DLPK
INSTALLATION
GUIDE
CANBUS DOORLOCK AND
IMMOBILIZER INTERFACE*
*RFLOOP may be required
Rev: 20110329
Update Alert: Firmware updates are posted to the web on a
regular basis. We recommend you check for firmware and/or
install guide updates prior to installation of this product.
www.xpresskit.com
© 2009-2011 Directed Electronics. All rights reserved.
Advertisement
Related Manuals for Xpresskit DLPK
Summary of Contents for Xpresskit DLPK
- Page 1 D I G I T A L O E M I N T E G R A T I O N DLPK INSTALLATION GUIDE CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required Rev: 20110329 Update Alert: Firmware updates are posted to the web on a regular basis.
- Page 2 Connect wire to Remote-Starter/Alarm OUTPUT INPUT INSTALLATION AND PROGRAMMING INSTRUCTIONS START HERE: Turn the key to the Make the connections of the DLPK "ON" position. to the vehicle: Connector 1 (White): Determine the type of installation: INSTALLATION WITH OR WITHOUT D2D (See P.8) Once the LED starts to flash rapidly turn the key to the OFF position.
- Page 3 SORTIE ENTRÉE démarreur à distance / alarme. INSTRUCTION D’INSTALLATION ET DE PROGRAMMATION COMMENCEZ ICI: Tournez la clé en Effectuez les connexions du DLPK position ignition. au véhicule: Connecteur 1 (Blanc): Déterminez le type d’installation: INSTALLATION AVEC OU SANS D2D: (P.:8) Lorsque la DEL clignote rapidement, tournez la clé...
- Page 4 VEHICLE FIT GUIDE / GUIDE DES VEHICULES Additionnal Parts Required RFLUB See www.xpresskit.ccom for installation schematic / Voir www.xpresskit.com pour les schémas d'installation A5 - S5 See www.xpresskit.ccom for installation schematic / Voir www.xpresskit.com pour les schémas d'installation RFLUB See www.xpresskit.ccom for installation schematic / Voir www.xpresskit.com pour les schémas d'installation...
- Page 5 Grand-Caravan CAN High: White/Green CAN Low: White/Blue Required Yukon RFLUB RFLUB RFLKIA2 Genesis Sedan CAN High: Brown CAN Low: White See www.xpresskit.com for installation schematic / Voir www. xpresskit.com pour les schémas d'installation EX35 - EX37 IntelliKey IntelliKey (FX35) Push to Start See www.xpresskit.com for installation...
- Page 6 Mercedes-Benz RFLUB RFLUB If push to start see KIBMW RFLMIT3 Raider CAN High: White/Green CAN Low: White/Blue Altima See www. xpresskit.com for installation schematic / Voir www. xpresskit.com pour les schéma d'installation See www. for installation schematic / Voir www.
- Page 7 VEHICLE FIT GUIDE / GUIDE DES VÉHICULES Fonctionnal if equipped Fonctionnelle si le véhicule en est équipé. Additionnal Parts Required Versa See www. xpresskit.com for installation schematic / Voir www. xpresskit.com pour les schéma d'installation Xterra Required See www. xpresskit.com...
- Page 8 VEHICLE FIT GUIDE / GUIDE DES VÉHICULES Fonctionnal if equipped Fonctionnelle si le véhicule en est équipé. Additionnal Parts Required CAN High: White CAN Low: Green RFLUB CAN High: Gray/Orange CAN Low: Purple/Orange CAN High: Gray/Orange CAN Low: Purple/Orange CAN High: White CAN Low: Green CAN High: White CAN Low: Green CAN High: Gray/Orange CAN Low: Purple/Orange XC60...
- Page 9 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required INSTALLATION WITH D2D INSTALLATION WITHOUT D2D / / INSTALLATION AVEC D2D INSTALLATION SANS D2D Cut off one plug of the D2D connector, connect the Starter or alarm red* wire to +12V and the black* wire to ground.
- Page 10 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 3 N.C. Orange Yellow N.C. N.C. Trunk Trigger White/Red White/Black Hood Trigger Tach Violet/white Grey Door Trigger (-) While running (status) Green...
- Page 11 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 5 Orange Yellow N.C. N.C. Trunk Trigger White/Red White/Black N.C. Hood Trigger Tach Violet/White Grey Door Trigger Blue/White Green (-) While running (status) N.C.
- Page 12 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 7 Configuration 8 Orange Yellow Orange Yellow N.C. N.C. N.C. N.C. White/Red White/Black Trunk Trigger Trunk Trigger White/Red White/Black N.C. N.C. Hood Trigger...
- Page 13 WARNING: On 2008 and newer vehicles (regular key & Turn button) a relay is required in the engine compartment in order to prevent permanent damage to the vehicle. See www.xpresskit.com for more information. | ATTENTION : Sur les véhicules 2008 et plus (clé...
- Page 14 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 14 Brown N.C. Green/Purple - Vert/Mauve Orange/Green (CAN High) Data (CAN Low) Data Orange/Brown Driver door pin At SJB Connector pin 11...
- Page 15 ** Only if the vehicle is equipped with a hood pin. ** Seulement si le véhicule est équipé d’un interrupteur de capot. Connect: Branchez: D2D (1 way) Connect: Branchez: D2D (2 way) WARNING: Every time the DLPK is Orange disconnected, once reconnected the Orange Yellow Yellow White/Red White/Red...
- Page 16 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 15 Configuration 17 Orange Yellow N.C. N.C. Trunk Trigger White/Red White/Black N.C. Tach Violet/White Grey Hood Trigger Door Trigger Green (-)While running (status)
- Page 17 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 19 D2D (1 way) Connect: Branchez: Orange Yellow White/Red White/Black Violet/White Grey Blue/white Green Brown Orange Yellow Orange/Green White/Violet Violet/Black Orange/Brown Trunk Trigger...
- Page 18 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 15 Configuration 21 Connect: Branchez: D2D (2 way) Orange Yellow N.C. Orange N.C. Yellow Trunk Trigger White/Red White/Black White/Red White/Black N.C. Violet/White...
- Page 19 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required WIRING SCHEMATIC CONFIGURATION / SCHÉMA DE BRANCHEMENT Configuration 15 Configuration 24 Volvo Push-to-Start : Use this diagram if the vehicle can be started without the key-fob in the key-port. The KILRV (Sold Seperately) must be used if the vehicle will only start with the key-fob in the key-port.
- Page 20 DLPK CANBUS DOORLOCK AND IMMOBILIZER INTERFACE* *RFLOOP may be required LIMITED ONE-YEAR CONSUMER WARRANTY For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material under normal use, provided the...
