper” as detailed above for detailed instructions in using the SAMURAI ﬂ oor stripper. Fig.17: How to use the SAMURAI Using the SAMURAI with the handle extension 1.
Page 20: Storing The Samurai
“Pre-Operating Note”. 10. Consult “General principles in using the SAMURAI ﬂ oor stripper” as detailed as above for detailed instructions in using the SAMURAI ﬂ oor stripper.
Page 21: Maintenance Procedures
4. Ensure that the technician has tied back or remove any loose hair, clothing and any other potential hazards and obstructions The SAMURAI is designed to be a low-maintenance unit. Provided that the unit has not been subjected to abuse or misuse, there are very few service items required. By following the Inspection Schedule below, BEFORE and AFTER each use of the ﬂ...
Page 22: A. Inspection Schedule
1.Changing the bushings for the SAMURAI Floor Stripper The bushings and bolts that frame and support the vibrating plate are crucial to the performance of the SAMURAI Floor Stripper. These parts are also the most common wear and tear parts, due to the vibrating plate design.
Page 23: B. Changing The Bearing Sa-49 And Rubber Bearing Cup Sa-50
A. Disassembling the SAMURAI Floor Stripper ... 4. Turn the SAMURAI upside down, taking care to support the unit as shown in Fig.30. Remove the 4 bolts from the vibrating plate, and set aside bolts and washers aside. NOTE: There are rubber washers set inside each of the 4 bolt holes on both sides of the vibrating plate as well as those threaded on the bolt.
Page 24: C. Replacing All The Bushings, Washers And Bolts
Maintenanace Procedures cont’d ... General Service Procedures cont’d ... 1.Changing the bushings for the SAMURAI Floor Stripper cont’d ... C. Replacing all the bushings, washers and bolts 1. Remove and inspect inner bushings set in the 4 bolt holes inside the top enclosure. Discard and replace with new bushings as needed.
Page 25: Changing Motor Brushes
Fig.44: Remove and Fig.45: Order of nylon inspect axle bolt. wheels for re-installation. Technical Support Hotline c/o Technical Service Uniquip Canada Inc. SAMURAI North American Authorized Dealer www.uniquip.ca French Service English Service T : 1-800-332-4012 T : 1-888-332-4012 F : 1-866-825-2221...
Page 26 Notes...
Page 27 Notes...
Page 28: Copyright
Technical Support Hotline c/o Technical Service Uniquip Canada Inc. SAMURAI North American Authorized Dealer www.uniquip.ca French Service English Service T : 1-800-332-4012 T : 1-888-332-4012 F : 1-866-825-2221 F : 1-866-567-0956 Copyright 2006. All rights reserved.
