Solid Signal HD Blade Manual

Download this manual

For help, call 1-877-312-4547

or email tech@solidsignal.com.

DO NOT RETURN ANTENNA TO PLACE OF PURCHASE.

Specifications and Setup

• For indoor use only

• Range of 25 miles

vary based on terrain and obstructions)

• For high VHF & UHF channels

• Recommended for use with one TV

• Small, compact size

• One side black, one side white to

blend into any decor

• No assembly required

• Model HD BLADE

Attach mini, or regular, coax cable

to the Antenna and run the other end

into the "Antenna In" coax port on the TV.

Run a channel scan.

listing of likely channels available in

your area, go online to dtv.gov/maps .)

If not satisfied with the number of channels found, try re-positioning the

antenna. Moving the antenna three feet in one direction is often enough

to change the reception. Then, re-run a channel scan.

(performance may

ANTENNA /

CABLE IN

(For a

Back of the TV

CABLE IN

Need help?

Do you have a question about the HD Blade and is the answer not in the manual?

Page 1 • One side black, one side white to blend into any decor • No assembly required • Model HD BLADE Attach mini, or regular, coax cable to the Antenna and run the other end into the “Antenna In” coax port on the TV.
Page 2 DO NOT insert nail here Okay to insert nail here The HD BLADE antenna is small enough to hide behind a TV or picture frame. e HD BLADE . y t Tips for Maximizing Reception The coax cable is running from the side of the antenna instead of the top or bottom of the antenna.
Page 3 A. The HD BLADE antenna can receive programming from all of the major local A. The antenna is designed for indoor use only. The HD BLADE antenna is not broadcast networks (e.g. ABC, CBS, FOX, NBC, PBS) plus additional networks meant to be mounted outdoors or in the attic.
Page 4 The 90 Day Warranty is provided on the condition that the equipment is properly delivered with all handling and freight charges prepaid to your Solid Signal dealer for return to our factory for repair or replacement. Solid Signal dealers will arrange for the replacement or repair and return to you without charge the product which failed due to defective material or workmanship.
